5 In the Control Panel, double-click Network.
6 Open the Adapter tab and click Add.
The Select network Adapter window appears.
7 If the message "networking not installed" appears, go to "Setup With No
Networking Installed" for instructions.
8 Click Have Disk.
9 Insert the 3Com Firewall PC Card with 10/100 LAN Installation CD in the CD-ROM
drive. Type the path to drivers (where D:\ is your CD-ROM drive).
For SystemSoft: D:\drivers\syssoft
For Softex: D:\drivers\softex
Then click OK.
10 When the Select OEM Option window opens, select 3Com Firewall PC Card with
10/100 LAN and click OK.
11 Wait while the files are copied to your notebook.
12 In the Network Settings window, accept the default settings and click Continue.
The default settings work in most instances. However, you may specify network
link settings, auto polarity, and IRQ and I/O values.
13 Click OK to save.
14 If prompted, enter IP information and click OK.
15 When prompted whether you are using DHCP, click Yes, if you are using DHCP, or
No, if you are not using it.
16 When prompted to restart the notebook, remove the 3Com Firewall PC Card with
10/100 LAN Installation CD from the CD-ROM drive and click Yes.
SystemSoft Note: After installation, the card will not be hot-swappable until a
Hot-Swap test is performed. Open the CardWizard and select the 3Com Firewall
PC Card. Click Wizard. The Wizard information window appears. Click Test to
perform the Hot-Swap test and follow the prompts.
Setup for Windows NT 4.0 7
