6.) Press and hold down the PROGRAM button for approximately 2 seconds or until the PROG
indicator in the display stops flashing. A flashing BLACKOUT indicator in the display confirms
that the controller is out of program mode.

3.2. Assign Joystick Reverse (PAN / TILT invert)

1.) Press and hold down the PROGRAM button for approximately 2 seconds or until the PROG
indicator in the display flashes. Once the indicator is flashing, record mode is engaged and
you may release the Program mode.
2.) Press and hold down the MODE button and then tap the Fine button. The Assign and Pan
LEDs illuminate.
3.) Once again, press and hold down the MODE button and then tap the FINE button. The
REVERSE LED should illuminate.
4.) Select the fixtures that you wish to assign the PAN reverse and TILT reverse for by pressing
the FIXTURES buttons 1-12, so the selected fixture LEDs illuminate. Ideally, you should
assign opposite fixtures for PAN / TILT reverse. For example, fixtures 1,3,5,7,...should be
assigned normal as describes in the previous section and fixtures 2,4,6,..., should be
assigned reversed so that when moving the joystick around, fixtures movements are reversed
from one another. This feature is normally referred to as PAN/TILT invert.
5.) Press the TAP / DISP button to switch between PL.XX, PH.XX. PL.XX represents the low
byte or fine channel, generally listed as the PAN fine channel and PH.XX represents the high
byte or coarse channel, generally listed as the PAN fine channel. Set it to PH.XX and press
and hold down the MODE button and then tap the SCENE button that corresponds to the
PAN channel of your fixture. For example if your fixtures PAN channel is 1 then you did press
the SCENE 1 button. Please refer to the fixtures DMX chart. If your fixture includes a PAN
fine channel, press the TAP / DISP button so the display reads PL.XX. Press and hold down
the MODE button and then tap the SCENE button that corresponds to the PAN fine channel
of your fixture. For example, if your fixtures PAN fine channel is 2 then you'd press the
SCENE 2 button.
6.) Press the BANK UP or BANK DOWN buttons to switch between TL:XX and TH.XX. TL:XX
represents the low byte or fine channel, generally listed as the TILT fine channel and TH.XX
represents the high byte or coarse channel, generally listed as the TILT channel. Set it to
TH.XX and press and hold down the MODE button and then tap the SCENE button that
corresponds to the TILT channel of your fixture. For example, if your fixtures TILT channel is
3 then you did press the SCENE 3 button. Please refer to the fixtures DMX chart. If your
fixture includes a TILT fine channel press the Tap / Disp button so the display reads TL.XX.
Press and hold down the MODE button and then tap the SCENE button that corresponds to
the TILT fine channel of your fixture. For example, if your fixtures PAN fine channel is 2 then
you did press the SCENE 4 button.
