Thuraya Orion IP
Satellite Terminal
Maritime Installation Guide
3500867-0001
Revision 5
November 31Dec, 2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Thuraya Orion and is the answer not in the manual?

Questions and answers

Summary of Contents for Hughes Thuraya Orion

  • Page 1 Thuraya Orion IP Satellite Terminal Maritime Installation Guide 3500867-0001 Revision 5 November 31Dec, 2013...
  • Page 2 Hughes Network Systems, LLC has made every effort to ensure the correctness and completeness of the material in this document. Hughes Network Systems, LLC shall not be liable for errors contained herein. The information in this document is subject to change without notice. Hughes Network Systems, LLC makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
  • Page 3: Table Of Contents

    Messages concerning personal injury ...................... vii Safety symbols .......................... vii Chapter 1 Introduction ......................9 Hughes mobile satellite terminals ......................9 Below Deck Unit (BDU) ......................... 10 Physical dimensions ..........................10 Power port ............................11 Table 2. Power port pin out ........................ 11 Four RJ-45 Ethernet with Power over Ethernet (PoE) ports ..............
  • Page 5 Figures Figure 1-1. BDU (left) and ADU (right) Maritime antenna ..............9 Figure 1-2. Below Decks Unit (BDU) ....................10 Figure 1-3. Fitting the SIM card Cover ....................12 Figure 2-1. BDU - mounting dimensions in mm................... 16 Figure 2-2 BDU Wiring Diagram ......................16 Figure 3-1.
  • Page 7: Understanding Safety Alert Messages

    Understanding safety alert messages Safety alert messages call attention to potential safety hazards and tell you how to avoid them. These messages are identified by the signal words WARNING or CAUTION, as illustrated below. To avoid possible property damage, personal injury, or in some cases possible death, read and comply with all safety alert messages.
  • Page 9: Chapter 1 Introduction

    Hughes mobile satellite terminals The mobile satellite terminals are composed of four core component parts: the transceiver or Below Deck Unit (BDU), the antenna or Above Deck Unit (ADU), the power connector/cable, and a 25 meter RF cable.
  • Page 10: Below Deck Unit (Bdu)

    The Thuraya Mobility (Maritime) kit is shipped with the following contents: Model Hughes part Description number Thuraya Orion IP (9105) 3500462-0004 Radio, Thuraya Orion IP (kit) Maritime kit 9506197-0001 WLAN antenna (2.4 GHz, 3 dB) 3500472-0003 Power cable with 3-pin connector 3500860-0001...
  • Page 11: Power Port

    Power port The power port is the connection from the power supply (vessel battery or some other 12 or 24Vdc power source) to the BDU. The power cable has a DC positive power line, a Remote Switch line and a DC negative power line. Line type Pin number V+ DC power line...
  • Page 12: Wlan Port

    WLAN port The WLAN port on the BDU is a reverse polarity SMA jack. A flexible antenna with RP-SMA plug connector is supplied, part number HG2403RD-RSF. To prevent blocking or attenuation of the WLAN signal, the BDU should be installed such that there is no metal blocking the radio path to the user’s device.
  • Page 13: System Power Requirements

    System power requirements There is one power connection on the BDU. This must be connected to a 12 or 24Vdc supply. Power requirements and consumption are as follows: Voltage Input Minimum Voltage Input Maximum Total Current for ADU and BDU (Max.
  • Page 15: Chapter 2 Below Deck Unit (Bdu) Install

    Chapter 2 Below Deck Unit (BDU) Install The BDU is generally located in an area accessible by the operator and protected from water/spray. The ADU is generally located in a position to give clear line of sight to the satellite and to avoid exposure of microwave radiation to personnel. Basic BDU installation procedure The basic installation procedure is as follows:...
  • Page 16: Bdu Mounting Information

    Use screws or bolts with a diameter between 3.5 to 4mm. Vibration- resistant screws or lock washers should be used. Dimension BETWEEN Mounting Holes: 271mm Figure 2-1. BDU - mounting dimensions in mm. Thuraya Orion IP BDU Chassis Gnd Point RSI = Remote Switch Input...
  • Page 17: Chapter 3 Above Deck Unit (Adu) Install

    Antenna cable lengths and types The Hughes BDU has an automatic cable calibration feature that determines the loss of the cable. The RF cable that comes standard in the terminal kit is 25 meters long. If a different cable is required for the installation, the end-to-end RF loss needs to be 10dB +0dB/-8dB at 1.6GHz and the cable must be 50 Ohm impedance.
  • Page 18: Antenna Location

    Antenna Location It is important for the operation and life of the Antenna and safety of personnel that the location / mounting / fitting instructions are followed – improper installation will void any warranty. Mounting Location:  Line-of-Sight: when locating the antenna, it is very important to ensure there is a clear line-of-sight to the satellite for all the satellite elevation angles in the region in which the ship will operate.
  • Page 19 Antenna Location – minimum distance from RADAR (X-Band) in istance Radar Min Distance at 6 Power vertical separation vertical separation Output 0-10kW 0.8 m (2.6 ft.) 0.4 m (1.3 ft.) 30kW 2.4 m (7.9 ft.) 1.2 m (3.9 ft) 50kW 2.0 m (6.6 ft) 2.0 m (6.6 ft) NAVIGATIONA AIDS: see the table below for suggested co-location minimum...
  • Page 20  The Above Deck Unit (ADU) Revision 1...
  • Page 21: Antenna Mounting

    Antenna Mounting Pedestal/Pole Mounting / Fitting Instructions: See the figure below for the installation of the Thuraya Maritime HN321 antenna on a pedestal. Connect the N-connector on the coax cable as shown before fastening the antenna to the pole mount. Do not obstruct the drain holes at the bottom of the antenna (around the N-connector) and at the bottom of the pole mount.
  • Page 22 Alternate Mounting Hardware: It is recognized that for some installations Custom mounts/mounting brackets may be required. The following template is provided for the Antenna footprint. NOTE: the Antenna must be fitted to allow for natural water drainage – please see template information –...
  • Page 23: Antenna Vibration

    Antenna Vibration The antenna is designed to meet the following operational vibration levels in any of three perpendicular directions measured at the mounting base of the radome i.e. at the flange of the mounting pole. Random Vibration: 1.05 grms with the following spectral density 5-2 Hz………….
