6 C 1: I
HAPTER NSTALLING THE
Confirming Installation
Windows NT with
Networking Installed
PC C D
ARD AND RIVERS
16 Enter the path to the Windows NT installation files (this is the location on the hard
drive where the I386 directory was copied from the NT CD) and click Continue.
The Setup window appears again.
17 In the 3Com Network Interface dialog box, accept the default settings and click
OK.
The default settings work in most instances. However, you may specify network
link settings, auto polarity, and IRQ and I/O values.
18 When prompted whether you are using DHCP, click Yes, if you are using DHCP, or
No, if you are not using it.
19 When the Protocol window for enabling or disabling protocols opens, click Next.
20 When Windows NT is ready to start the network, click Next to copy the network
files.
21 Enter your notebook name and workgroup or domain name when prompted.
22 When the system displays "Networking has been installed on your notebook,"
click Finish.
23 When prompted to restart the notebook, remove the 3Com Firewall PC Card with
10/100 LAN Installation CD from the CD-ROM drive and click Yes.
If you had a Windows service pack installed prior to setting up the PC Card,
reinstall it now.
SystemSoft Note: After installation, the card will not be hot-swappable until a
Hot-Swap test is performed. Open the CardWizard and select the 3Com Firewall
PC Card. Click Wizard. The Wizard information window appears. Click Test to
perform the Hot-Swap test and follow the prompts.
To confirm installation:
1 Double-click My Computer, double-click Control Panel, and then double-click
Network.
2 Select the Adapters tab.
3Com Firewall PC Card with 10/100 LAN appears on the list.
Follow these steps if networking is installed:
1 Make sure Card and Socket Services are installed (i.e. Softex or SystemSoft).
2 Turn the notebook on.
3 Insert your PC card.
4 In SystemSoft you will be prompted to configure the PC card when it is inserted.
Click Correct.
In Softex you will be prompted to configure the PC card when it is inserted. Select
"Manually install the driver for this card".
When the Select OEM Driver window opens, select "Network Adapter" and click
OK.
