1 Getting Started

1.1 Power ON/OFF

To turn the unit ON, simply push and press down the OK –button for a couple of
seconds.
NOTICE, The unit will start booting up (which takes about 10-15 seconds) The unit
will "beep" in a steady pace and the LCD back-light will lit during start-up.
The unit starts in Easy Find mode on the last selected satellite position.
To turn the unit OFF, push and hold down the Ok –button for a couple of seconds.

1.2 Power supply and battery

satlook Lite can be fed by an external power-supply through the VDC port, by an
external power-source (12v dc, max 1.2A). This is useful in case that the battery goes
empty during an installation. Connect the power-source and hold down the ON
button for a couple of seconds (until the unit turns On).
To turn the unit OFF when the unit is fed by an external power-supply, simply
disconnect the power-source.
A discharged battery takes about 14 hours to recharge. The recharging is controlled
by the units microprocessor and is indicated on the display. Please notice that to
obtain full capacity of new batteries it is necessary to recharge and run down the
battery-pack a couple of times.
The meter has 8 x AA rechargeable NiMe batteries in the battery-compartment. Apart
from recharging the battery the unit does not need any particular maintenance. The
unit should be recharged when the battery is empty (indicated with a battery-indicator
symbol on the display. A fully charged battery is operational for about an hour
(depending on the external antenna load).

1.3 How to use the meter

Start by connecting the LNB of the dish and then turn the meter On.
The instrument starts in the "EasyFind"-mode which makes it easy to detect the
satellite/s You are looking for.
Satellite
Searching
