USCutter SC2 User Manual & Assembly Instructions page 11

USB CABLE PORT
SERIAL (COM) CABLE PORT
POWER SWITCH
POWER CABLE PORT
FUSE CARTRIDGE
CARRIAGE SLOT
LOCKING KNOB
RIGHT SIDE VIEW
USB CABLE PORT
SERIAL (COM)
CABLE PORT
LEFT SIDE VIEW
POWER CABLE
PORT
POWER SWITCH
FUSE CARTRIDGE
CARRIAGE SLOT
LOCKING KNOB
