Move the cursor to TITLE and press IRIS ON to enter the edition mode of zone title.
E4. <LEFT LIMIT>
Move the cursor to <LEFT LIMIT> and press IRIS ON to start setting the left limit of
the current zone. Then the sentence "PRESS IRIS ON TO CONFIRM"will appear on the
screen. Move the joystick and press IRIS ON to confirm.
E5. <RIGHT LIMIT>
Move the cursor to <RIGHT LIMIT> and press IRIS ON to start setting the right limit
of the current zone. Then the sentence "PRESS IRIS ON TO CONFIRM"will appear on
the screen. Move the joystick and press IRIS ON to confirm.
E6. DELETE
Press IRIS ON to delete the current zone.
F.TIMING ACTION
MOTION
――――――――――――――
<PRESET>
<SCAN>
<SEQUENCE>
<PATTERN>
<ZONES>
<TIMING ACTION>
<AUTO TRACKING>
F1. SHEDULE NO.
F2. START
Start time of timing action.
F3. STOP
Stop time of timing action.
F4 .MOTION
Timing action modes: PRESET 1-8, SCAN 1-4, SEQUENCE 1-4, PATTERN 1-4
F5: ON/OFF
Press IRIS ON to enable or disable the timing action
F6: COPY
User can copy a schedule to other 6 days in a week.
F7. BACK
Go back to upper menu
TIMING ACTION
――――――――――――――
NO. START STOP MOTION
NONE
1
0 0 : 0 0
0 0 : 0 0
NONE
2
0 0 : 0 0
0 0 : 0 0
NONE
3 0 0 : 0 0
0 0 : 0 0
NONE
0 0 : 0 0 0 0 : 0 0
4
NONE
0 0 : 0 0 0 0 : 0 0
5
6 NONE
0 0 : 0 0 0 0 : 0 0
7 NONE
0 0 : 0 0
0 0 : 0 0
NONE
8
0 0 : 0 0 0 0 : 0 0
MON COPY BACK
OFF
F1
F2
F3
F4
F5
F6
F7
