5. Scenes

5.1. Recording scenes

1.) Press and hold down the Program button for approximately 2 seconds or until the PROG
indicator in the display flashes. Once the indicator is flashing, record mode is engaged and
you may release the Program button.
2.) Select the fixtures that you wish to include into your scene by pressing the FIXTURES
buttons 1-12. So the selected fixture LEDs illuminate.
3.) Set your scene by using the eight CHANNEL faders, joystick and PAGE SELECT button if
needed. The PAGE SELECT button should be used to switch between channel 1-8 and 9-16.
4.) Once you are satisfied with the look of your scene, press the MIDI / REC button to record it.
5.) Use the BANK UP / DOWN buttons to select a scene bank to store to. There are 30 available
scene banks and you can view them in the display by referring to the furthest two digits to the
right.
6.) Press a SCENE button 1-8, to store to. Once pressed, all LEDs will flash indicating that your
scene was stored. There are 8 SCENE buttons to store for each bank. Make sure you
selected a different scene button each time you store a scene so you do not record over
something that you wanted to keep.
7.) To record additional scenes, repeat steps 2 to 6.
8.) Once you have stored all of your scenes, press and hold down the PROGRAM button for
approximately 2 seconds to exit. A flashing BLACKOUT indicator in the display indicative
that you are out of program mode.

5.2. Edit Scenes

1.) Press and hold down the PROGRAM button for approximately 2 seconds or until the PROG
indicator in the display flashes. Once the indicator is flashing, record mode is engaged and
you may release the PROGRAM button.
2.) Use the UP / DOWN Bank button to select the bank that contains the scene that you want to
edit. You can view the active bank in the display.
3.) Press the SCENE button 1-8, that you want to edit so the scene comes on.
4.) Select the fixtures or fixtures that you wish to change settings for in the current scene by
pressing the relevant FIXTURE buttons 1-12. The selected fixture LEDs should illuminate.
5.) Make your changes by using the faders or joystick.
6.) Press the MIDI / REC button and then press the SCENE button that you are editing. ALL
LEDs will flash three times to confirm that your new settings were saved.
7.) Press and hold down the PROGRAM button for approximately 2 seconds to exit. A flashing
BLACKOUT indicator, in the display, is indicative that you are out of program mode.
