SAFETY AND INSTRUCTION MANUAL

Charcoal Grill

26500/008 - TCP 450
26500/009 - TCP 450L
26500/010 - TCP 560
26500/002 - TCP 320
26500/005 - TCP 320F
26500/003 - TCP 320L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TCP-320 and is the answer not in the manual?

Questions and answers

Related Manuals for Tramontina TCP-320

Summary of Contents for Tramontina TCP-320

  • Page 1: Charcoal Grill

    SAFETY AND INSTRUCTION MANUAL Charcoal Grill 26500/008 - TCP 450 26500/009 - TCP 450L 26500/010 - TCP 560 26500/002 - TCP 320 26500/005 - TCP 320F 26500/003 - TCP 320L...

  • Page 3: Table Of Contents

    2.3. TCP-320F ..................................4 2.4. TCP-450 ..................................5 2.5. TCP-450L ..................................5 2.6. TCP-560 ..................................5 3. CHARCOAL GRILL COMPONENTS BY MODEL ........................6 3.1. MODEL TCP-320 ................................6 3.1.1. Components: ...............................6 3.1.2. Assembly instructions: ............................6 3.2. MODEL TCP-320L .................................7 3.2.1. Components: ................................7 3.2.2. Assembly instructions: ............................7 3.3.

  • Page 4: Introduction

    This is the manual for grill models TCP-320, TCP-320L, TCP-320F, TCP- To maintain your grill’s smooth performance and make it last longer, follow the 450,TCP-450L e TCP-560. Therefore, please do not take into consideration guidelines in this manual.

  • Page 5: Tcp-450

    2.4. TCP-450 (Ref.: 26500/008): *The dimensions below are for reference only. Identification Measurements (cm) Ø47.0 73.6 16.3 52.0 2.5. TCP-450L (Ref.: 26500/009): *The dimensions below are for reference only. Identification Measurements (cm) Ø47.6 73.6 16.3 52.0 97.3 2.6. TCP-560 (Ref.: 26500/010): *The dimensions below are for reference only.

  • Page 6: Charcoal Grill Components By Model

    3. CHARCOAL GRILL COMPONENTS BY MODEL 3.1. MODEL TCP-320 (Ref.: 26500/002): 3.1.1. Components: ITEM DESCRIPTION QUANTITY LARGE SILICONE SUPPORT SMALL SILICONE SUPPORT UTENSIL FOR HANDLING COOKING GRATES STAINLESS STEEL COOKING GRATE STAINLESS STEEL CHARCOAL TRAY ENAMELED STEEL BOWL PAINTED STEEL TRIPOD...

  • Page 7: Model Tcp-320L

    3.2. MODEL TCP-320L (Ref.: 26500/003): 3.2.1. Components: ITEM DESCRIPTION QUANTITY LARGE SILICONE SUPPORT SMALL SILICONE SUPPORT UTENSIL FOR HANDLING COOKING GRATES ENAMELED STEEL COOKING GRATE ENAMELED STEEL CHARCOAL TRAY ENAMELED STEEL BOWL PAINTED STEEL TRIPOD PIN WITH M6 THREAD M6 WING NUT METALLIC WASHER INSULATING WASHER M5 SCREW...

  • Page 8: Model Tcp-320F

    3.3. MODEL TCP-320F (Ref.: 26500/005): 3.3.1. Components: ITEM DESCRIPTION QUANTITY LARGE SILICONE SUPPORT SMALL SILICONE SUPPORT UTENSIL FOR HANDLING COOKING GRATES STAINLESS STEEL COOKING GRATE STAINLESS STEEL CHARCOAL TRAY ENAMELED STEEL BOWL PAINTED STEEL TRIPOD M4 SCREW M4 NUT STAINLESS STEEL HOLDER FOR COOKING GRATE AND TRAY M6 LARGE SCREW METALLIC WASHER...

  • Page 9: Model Tcp-450

    STEP 3 STEP 4 Place the tray (item 5) on the lower part of the holders and the cooking grate (item 4) Attach the holder (item 19) to the lid (item 20) using the M5 screw (item 15), a on the upper part of the holders as shown in picture 09. If using the skewer support metallic washer (item 12) and insulating washer (item 13), as shown in picture 11.

  • Page 10: Assembly Instructions

    3.4.2. Assembly instructions: STEP 1 STEP 3 Align two M6 screws (item 10) with the holes in the outer holder (item 2) according Position the chrome steel triangle (item 8) and secure it with M5 screws (item 9), to picture 12. Insert the holder with the screws into the bowl (item 6), making sure as shown in picture 16.

  • Page 11: Model Tcp-450L

    3.5. MODEL TCP-450L (Ref.: 26500/009): 3.5.1. Components: ITEM DESCRIPTION QUANTITY STAINLESS STEEL LEG STAINLESS STEEL OUTER HOLDER STAINLESS STEEL INNER HOLDER STAINLESS STEEL COOKING GRATE ENAMELED STEEL CHARCOAL TRAY ENAMELED STEEL BOWL UTENSIL FOR HANDLING COOKING GRATES CHROME STEEL TRIANGLE M5 SCREW M6 SCREW M6 NUT...
  • Page 12 STEP 2 NOTE: The cooking grate (item 4) is double-sided, meaning it can be used on both Hold the existing pin on the leg (item 1) and insert it into the securing hole of the of its sides: outer holder (item 2), according to picture 24. Make sure that the hole of the outer •...

  • Page 13: Model Tcp-560

    STEP 7 Attach the thermometer (item 14) using its metallic washer (item 20) and a wing nut The internal holder allows for the lid to be supported on the grill bowl, as shown (item 17), as shown in pictures 34 and 35. in picture 36.

  • Page 14: Assembly Instructions

    3.6.2. Assembly instructions: ITEM DESCRIPTION QUANTITY Follow all instructions in this manual for the correct grill assembly M6X12 SCREW procedure. M6X12 SCREW To quickly assemble your grill, please follow the instructions below: M4X12 SCREW M5X10 SCREW • Remove all parts from the packaging and carefully display all items on a level surfac(separate small and large parts).
  • Page 15 STEP 5 Attach the handle (item 24) to the shaft (item 21) then attach them to the air inlet ring (item 20) using a nut (item JJ), as shown in picture 41. Picture 44 STEP 8 Picture 41 Attach the handle (item 1) to the lid (item 3) using M6x12 screws (item AA), metallic washers, and insulating washer (items HH and II), and then attach the STEP 6 thermometer (item 2) using the wing nut that has been already attached to it as...

  • Page 16: General Safety Information

    • Incorrect assembly can be dangerous. Follow this manual’s assembly instructions length: 40 cm). as well as the video available on Tramontina’s website. Only use the grill when all • For the TCP-560 grill we recommend using Tramontina skewers 75cm.

  • Page 17: Cooking Methods

    If you want the food to cook more slowly, the air inlet It is not possible to use the indirect cooking method in the TCP-320, TCP-320L, should be reduced. Please disregard this information if your model does not have TCP-320F, TCP-450 and TCP - 450L models.

  • Page 18: Cleaning Instructions

    • Wash the grates using a metal bristled brush, mild detergent, and warm water. Rinse to chemicals, directly or in the atmosphere; well with clean water and keep the grill dry. We recommend using a Tramontina • Occurrence of corrosion (rust) due to exposure to high humidity or retention of brush with metal bristles.
  • Page 20 Belém: Fone: (91) 4009.7700 Belo Horizonte: Fone: (31) 3223.4026 Curitiba: Fone: (41) 2111.9110 Goiânia: Fone: (62) 3272.2100 Porto Alegre: Fone: (51) 2101.5000 Recife: Fone: (81) 3128.5500 Rio de Janeiro: Fone: (21) 2224.5004 Salvador: Fone: (71) 3215.8266 São Paulo: Fone: (11) 4197.1266 www.tramontina.com...
