EtherWAN EX3101 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Preface

This manual describes how to install and use the Ethernet Extender. The
Ethernet Extender introduced here provides one channel for Ethernet over
VDSL.
The Ethernet Extender fully complies with IEEE 802.3 10BaseT and IEEE
802.3u 100BaseTX standards.
In this manual, you will find:
Product overview
F
EATURES ON THE
Illustrative LED functions
Installation instructions
Specifications
User's Manual
E
E
THERNET
XTENDER
Ethernet Extender
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EX3101 and is the answer not in the manual?

Questions and answers

Related Manuals for EtherWAN EX3101

Summary of Contents for EtherWAN EX3101

  • Page 1: Preface

    Ethernet Extender Preface This manual describes how to install and use the Ethernet Extender. The Ethernet Extender introduced here provides one channel for Ethernet over VDSL. The Ethernet Extender fully complies with IEEE 802.3 10BaseT and IEEE 802.3u 100BaseTX standards. In this manual, you will find: Product overview EATURES ON THE...

  • Page 2: Table Of Contents

    Ethernet Extender Table of Contents ................1 REFACE ..............2 ABLE OF ONTENTS ...............3 NTRODUCTION ............3 RODUCT VERVIEW ............3 RODUCT EATURES ..............3 ACKING ........4 HANNEL THERNET XTENDER ................4 ORTS VDSL M ............4 ETTINGS & LED ............4 RONT ANEL ................6 NSTALLATION ......6 ELECTING A ITE FOR THE QUIPMENT .............6...

  • Page 3: Introduction

    Ethernet Extender Introduction The Ethernet Extender provides one channel for Ethernet over VDSL. It can be used as a stand-alone device or with a standard 19” chassis. Product Overview Product Features One 10/100BaseTX (TX) Ethernet port with RJ-45 connector Auto negotiation of speed and duplex mode on TX port Auto MDIX on TX port Complies with IEEE 802.3 10BaseT and IEEE 802.3u 100BaseTX standards...

  • Page 4: One-Channel Ethernet Extender

    Ethernet Extender One-Channel Ethernet Extender Ports The Ethernet Extender provides one TX port and one VDSL port. For the TX port, it uses RJ-45 connector and auto senses the speed of 10/100Mbps. For the VDSL port, it uses RJ-11 connector and auto senses the speed of 1/3/5/10/15/20/25/30Mbps.
  • Page 5 Ethernet Extender LEDs State Indication Steady Power on POWER WR STANDS FOR Power off Ethernet Lnk/Act Steady A valid Ethernet connection established Lnk stands for LINK Flashing Transmitting or receiving Ethernet data Act stands for ACTIVITY Neither valid Ethernet connection established transmitting/receiving Ethernet data Steady...

  • Page 6: Installation

    Ethernet Extender Installation This chapter gives step-by-step installation instructions for the Ethernet Extender. Selecting a Site for the Equipment As with any electric device, you should place the equipment where it will not be subjected to extreme temperatures, humidity, or electromagnetic interference.

  • Page 7: Installing In A Chassis

    Ethernet Extender Installing in a Chassis The Ethernet Extender can be fit into any of the expansion slots on a special designed chassis. First, install the Ethernet Extender onto a carrier supplied with the chassis: Step 1- Unscrew the carrier from the desired expansion slot on the chassis. Step 2- Fit the Ethernet Extender onto the carrier.

  • Page 8: Use Panel Mount Kit

    Ethernet Extender When the Ethernet Extender is completely seated onto the carrier, insert the carrier to the guide rails of the expansion slot. Carefully slide in the carrier until it is fully and firmly fit the chassis. Fasten the screws onto the carrier. <NOTE>...
  • Page 9 Ethernet Extender Step 1- Loosen the screws by the side of the unit. Step 2- Fit the panel mount kit onto the unit and fasten the screws. User’s Manual...

  • Page 10: Specifications

    Ethernet Extender Specifications Applicable Standards IEEE 802.3 10BaseT IEEE 802.3u 100BaseTX VDSL THERNET OVER Fixed Ports 1 x 10/100Mbps Ethernet port with RJ-45 connector 1 x Ethernet over VDSL port with RJ-11 connector Speed 10BaseT 10/20Mbps for half/full-duplex 100BaseTX 100/200Mbps for half/full-duplex VDSL 1, 3, 5, 10, 15, 20, 25, 30M THERNET OVER...
