Summary of Contents for Clarke MBS600D
-
Page 1: Assembly Instructions
COMPOUND MITRE SAW MODEL NO: MBS600D Part No: 6461516 ASSEMBLY INSTRUCTIONS GC05/12... -
Page 2: Environmental Protection
GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase. -
Page 3: Component Guide
WORK STOP WORK CLAMP Upon receipt of the product, unpack all loose components and check for any missing parts. Any identified should be reported to your Clarke dealer. The MBS600D includes the following: 1 x Saw Table with wooden base... - Page 4 ASSEMBLY GUIDE RODS, SAW FRAME AND BLADE 1. Attach the handle to the upright FIXING SCREWS part of the saw frame using the two screws, with the nuts seated in the handle moulding. 2. Connect the polymer guide pieces to the saw frame assembly as shown in Fig 1.
-
Page 5: Work Clamp
6. With the saw frame assembly in TENSIONING WING NUT position, tension the blade using the wing nut, until any sideways deflection of the blade is minimal. • This is essential to ensure a straight and repeatable cut from the blade. -
Page 6: Cutting Technique
USING THE MITRE SAW CUTTING SIMPLE MITRES OR BEVELS Simple mitres or bevels are cuts made in one plane only. For simple mitres, the carriage is moved to the desired angle to the base by pulling the horizontal quadrant release lever to allow the carriage to swivel, with the saw blade remaining perpendicular to the table. -
Page 7: Specifications
SPECIFICATIONS Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice. Parts & Service: 020 8988 7400/E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
