DH-Vision Auto-tracking High Speed Dome Camera User Manual page 18

D. PATTERN
――――――――――――――
<PRESET>
<SCAN>
<SEQUENCE>
<PATTERN>
<ZONES>
<TIMING ACTION>
<AUTO TRACKING>
BACK
EXIT
D1. PATTERN NO.
Move the cursor to PATT and press the key IRIS ON(key on control keyboard) to
enter the edition mode of sequence No., move the joystick upward and downward
to select number. Then press IRIS ON to confirm.
D2. TITLE
Move the cursor to TITLE and press IRIS ON to enter the edition mode of sequence
title.
D3. START
MOVE the cursor to START and press IRIS ON to start the current Pattern.
D4. <SET>
Move the cursor to SET and press IRIS ON the enter pattern setting mode. Then the
sentence "PRESS IRIS ON TO CONFIRM"will appear on the screen. Move the joystick
to do PTZ move and press IRIS ON to confirm.
D5. DELETE
Move the cursor to DELETE and press IRIS ON to delete the current pattern.
E. <ZONES>
――――――――――――――
<PRESET>
<SCAN>
<SEQUENCE>
<PATTERN>
<ZONES>
<TIMING ACTION>
<AUTO TRACKING>
BACK
EXIT
E1. ZONE INFORMATION
E2. ZONE NO.
Move the cursor to ZONE NO. and press the key IRIS ON(key on control keyboard)
to enter the edition mode of zone No., move the joystick upward and downward to
select number. Then press IRIS ON to confirm.
E3. TITLE
16
MOTION
MOTION
PATTERN
――――――――――――――
PATTERN NO. : 1
TITLE : PATTERN 1
START
<SET>
DELETE
BACK
EXIT
ZONES
――――――――――――――
－ ZONE IS NOT SET －
ZONE NO. : 1
TITLE NO. : ZONE 1
<LEFT LIMIT>
<RIGHT LIMIT>
DELETE
BACK
EXIT
D1
D2
D3
D4
D5
E1
E2
E3
E4
E5
E6
