PEAK 637 User's Guide
Chapter 1: Specification
The PEAK 637 is a full size Single Board Computer. It applies single Socket 370 FC-PGA based
processor, supporting both 66 MHz (Celeron) and 100 MHz (Pentium III) FSB CPU up to 850 M+Hz and
future Intel 100MHZ FSB CPU to 1GHZ or 1.1GHZ. The memory it can accommodate is 512 MB
SDRAM up to 100 MHz.
PEAK 637 will be offered at extraordinary good pricing while also equip with powerful features.

System architecture

Full size SBC with PCI/ISA Gold finger
Intel Brand New Socket 370 Celeron/Pentium III with 66/100MHz FSB
PCI V2.1 complied
PICMG 1.0 (Rev.2.0) complied

CPU Support

Intel Celeron/Pentium III (FC-PGA) CPU with 128/256 cache on die up 850MHz,
100MHZ FSB CPU to 1GHZ or 1.1GHZ
Supports streaming SIMD instruction

Main Memory

Support SDRAM up to 512MB (Max.)
168 pin DIMM socket ×2
BIOS
Award System BIOS
Chip Set
Intel 82440BX AGP set
66/100MHz FSB support
PCI V2.1 complied
On Board RTC
High precision real time clock/calendar with battery back up

Watchdog Timer

1, 2, 4 ..... 64 seconds time-out intervals
