MODEL G0529
OSCILLATING SPINDLE &
12" DISC SANDER
OWNER'S MANUAL
(For models manufactured since 04/17)
COPYRIGHT © SEPTEMBER, 2003 BY GRIZZLY INDUSTRIAL, INC. REVISED AUGUST, 2017 (JH)
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
#JT5422 PRINTED IN TAIWAN

Advertisement

Table of Contents
loading

Related Manuals for Grizzly G0529

Summary of Contents for Grizzly G0529

  • Page 1 OWNER'S MANUAL (For models manufactured since 04/17) COPYRIGHT © SEPTEMBER, 2003 BY GRIZZLY INDUSTRIAL, INC. REVISED AUGUST, 2017 (JH) WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
  • Page 2 This manual provides critical safety instructions on the proper setup, operation, maintenance, and service of this machine/tool. Save this document, refer to it often, and use it to instruct other operators. Failure to read, understand and follow the instructions in this manual may result in fire or serious personal injury—including amputation, electrocution, or death.

  • Page 3: Table Of Contents

    Table of Contents INTRODUCTION ..........2 SECTION 4: OPERATIONS ......20 Contact Info............ 2 Operation Overview ........20 Manual Accuracy ........... 2 Power Switch ..........20 Identification ........... 3 Spindle Sanding ........... 21 Machine Data Sheet ........4 Disc Sanding ..........22 Miter Sanding ..........

  • Page 4: Introduction

    ID label (see below). This information is required for us to provide proper tech support, and it helps us determine if updated documenta- tion is available for your machine. Manufacture Date Serial Number Model G0529 (Mfd. Since 04/17)

  • Page 5: Identification

    An important part of safety is knowing your machine and its components. Take the time to familiarize yourself with the features of your new G0529 Oscillating Spindle & 12" Disc Sander. They will be fre- quently mentioned throughout the instructions in this manual.

  • Page 6: Machine Data Sheet

    MACHINE DATA SHEET Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901 MODEL G0529 OSCILLATING SPINDLE / 12" DISC SANDER Product Dimensions: Weight................................166 lbs. Width (side-to-side) x Depth (front-to-back) x Height................32 x 18 x 47 in.
  • Page 7 The information contained herein is deemed accurate as of 8/7/2017 and represents our most recent product specifications. Model G0529 PAGE 2 OF 2 Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. Model G0529 (Mfd. Since 04/17)

  • Page 8: Section 1: Safety

    Everyday ery. Never operate under the influence of drugs or eyeglasses are NOT approved safety glasses. alcohol, when tired, or when distracted. Model G0529 (Mfd. Since 04/17)
  • Page 9 EXPERIENCING DIFFICULTIES. If at any time debris. Make sure they are properly installed, you experience difficulties performing the intend- undamaged, and working correctly BEFORE ed operation, stop using the machine! Contact our operating machine. Technical Support at (570) 546-9663. Model G0529 (Mfd. Since 04/17)

  • Page 10: Additional Safety For Combo Sanders

    Never operate without adequate dust collection system in place and running. some type of jig is used to maintain support and However, dust collection is not a substitute for control when sanding force is applied. using a respirator. Model G0529 (Mfd. Since 04/17)

  • Page 11: Section 2: Power Supply

    Model G0529 (Mfd. Since 04/17)

  • Page 12: Extension Cords

    Two-prong outlets do not meet the grounding requirements for this machine. Do not modify or use an adapter on the plug provided—if it will not fit the outlet, have a qualified electrician install the proper outlet with a verified ground. -10- Model G0529 (Mfd. Since 04/17)

  • Page 13: Section 3: Set Up

    Inventory Box 1 (Figure 3) The Model G0529 Oscillating Spindle & 12" Disc A. Sander Unit......1 Sander was carefully packed at the factory.

  • Page 14: Hardware Recognition Chart

    Hardware Recognition Chart -12- Model G0529 (Mfd. Since 04/17)

  • Page 15: Cleanup

    Lighting around the machine must be adequate damage painted surfaces. enough that operations can be performed safely. Shadows, glare, or strobe effects that may distract or impede the operator must be eliminated. Model G0529 (Mfd. Since 04/17) -13-...

  • Page 16: Beginning Assembly

    Beginning Assembly Cabinet Assembly The machine must be fully assembled before it The Model G0529 Sander mounts on a sturdy can be operated. Before beginning the assembly cabinet stand. process, refer to Needed for Setup and gather all listed items. To ensure the assembly process...

  • Page 17: Mounting Sander

    To mount the sander to the top of the cabinet Select the proper diameter of spindle sleeve. stand: The Model G0529 comes with the following four sizes of spindle sleeves: With the help of an assistant, place the sander on the cabinet stand.

  • Page 18: Squaring Table

    DISCONNECT MACHINE FROM POWER! diameter spindle you are using. Set the table at 90˚, as shown in Figure 9. The Model G0529 comes with the following four table inserts: • 2" • 1"...

  • Page 19: Squaring Disc Sander

    Tighten the lock lever while holding the table disc sander have tilting capabilities from 0˚ to perpendicular. 45˚. Adjust the scale pointer to read 0˚ when the To tilt the sanding table: table has been properly adjusted. DISCONNECT MACHINE FROM POWER! Model G0529 (Mfd. Since 04/17) -17-...

  • Page 20: Sanding Disc

    Rotate the disc so the lower half is above the table. Peel off the remaining half of the pro- tective paper and press sandpaper against disc. Figure 13. Example of installing PSA sanding disc. -18- Model G0529 (Mfd. Since 04/17)

  • Page 21: Miter Gauge

    Note: Sometimes the tightening procedure can affect the adjustment. Loosen the set screw that secures the angle pointer and adjust the pointer to the 0˚ mark on the scale. Retighten the set screw that secures the angle pointer. Model G0529 (Mfd. Since 04/17) -19-...

  • Page 22: Section 4: Operations

    Operation Overview Power Switch The purpose of this overview is to provide the nov- The Model G0529 sander is equipped with a ice machine operator with a basic understanding paddle-type power switch with a safety key. of how the machine is used during operation, so...

  • Page 23: Spindle Sanding

    Spindle Sanding Never use the Model G0529 for applica- tions other than those for which it was The oscillating spindle sander on the Model made. DO NOT overload the machine or G0529 produces an extremely fine sanding finish use excess force when sanding. Severe on edges or contours.

  • Page 24: Disc Sanding

    This will keep the workpiece from flying out of your hands from the rotational forces. Figure 19. Disc sanding with miter. Figure 18. Disc sanding with table tilted. -22- Model G0529 (Mfd. Since 04/17)

  • Page 25: Section 5: Accessories

    To reduce this risk, only install accessories H6663 ⁄ " x 5 ⁄ " H6664 ⁄ " x 5 ⁄ " recommended for this machine by Grizzly. H6665 ⁄ " x 5 ⁄ " H6666 ⁄ " x 5 ⁄ "...

  • Page 26: Section 6: Maintenance

    To reduce risk of shock or accidental startup, always disconnect machine from power before adjustments, Cleaning the Model G0529 is relatively easy. maintenance, or service. Vacuum excess wood chips and sawdust, and wipe off the remaining dust with a dry cloth. If any...

  • Page 27: Section 7: Service

    1. Too much pressure against sleeve/disc. 1. Reduce pressure on workpiece while sanding. clogs quickly 2. Sanding softwood. 2. Use different stock. Or, accept characteristics of the burns. and plan on cleaning/replacing sleeves frequently. Model G0529 (Mfd. Since 04/17) -25-...
  • Page 28 1. Not supporting workpiece against stable. 1. Use table to support workpiece. ly gets pulled out of 2. Starting the workpiece on a leading corner. 2. Start workpiece on a trailing corner. your hand. -26- Model G0529 (Mfd. Since 04/17)

  • Page 29: Section 8: Wiring

    Technical Support at (570) 546-9663. The photos and diagrams included in this section are best viewed in color. You can view these pages in color at www.grizzly.com. Model G0529 (Mfd. Since 04/17) -27-...

  • Page 30: Wiring Diagram

    Capacitor 45MFD 250VAC Start Capacitor 300MFD 125VAC The motor wiring shown here is current at the time of printing, but it match your machine. Always use the wiring diagram inside the motor junction box. -28- Model G0529 (Mfd. Since 04/17)

  • Page 31: Section 9: Parts

    SECTION 9: PARTS We do our best to stock replacement parts when possible, but we cannot guarantee that all parts shown are available for purchase. Call (800) 523-4777 or visit www.grizzly.com/parts to check for availability. Frame Breakdown 97 98 38 37...

  • Page 32: Main Parts List

    SIDE COVER P0529103 PHLP HD SCR M5-.8 X 25 P0529042 FRONT AND REAR COVER P0529104 FLAT WASHER 1/4 P0529043 SPACER 106V2 P0529106V2 CAP SCREW 5/16-18 X 3/8 V2.08.17 P0529044 ARBOR 5/8 P0529107 LOCK WASHER 5/16 -30- Model G0529 (Mfd. Since 04/17)
  • Page 33 PHLP HD SCR 10-24 X 3/8 P0529141 WARNING LABEL-DISCONNECT P0529118 HEX NUT M6-1 P0529144 HEX WRENCH 4MM P0529119 HEX BOLT 5/16-18 X 3 P0529145 HEX WRENCH 5MM P0529121 HEX BOLT 1/4-20 X 1/2 P0529146 HEX WRENCH 6MM Model G0529 (Mfd. Since 04/17) -31-...

  • Page 34: Cabinet Breakdown

    MACHINE ID LABEL P0529106 CAP SCREW 5/16-18 X 3/4 P0529143 GRIZZLY LOGO P0529108 FLAT WASHER 5/16 P0529147 HEX BOLT 5/16-18 X 3/4 P0529125 RIGHT OR LEFT PANEL P0529148 CAP SCREW 5/16-18 X 3/8 -32- -32- Model G0529 (Mfd. Since 04/17)
  • Page 35 Would you recommend Grizzly Industrial to a friend? _____ Yes _____No Would you allow us to use your name as a reference for Grizzly customers in your area? Note: We never use names more than 3 times. _____ Yes _____No 10.
  • Page 36 FOLD ALONG DOTTED LINE Place Stamp Here GRIZZLY INDUSTRIAL, INC. P.O. BOX 2069 BELLINGHAM, WA 98227-2069 FOLD ALONG DOTTED LINE Send a Grizzly Catalog to a friend: Name_______________________________ Street_______________________________ City______________State______Zip______ TAPE ALONG EDGES--PLEASE DO NOT STAPLE...

  • Page 37: Warranty & Returns

    WARRANTY & RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance.
