B Configuring IPSec
30
Defining the Console
This sequence establishes the console and defines its parameters.
1 In the Windows task bar, click Start>Programs>Accessories>CommandPromp.
2 At the DOS prompt, enter
MMC
The Console1 screen appears
3 In the menu, click Console, then Add/Remove Snap-in.
The Add/Remove Snap-in screen appears.
4 Click Add.
The Add Standalone Snap-in screen appears.
5 Select IP Security Policy Management and click Add.
The Select which computer this Snap-in will manage screen appears.
6 Enable the Local computer option.
7 Click Finish, Close, and then OK.
Creating the Policy
This sequence creates and names the new security policy.
The Console1 and Console Root screen appears with IP Security Policies on Local Machine
displayed in the list.
1 In the left pane, click IP Security Policies on Local Machine.
2 Right-click inside the right pane below the list items.
3 From the pop-up menu, select Create IP Security Policy.
The IP Security Policy Wizard starts.
4 Click Next.
The IP Security Policy Name screen appears.
5 Enter a name for the new security policy that you are creating and, if you wish, a
description that identifies the policy.
6 Click Next.
The Requests for Secure Communication screen appears.
7 Clear the Activate the default response rule check box.
8 Click Next and then Finish.
9 Click Add.
The Security Rule Wizard starts.
10 Click Next.
The Tunnel Endpoint screen appears.
11 Enable the default option This rule does not specify a tunnel, and click Next.
The Network Type screen appears.
12 Enable the default option All network connections, and click Next.
The Authentication Methods screen appears.
13 Enable the Use this string to protect the key exchange (preshared key): option, type
the appropriate string text in the entry field, and then click Next.
