EMERGENCY LOCATOR TRANSMITTER
Abbreviated Component Maintenance Manual
This manual includes data for the equipment that follows:
Component
Emergency Locator Transmitter
Emergency Locator Transmitter
C406-2 SERIES
Part No.
453-5000
453-5001
25-62-11
Model No.
C406-2
C406-2HM
Wulfsberg Electronics Division
Wulfsberg Electronics Division
6400 Wilkinson Rd., Prescott, AZ 86301
6400 Wilkinson Rd., Prescott, AZ 86301
Cage Code: 1B7G3
Cage Code: 1B7G3
570-5000 Rev. C
Initial Issue JUN 30/1999
Page 1 of 90
APR 06/10
