It can be useful as a monitoring/troubleshooting tool or as a standalone DVB- ASI Transport Stream
output with rates up to 50 Mbps.
As a monitoring/troubleshooting tool the user can verify the correct operation of the encoder –
decoder portion of the link by running this output directly into the decoder's ASI INPUT, essentially
bypassing the RF portion of the link.
As a standalone Transport Stream output the encoder can be placed into a "Encoder" only mode in
which the ASI Transport Stream rates can run as high as 50 Mbps (see software section 5.1).
*P5

4.3.7 KLV TIME SYNC IN

Connector Type: BNC-F, 75 ohm
This input is used to provide time-correlated KLV-1 and KLV-2 META data processing that is used in
Airborne Surveillance Applications and Geospatial determination.
100-M0177X1 18 of 40
