DH-Vision Auto-tracking High Speed Dome Camera User Manual page 21

VIDEO ANALYSIS
-------------------------------------------
<AUTO TRACKING >
<CROSS ALARM >
<LOSS DETECT >
DELAY TIME:
DSP ENABLE:
BACK
EXIT
A. TRACKING SENSITIVITY
Move the cursor to "SENSITIVITY", press "IRIS ON" to set the parameter among
"HIGH""MID""LOW" and can adjust according to the current environment in the
surveillance area. When there are many interferential target (eg. leaves, flags) in the
surveillance area, suggested to use the low sensitivity, and normally use the middle
sensitivity.
B. PURSUIT SPEED RATE
This parameter's range is 1-6 optional, it correspond the dome camera rotational
speed, "1" means the lowest speed, and "6" means highest speed
C. PURSUIT SIZE
This parameter is divided into "BIG""MID""SMALL" 3 grades, when area of pursuit
area is more than 300㎡, suggested to set "BIG"; less than 300㎡ and more than 100㎡
suggested to set "MID"; others set to "SMALL".
D. STATIONARY FRAME THRESHOLD
This parameter is divided into "BIG""MID""SMALL" 3 grades, support to set "MID"
E. MOTION FRAME THRESHOLD
This parameter is divided into "BIG""MID""SMALL" 3 grades, support to set "MID"
F. OTHERS OPTION
Move the cursor to "OTHERS", press "IRIS ON" to set the preset location and track
location.
AUTO TRACKING
-------------------------------------------
SENSITIVITY
PURSUIT SPEED ： 2
PURSUIT SIZE ： BIG
THRESHOLD 1 ： MID
THRESHOLD 2 ： MID
< OTHERS >
ENABLE
BACK
EXIT
F1. TRACKING THE PRESET POINT
This parameter is optional from the preset location 1-4, after turn on the auto
tracking function, the preset location area of this parameter set will be the
surveillance point of auto tracking function
F2. LINKAGE OUTPUT
05
OFF
-------------------------------------------
TRACK LOCATION ：<PRT1>
： MID
LINKAGE OUT
< LEFT LIMIT >
< RIGHT LIMIT >
ENABLE ： OFF
： OFF
BACK
EXIT
AUTO TRACKING
-------------------------------------------
SENSITIVITY
： MID
PURSUIT SPEED ： 2
PURSUIT SIZE ： BIG
THRESHOLD 1 ： MID
THRESHOLD 2 ： MID
< OTHERS >
ENABLE
： OFF
BACK
EXIT
PURSUIT OTHERS
：OFF
A
B
C
D
E
F
G
F1
F2
F3
F4
F5
19
