a. Check Active Status or Inactive Status depending
on whether you want to actively monitor the ports or
not.
b. Check Trunk if you only want to select trunk (uplink)
ports in the filter. If Trunk is not checked, then both
trunk ports and access ports will be selected in the
filter.
c. Specify Port Range using values separated by
commas. HP uses a convention of 1-48. Cisco uses
a row/port notation (and a switch/row/port notation for
stacked switches). An example for Cisco is: 0/1-48,
1/1-48,1/1-24 etc.
d. Specify VLAN as an integer ranging from 1-4095.
You can provide a comma-separated list or range.
For example: 1,2,5,6-20,66.
e. Specify Port Description for each port by specifying
a different description on each line using strings, *, or
regular expressions. For information about using
regular expressions, refer to Appendix C, "Regular
Expression Pattern Matching."
8. Expand the Device tree at the bottom of the page and select the desired
ports:
9. Click Filter All Ports Below to apply the selected filtering options to the
selected ports. If you want to undo the filtering, deselect the Advanced
Filtering Options chosen previously and click Filter All Ports Below.
Then click the check box next to the Name column (or the check box next
to each desired device name) to restore all the discovered ports.
10. Click NEXT to begin monitoring the selected ports.
11. If no new Active Directory Domain Controllers were discovered, and you
want to monitor users with UDT, you will need to add the relevant AD
domain controllers after finishing the discovery wizard.
In the meantime, click IMPORT.
Details on the ports successfully imported are listed.
User Device Tracker Port Discovery
