Dahua SD60-***-SL Series Installation Manual

Anti-corrosion intelligent speed dome
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Anti-corrosion Intelligent Speed Dome
Installation Manual
Version 1.0.0

Advertisement

Table of Contents
loading

Related Manuals for Dahua SD60-***-SL Series

Summary of Contents for Dahua SD60-***-SL Series

  • Page 1 Anti-corrosion Intelligent Speed Dome Installation Manual Version 1.0.0...

  • Page 2: Table Of Contents

    Table of Contents INSTALLATION PREPARATION ................ 1 Basic requirements ..........................1 Installation Check ..........................1 Cable Requirements ..........................1 1.3.1 Video Cable Requirements ......................1 1.3.2 Power Supply Cable Requirements ....................2 SPEED DOME INSTALLATION ................3 Check Accessories ..........................3 Open the Device ............................
  • Page 3 Junction Box ............................14 Wall Mount Bracket ..........................14 Corner Mount Bracket ......................... 15 Pole Mount Bracket ..........................16 WALL MOUNT BRACKET INSTALLATION ............18 Component Installation ........................18 Wall Mount Installation Steps ......................18 4.2.1 Installation Requirements ......................18 4.2.2 Installation Steps ..........................
  • Page 4 APPENDIX Ⅱ ABOUT RS485 BUS ..............27 RS485 Bus Main Feature ........................27 RS485 Bus Transmission Distance ....................27 The Problem in Practical Use ......................27 RS485 Bus FAQ ..........................28 APPENDIX Ⅲ THE RELATIONSHIP BETWEEN THE 24V AC CABLE DIAMETER AND THE TRANSMISSION DISTANCE ..........
  • Page 5 Welcome Thank you for purchasing our speed dome! Please read the following safeguards and warnings carefully before you install or use the product!

  • Page 6: Important Safeguards And Warnings

    Important Safeguards and Warnings Safety Measures 1. Qualified Engineer Needed  The installation engineer or maintenance engineer shall have corresponding CCTV system installation certificate or maintenance qualification certificate.  The installation engineer or maintenance engineer shall have qualification certificate for work at height.
  • Page 7 Please turn off the power and unplug the power cable, If there is any smoke, disgusting smell, or noise. Please contact your local retailer or customer service center for help. All the examination and repair work should be done by the qualified service engineers. We are not liable for any problems caused by unauthorized modifications or attempted repair.
  • Page 8  Please use the soft cloth to clean dust on the shell, or you can use soft cloth with cleaning liquid to clean the shell and then use soft cloth to make it dry.  Do not use gasoline, dope thinner or other chemical material to clean the shell. It may result in shell transfiguration or paint flake.

  • Page 9: Installation Preparation

    1 Installation Preparation 1.1 Basic requirements  All installation and operation here should conform to your local electrical safety codes.  Before installation, please open the package and check all the components are included.  Please make sure the speed dome installation environment and installation mode can meet your requirement.

  • Page 10: Power Supply Cable Requirements

    1.3.2 Power Supply Cable Requirements Refer to appendix 3 for AC 24V power supply device. Refer to appendix 4 for DC12V power supply device.

  • Page 11: Speed Dome Installation

    2 Speed Dome Installation 2.1 Check Accessories Before the installation, please check the accessories one by one according to the packing list. Please make sure all the components are included (please refer to the packing list for more details). 2.2 Open the Device Step 1 Please open the box and then take out the speed dome.

  • Page 12: Dial Switch Setup

    Figure 2-2 2.3 Dial Switch Setup 2.3.1 Dial Switch Address and Function The corresponding functions of dial switch for both analog speed dome and HDCVI speed dome are different, which will be introduced respectively. 2.3.1.1 Analog Speed Dome Dismantle the bracket component; you can see there are two dial switches on the PTZ mainboard.

  • Page 13: Dial Switch Setup

    2.3.1.2 HDCVI Speed Dome Dismantle the bracket component; you can see there are two dial switches on the PTZ mainboard. You can use them to set speed dome address, baud rate and HD/SD video mode. Please refer to Figure 2-4 for the dial switch address. Figure 2-4 2.3.2 Dial Switch Setup Users must set the address number, Baud rate, parity setup or HD/SD video mode which is used...

  • Page 14: Baud Rate, Parity Setup, Hd/Sd Video Mode Setup

    Address …… ………………………………………………………………… Sheet 2-1 2.3.4 Baud Rate, Parity Setup, HD/SD Video Mode Setup The functions which need to be set are different for analog speed dome and HDCVI speed dome, which will be introduced respectively. 2.3.4.1 Analog Speed Dome It is used to set speed dome Baud rate and parity.

  • Page 15: Terminal Matched Resistance Setup

    Figure 2-7 Baud rate 9600bps 4800bps 2400bps 1200bps Sheet 2-4 HD/SD video mode Self-adaptive Sheet 2-5 2.3.5 Terminal Matched Resistance Setup The connection mode of device terminal 120Ω resistance is equipped on the power board. There are two connection modes which are shown in Figure 2-8. Figure 2-8 The factory default connection mode is shown in Figure 2-9;...

  • Page 16: Sd Card Installation (Network Speed Dome)

    2.4 SD Card Installation (Network Speed Dome) Dismantle the bracket component, open the window cover, then you can see there is a Micro-SD card slot on the module ISP board, which is shown in Figure 2-11. Micro-SD card is used to save the data.
  • Page 17 Figure 2-12 Note: The figure above is for reference only, the combination cable is based on the model of speed dome. Connect the safety hook of the speed dome to the quick installation connector, connect the integration cable reserved by the wall-mounted bracket to the multi-function combination cable of the speed dome according to the requirements, and then use the insulated rubber tape to twist the connection joints respectively to make it waterproof, which is shown in Figure 2-13.

  • Page 18: Junction Box And Protection Tube Installation

    The video port is covered with a heat shrink tube of high shrinking ratio. It needs to heat and shrink the tubes on both sides after the video port is well connected, which is to make sure the video port is damp proof and waterproof. 2.5.2 Junction Box and Protection Tube Installation The junction box is used to protect speed dome cable and port, avoid corrosion from external environment.

  • Page 19: Install Speed Dome

    Figure 2-15 The installation result is shown in Figure 2-16. Figure 2-16 2.5.3 Install Speed Dome...
  • Page 20 Step 1 Slowly put the connected integration connection cable and multi-function combination cable into the wall-mounted bracket. Step 2 Use the screws to fix the junction box on the bracket. Step 3 Push the pre-hung screw of the speed dome flange along the hanging hook on the bracket till the screw reaches the bottom of the hanging hook.
  • Page 21 Figure 2-18...

  • Page 22: Component Dimension

    3 Component Dimension 3.1 Junction Box Please refer to Figure 3-1 for the dimension of junction box. Figure 3-1 3.2 Wall Mount Bracket Please refer to Figure 3-2 for the dimension of wall mount bracket.

  • Page 23: Corner Mount Bracket

    Figure 3-2 3.3 Corner Mount Bracket Please refer to Figure 3-3 for the dimension of corner mount bracket.

  • Page 24: Pole Mount Bracket

    Figure 3-3 3.4 Pole Mount Bracket Please refer to Figure 3-4 for the dimension of pole mount bracket.
  • Page 25 Figure 3-4...

  • Page 26: Wall Mount Bracket Installation

    4 Wall Mount Bracket Installation 4.1 Component Installation The wall mount bracket needs to be used with a junction box, which is shown in Figure 4-1. Figure 4-1 4.2 Wall Mount Installation Steps 4.2.1 Installation Requirements The wall mount speed dome can be installed in the hard construction wall in the indoor or outdoor environments.
  • Page 27 Figure 4-2 Step 2 Install the speed dome onto the wall mount bracket. Please refer to Figure 4-3 for more details. Please refer to “Chapter 2.6 Speed Dome Installation” for detailed installation modes. Figure 4-3...

  • Page 28: Corner Mount Bracket Installation

    5 CORNER MOUNT BRACKET INSTALLATION 5.1 Component Installation The corner mount bracket needs to be used with a junction box, please refer to Figure 5-1 for the accessories which are needed for installation. Figure 5-1 5.2 Corner Mount Bracket Installation Steps 5.2.1 Installation Requirements The corner mount speed dome can be installed in the hard construction wall in the indoor or outdoor environments where there is a 90︒...
  • Page 29 Figure 5-2 Step 2 Install a junction box on the corner mount bracket. Step 3 Install speed dome according to Figure 5-3, please refer to Chapter 2.6 for more details about speed dome installation.
  • Page 30 Figure 5-3...

  • Page 31: Pole Mount Bracket Installation

    6 Pole Mount Bracket Installation 6.1 Component Installation Pole mount bracket needs to be used with a junction box, please refer to Figure 6-1 for the accessories which are needed for installation. Figure 6-1 6.2 Pole Mount Bracket Installation Steps 6.2.1 Installation Requirements The pole-mounted speed dome can be installed in the hard construction wall in the indoor or outdoor environments.
  • Page 32 Pull the cable out of the pole accessories and then use clamp to fix the pole accessories to the pole. Finally, you can use silicon sealant to cover the outlet hole to make it sealed and waterproof. Figure 6-2 Note： After the installation, please make sure the clamp is firmly fastened in case it may result in broken clamp.
  • Page 33 Figure 6-3...

  • Page 34: Appendix Ⅰ Lightning Proof And Surge Protection

    7 APPENDIX Ⅰ LIGHTNING PROOF AND SURGE PROTECTION This series speed dome adopts TVS lighting protection technology. It can effectively prevent damages from various pulse signals below 6000W, such as sudden lighting and surge. While maintaining your local electrical safety code, you still need to take necessary precaution measures when installing the speed dome in the outdoor environment.

  • Page 35: Appendix Ⅱ About Rs485 Bus

    8 APPENDIX Ⅱ ABOUT RS485 BUS 8.1 RS485 Bus Main Feature RS485 is semi duplex communication cable of impedance 120Ω. Its max load amount is 32 effective loads (including main control device and devices to be charged). 8.2 RS485 Bus Transmission Distance When we take 0.56mm (24AWG) twisted-pair as communication cable, the max transmission distance (theoretically) are listed below (according to different baud rates).

  • Page 36: Rs485 Bus Faq

    Figure 8-2 8.4 RS485 Bus FAQ Phenomenon Possible Reasons Solution   Modify host or speed dome setup ； Speed dome Host address(baud rate) and can run self- speed dome address(baud rate)  Switch RS485 positive end and diagnosis but I are not match;...

  • Page 37: Diameter And The Transmission Distance

    9 APPENDIX Ⅲ THE RELATIONSHIP BETWEEN THE 24V AC CABLE DIAMETER AND THE TRANSMISSION DISTANCE It is the recommended transmission distance when the cable diameter is fixed and the 24V AC power consumption is below 10%. For the AC device, the max permission voltage power consumption is 10%.
  • Page 38 Feet（m） 0.8000 1.000 1.250 2.000 38.17 59.63 152.66 24.43（7.45） （11.63） （18.18） （46.53）...

  • Page 39: Appendix Ⅳ The Relationship Between The 12V Dc Cable

    10 APPENDIX Ⅳ THE RELATIONSHIP BETWEEN THE 12V DC CABLE DIAMETER AND THE TRANSMISSION DISTANCE It is the recommended transmission distance when the cable diameter is fixed and the 12V DC power consumption is below 10%. For the DC device, the max permission voltage power consumption is 10%.
  • Page 40 Feet（m） 0.8000 1.000 1.250 2.000 38.17 6.11（1.86） 9.54（2.91） 14.91（4.54） （11.63）...

  • Page 41: Appendix Iv Wire Gauge Reference Sheet

    11 APPENDIX IV WIRE GAUGE REFERENCE SHEET Metric bare wire Bare wire cross diameter section （mm） （mm ） 0.050 0.00196 0.060 0.00283 0.070 0.00385 0.080 0.00503 0.090 0.00636 0.100 0.00785 0.110 0.00950 0.130 0.01327 0.140 0.01539 0.160 0.02011 0.180 0.02545 0.200 0.03142 0.230...
  • Page 42 Note  This manual is for reference only. Slight difference may be found in the user interface.  All the designs and software here are subject to change without prior written notice.  All trademarks and registered trademarks are the properties of their respective owners.
