Controls
acceSSorieS
Resetting
If there are any problems, such as the
abnormal display of frequency or failure of
selection, reset the radio by pressing the "4"
button while pressing the AST button and
the AUX button together. Then, "JP" and the
clock display appear on the LCD, indicating
that the radio is turned off. Note that the
memory stored in the preset button is
cleared.
SPECIFICATIONS
Power source: .... 12/24 VDC (negative
Maximum power consumption:
........................... 3A or less (at max. volume,
Maximum output power:
........................... 16 W + 16 W (4Ω) (at 28.8
Rated output power:
........................... 12 W + 12 W (10%
Dimensions: ........ 178 (W) x 50 (H) x 65 (D)
Receiving frequency:
........................... MW (AM) 531 to 1602 kHz
Practical sensitivity:
........................... MW (AM) 32 dB or less
S/N ratio: ............ MW (AM) 40 dB or more
AUX-IN: .............. Stereo mini jack (3.5 mm);
Note: Specifications and dimensions may be
changed without notice.
2-41
ground)
24 V)
VDC input)
5W+5W (4Ω) (at 14.4 VDC
input)
distortion, 4Ω) (at 28.8
VDC input)
3.5 W + 3.5 W (10%
distortion, 4Ω) (at 14.4
VDC input)
mm (excluding protrusions)
(Europe, Asia), 530 to
1710 kHz (North, Central
and South America)
FM 87.5 to 108 MHz
(Europe, Asia), 87.9 to 108
MHz (North, Central and
South America)
(S/N 20 dB)
FM 12 dB or less (S/N 30
dB)
FM 50 dB or more
rated input, 90 mV; 20 kΩ
impedance
