3Com 3CRFW102 User Manual page 9

Setup with No
Networking Installed
10 When the Select OEM Option window opens, select 3Com Firewall PC Card with
11 Click Next.
12 In the Network Protocols list, place a check mark next to each network protocol
13 In the Network Services window, place a check mark in the box next to each
14 Click Next to install the selected components.
15 Click Next.
• The protocol used in the Microsoft Windows network (NWLink IPX/SPX
compatible transport, TCP/IP protocol, NetBEUI protocol).
• The name of the NT server domain or workgroup to which you belong.
• Your IP address (unless you are using DHCP).
If no networking is installed, follow these steps:
1 Turn your notebook computer on.
2 Install your Card and Socket Services (i.e. Softex or SystemSoft).
3 Copy i386 directory from Windows NT CD to your hard drive.
4 In SystemSoft you will be prompted to configure the PC card when it is inserted.
Click Correct.
In Softex you will be prompted to configure the PC card when it is inserted. Select
"Manually install the driver for this card".
When the Select OEM Driver window opens, select "Network Adapter" and click
OK.
5 When the system prompts: "Windows NT Networking is not installed. Do you
want to install it now?", click Yes. This opens the Network Setup Wizard.
If this message does not appear, go to "Windows NT With Networking Installed,"
and follow the instructions.
6 Check Wired to the network and click Next.
7 When the system prompts to have setup start searching for a network adapter,
click Select from List.
8 Click Have Disk.
9 Insert the 3Com Firewall PC Card with 10/100 LAN Installation CD in the CD-ROM
drive. Type the path to drivers (where D:\ is your CD-ROM drive).
For SystemSoft: D:\drivers\syssoft
For Softex: D:\drivers\softex
Then click OK.
10/100 LAN and click OK.
The Network Setup Wizard window appears.
required for your site and click Next.
desired service. Select the default settings.
The message "Windows NT is ready to install networking" appears.
The Windows NT Setup windows asks for the location of the Windows NT
installation files.
Setup for Windows NT 4.0 5
