CHAP. 1 PARTS LIST, MATERIALS AND TOOLS LIST

1.1 Warning

DO NOT EXPOSE THE MODEL TO HIGH TEMPERATURES. Exposing the model (or its parts) to high temper-
°
atures, over 50
C (example: in a car parked directly in the sun) may deform structures and make it unus-
able.

1.2 Components included in the kit

COD.
QT.
FUSO
1
fuselage
CONO
1
front cone
ADXL
1
right wing-panel
ASXL
1
left wing-panel
CODX
1
V left tailplane
COSX
1
V right tailplane
BAIO
1
wing rod
BASE
1
servos mounting frame
CARB
2
elevator pushrod
TCA4
1
spacer for pushrods
AMR2
8
metal pushrod
UNIB
2
Nylon uniball
VITE
2
screw
GIUN
2
ball for uniball
FOR2
6
clevis
DAD2
6
nut
MPXF
2
MPX connector female
MPXM
2
MPX connector male
CAVS
1
wing servo cable
CARS
2
servo hole cover
BOCC
4
threaded bush
PERN
4
threaded horn
Item
fiberglass, carbon reinforced (optional, all carbon fiber)
fiberglass (optional, all carbon fiber)
fiberglass, carbon reinforced with aileron and flap (optional,
all carbon fiber)
fiberglass, carbon reinforced with aileron and flap (optional,
all carbon fiber)
balsa fiberglass sandwich with carbon spar
balsa fiberglass sandwich with carbon spar
steel ~175 / ~ 235 mm - Ø 10 mm
ply-wood
carbon tube - length 100 cm - Ø 6 mm - hole Ø 4 mm
carbon tube - length 20 cm - Ø 4 mm - hole Ø 2 mm
length 30 cm - one tip M2 thread
M2 thread
length 20 mm - M2 thread
M2 thread
M2 thread
M2 thread
plastic - 6 pin
plastic - 6 pin
twisted - three wires, length 2 m
2 pair supplied to suit 4 holes
brass threaded M3
brass threaded M3
Nuova FULCRO Service
Remarks
3
