DREAMS 215-00945 Assembly Instructions Manual

Knox bed

Advertisement

Quick Links

Knox bed
Assembly Instructions
Before you
Start, here
are some
helpful
advices.
Revision number 1/1
1. We suggest you spend a short time reading through this leaflet and then follow
the simple step by step instructions.
2. If you follow the instructions carefully the end result should be worth the effort.
3. Do not discard any of the packaging until you have checked that you
have all the parts and the pack of fittings.
4. Assemble this product on a carpet.
5. To ensure an easier assembly, we strongly advise that all fittings are only
finger tightened during initial assembly. Only upon completion of the.
Assembly should all fixing points be fully tightened.
6. We recommend a periodic check on all fixing points to make sure they remain
fully tightened.
7. Keep glue and fittings out of children s reach.
In the unlikely event that this product has missing or damaged parts, please call
03442 920000 to obtain spares
215-00945 (Solid slats)
215-00946 (Sprung slats)

Advertisement

loading
Need help?

Need help?

Do you have a question about the 215-00945 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DREAMS 215-00945

  • Page 1 215-00945 (Solid slats) Knox bed 215-00946 (Sprung slats) Assembly Instructions Before you 1. We suggest you spend a short time reading through this leaflet and then follow Start, here the simple step by step instructions. 2. If you follow the instructions carefully the end result should be worth the effort.
  • Page 2 PARTS Fittings M6x35mmx6 pcs M3x 35mmx1pc M6nut x6pcs M6 Washer x6 pcs NO. PART LIST (1) HEADBOARD (2) FOOTBOARD M4Allen key x 2pcs (3) WOODEN FEET (4) SIDE RAILS (5) SUPPORT LEG M5Allen key x 1pc Plastic Washer x 4pcs Not included Revision number 1/1...
  • Page 3 ASSEMBLY (1). Attach the Wooden Feet to the headboard and footboard by using STEP 1 M5 Allen key × 1pcs Plastic Washer (G) . Plastic Washer x4pcs ( ). Loosen the pre-assembled bolts on the headboard and footboard with the Allen Key(F) Note: Leave 10 mm protruding as in the diagram 10mm...
  • Page 4 ASSEMBLY (1). Attach the side rails to the STEP 2 headboard and footboard. Revision number 1/1...
  • Page 5 ASSEMBLY MAKE CERTAIN THE BED IS STEP 3 SQUARED UP .AS SHOWN ON M5 Allen key × 1pcs THE RIGHT. Once all four comers are located. make sure the bed is still square as in the sketch.then tighten all the bolts 100% using Allen key (F).
  • Page 6 M3 × 35 mm x 1 pc bedstead. You can make a choice between the two slats. M6 nut x 6 pcs OPTION"A": DREAMS FIXED WOOD SLATS M6 Washer x6pcs (1) Carefully locate the slats M4 Allen key × 2 pcs onto the unit.
  • Page 7 ASSEMBLY OPTION"B": DREAMS SPRUNG STEP 5 M6 × 35 mm x 6 pcs SLATS 1) Use the bolt to fix support leg M6 nut x 6 pcs onto the slat frame. Please note that these bolts are to be found inside the slat frame box.

This manual is also suitable for:

215-00946
