Summary of Contents for Hunter Douglas Duette EasyView Arch
- Page 1 Installation Operation Care • • Duette Honeycomb Shades ® EasyView Arch ®...
-
Page 2: Table Of Contents
Cleaning Procedures ............14 Child Safety: Warning ................16 Questions? Call the Hunter Douglas Customer Information Center at 1-888-501-8364. © 2016 Hunter Douglas. All rights reserved. All trademarks used herein are the property of Hunter Douglas or their respective owners. -
Page 3: Getting Started
GETTING STARTED Product View Arch Trim Top Cord Guide Arch Handle Bottom Rail Installation Brackets... -
Page 4: Tools And Fasteners Needed
GETTING STARTED Thank you for purchasing the Hunter Douglas Duette EasyView Arch. With proper installation, ® ® operation, and care, your new shade will provide years of beauty and performance. Please thoroughly review this instruction booklet and the enclosed packing list before beginning the installation. -
Page 5: Installation
INSTALLATION Installation Overview Your order will include two installation brackets specific to the fabric pleat size and type of ■ brackets ordered. " " " " Standard Standard Swivel Swivel " " End Mount End Mount Installation Installation Bracket Bracket Bracket Bracket (Optional) -
Page 6: Mount The Installation Brackets - Inside Mount
INSTALLATION Mount Installation Brackets — Inside Mount Place the shade in the window. ■ Mark the mounting surface below the two bottom cord guides. ■ Find the center point between your mark and the window jamb. ■ Center Bracket (For Shades Over 30") Center Point... -
Page 7: Mount The Installation Brackets - End Mount
INSTALLATION Drill the screw holes using a " drill bit. ■ CAUTION: Use drywall anchors when mounting into drywall. Attach the installation brackets using the screws provided. ■ Check that the mounting surface is level and the brackets are aligned. If mounting to a ➤... -
Page 8: Install The Shade
INSTALLATION Attach the End Mount Brackets to the Window Jamb Fully lower the shade. ■ Position the fully lowered shade in the window. ■ Gently push the fabric away from the end mount brackets to allow access to the ■ screw holes. -
Page 9: Install The Arch Trim
INSTALLATION Install the Arch Trim To size the trim, position it along ■ the entire curved surface, inside the window frame. Notch Mark where to cut the arch trim. ■ With inside-mounted shades, the ends of the trim should rest on the bottom of the window casement. - Page 10 INSTALLATION Mark and drill the back hole of the guide. ■ Put a screw in the back hole only. ■ Check the top cord guide placement by moving the arch handle to the right to raise the ■ shade. Determine if the top center cord guide is in the correct location by watching the fabric rise.
-
Page 11: Operation
OPERATION Shade Operation To close the shade, slide the arch handle to the right. ■ Close To open the shade, slide the arch handle to the left. ■ Open... -
Page 12: Troubleshooting
OPERATION Troubleshooting Problem The top cord guide does not reach the top of the window opening. Solution Decrease Tension / Lengthen the Center Cord Open the shade by pulling the handle all the way to the left. Locate the cord from the right hole next to the pocket (as shown). Remove the ferrule from the pocket by pulling on the excess cord Ferrule Pocket... - Page 13 OPERATION Problem The shade has a droopy cord or the shade will not stay up. Solution Increase Tension / Shorten the Center Cord Close the shade by moving the handle all the way to the right. Locate the cord from the right hole next to the pocket (as shown). Remove the ferrule from the pocket by pulling on the excess cord Ferrule Pocket...
- Page 14 OPERATION Problem The fabric rubs against the window casement while opening or closing the shade. Solution Adjust the Shade Before trimming the shade, be sure that the bottom rail is level. Shim if necessary. Also check that the top cord guide is directly above the center of the shade.
-
Page 15: Care
CARE Removing the Shade (If Necessary) Lower the shade completely. ■ Screws Remove the two screws securing the top cord guide ■ in place. Top Cord Guide Shade Lift Cords Standard Installation Brackets While holding the rail, loosen the tab screw on each ■... -
Page 16: Cleaning Procedures
CARE Cleaning Procedures Hunter Douglas Duette honeycomb shades are made of anti-static, dust-resistant fabric which ® repels dirt and dust. For most honeycomb fabrics, the following cleaning options are available. Dusting Regular light dusting with a feather duster is all the cleaning that is needed in most ■... - Page 17 CARE Ultrasonic Cleaning CAUTION: Do not ultrasonically clean Batiste Semi-Sheer, Opalessence , and all ™ opaque fabrics. Some honeycomb fabrics can be ultrasonically cleaned by a professional. ■ Specify that a mild detergent solution be used. ■ Never immerse the headrail into the solution. ■...
-
Page 18: Child Safety
CHILD SAFETY WARNING For more safety information call 1-888-501-8364 in the U.S. or 1-866-662-0666 in Canada. Young children can STRANGLE in cord loops. They can also wrap cords around their necks and STRANGLE. Always keep cords out of the reach of children. ■... - Page 20 2. Visit hunterdouglas.com for additional warranty information, frequently asked questions and access to service locations. 3. Contact Hunter Douglas at (888) 501-8364 for technical support, certain parts free of charge, for assistance in obtaining warranty service or for further explanation of our warranty.
