Porter-Cable CPLC7060V Instruction Manual

Porter-Cable CPLC7060V Instruction Manual

Single-stage oillube compressor
Hide thumbs Also See for CPLC7060V:

Advertisement

Instruction
manual
MODEL
CPLC7060V
To learn more about Porter-Cable
visit our website at:
http://www.porter-cable.com
PROFESSIONAL POWER TOOLS
Copyright © 2000 PORTER-CABLE Corporation
ESPAÑOL: PÁGINA 27
FRANÇAIS: PAGE 53
Single-Stage Oillube
Compressor
IMPORTANT
Please make certain that the person who is to use
this equipment carefully reads and understands
these instructions before starting operations.
The Model and Serial No. plate is located on the
frame. Record these numbers in the spaces below
and retain for future reference.
Model No.
Type
Serial No.
Part No.
D20324-011-2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CPLC7060V and is the answer not in the manual?

Questions and answers

Summary of Contents for Porter-Cable CPLC7060V

  • Page 1: Instruction Manual

    Instruction manual MODEL CPLC7060V To learn more about Porter-Cable visit our website at: http://www.porter-cable.com PROFESSIONAL POWER TOOLS Copyright © 2000 PORTER-CABLE Corporation ESPAÑOL: PÁGINA 27 FRANÇAIS: PAGE 53 Single-Stage Oillube Compressor IMPORTANT Please make certain that the person who is to use this equipment carefully reads and understands these instructions before starting operations.
  • Page 2: Read And Follow All Instructions

    NOT be modified and/or used for any application other than for which it was designed. If you have any questions relative to its application, DO NOT use the tool until you have written Porter-Cable and we have advised you. CAUTION indicates a potentially...
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS (cont’d) SAVE THESE INSTRUCTIONS IMPROPER OPERATION OR MAINTENANCE OF THIS PRODUCT COULD RESULT IN SERIOUS INJURY AND PROPERTY DAMAGE. READ AND UNDERSTAND ALL WARNINGS AND OPERATING INSTRUCTIONS BEFORE USING THIS EQUIPMENT. RISK OF EXPLOSION OR FIRE WHAT CAN HAPPEN IT IS NORMAL FOR ELECTRICAL CONTACTS WITHIN THE MOTOR AND PRESSURE SWITCH TO SPARK.
  • Page 4 SOLVENTS, PAINT REMOVER, INSECTICIDES, WEED KILLERS, CONTAIN HARMFUL VAPORS AND POISONS. RISK OF ELECTRICAL SHOCK WHAT CAN HAPPEN YOUR AIR COMPRESSOR IS POWERED BY ELECTRICITY. LIKE ANY OTHER ELECTRICALLY POWERED DEVICE, IF IT IS NOT USED PROPERLY IT MAY CAUSE ELECTRIC SHOCK. REPAIRS...
  • Page 5 IMPORTANT SAFETY INSTRUCTIONS (cont’d) RISK FROM MOVING PARTS WHAT CAN HAPPEN MOVING PARTS SUCH AS THE PULLEY, FLYWHEEL, AND BELT CAN CAUSE SERIOUS INJURY IF THEY COME INTO CONTACT WITH YOU OR YOUR CLOTHING. ATTEMPTING TO OPERATE COMPRESSOR WITH DAMAGED OR MISSING PARTS OR ATTEMPTING TO REPAIR COMPRESSOR WITH PROTECTIVE SHROUDS REMOVED CAN EXPOSE YOU TO MOVING PARTS AND CAN RESULT IN SERIOUS...
  • Page 6: Specifications

    DUTY CYCLE Porter-Cable air compressors should be operated on not more than a 50% duty cycle. This means an air compressor that pumps air more than 50% of one hour is considered misuse, because the air compressor is undersized for the required air demand.
  • Page 7: Description Of Operation

    Check Valve (not shown): When the air compressor is operating, the check valve is "open", allowing compressed air to enter the air tank. When the air compressor reaches "cut-out" pressure, the check valve "closes", allowing air pressure to remain inside the air tank.
  • Page 8: Installation

    Closely follow instructions packaged with the filter for proper installation. It must be installed as close as possible to the accessory. The air compressor should be as near to air outlets as possible in order to avoid long pipe lines. Do not place the air compressor where heat is excessive.
  • Page 9 Install the air compressor unit as close to the main power supply as possible. This practice will avoid using long lengths of electrical wiring for the power supply which can cause power loss to the motor.
  • Page 10: Voltage And Circuit Protection

    Make certain that the electrical circuit to which the air compressor is connected provides proper electrical grounding, correct voltage and adequate fuse protection. The air compressor can be grounded by the following method: When hard wiring an air compressor, use wiring that contains a bare copper grounding wire.
  • Page 11: Additional Regulators And Controls

    To remove dirt, oil, and water, install a separator in the main distribution line. Install separator 5 to 6 feet from air compressor to allow the air to cool to room temperature before passing through the separator. Additional separators or filters may be used depending on the application.
  • Page 12 Compressed air dryers reduce the water vapor concentration and prevent water formation in compressed air lines. Dryers are a necessary companion to filters, aftercoolers, and automatic drains for improving the productivity of compressed air systems. Water and water vapor removal increases the efficiency of air operated equipment, reduces contamination and rusting, increases the service life of pneumatic equipment and tools, prevents air line freeze-ups, and reduces product rejects.
  • Page 13: Break-In Procedures

    4. Move the pressure switch lever to "ON/AUTO". The compressor will start. 5. Run the air compressor for 30 minutes. Make sure the drain valve is open and there is minimal air pressure build-up in tank.
  • Page 14: Routine Maintenance Schedule

    12.After the water has been drained, close the drain valve. if the air compressor is under continuous use, drain at least once each day. if the air compressor is only used occasionally, drain after each use. If drain cock valve is clogged, release air pressure in air tank. The drain cock valve can then be removed, cleaned and reinstalled.
  • Page 15: Air Filter - Inspection And Replacement

    A dirty air filter will not allow the air compressor to operate at full capacity. Before you use the air compressor, check the air filter to be sure it is clean. If it is dirty, replace it with a new filter.
  • Page 16 MUST BE REPLACED WITH A VALVE HAVING THE SAME PRESSURE RATING. 1. Remove and lock out power from the air compressor. Release any air pressure from the air tank. 2. Remove safety valve and replace with valve of the same pressure rating.
  • Page 17 The belt must be centered over the grooves on the flywheel and motor pulley. 4. To reinstall beltguard, align the bottom tabs of the beltguard into the slots of the base. These are located behind the ON/OFF switch. Replace beltguard screws and tighten securely.
  • Page 18: Servicing Intake And Exhaust Valves

    2. Remove beltguard. 3. Place a straight edge (such as a ruler) against the outside of the flywheel and measure the distance from it to the nearest groove. Alignment is achieved when the other end of the straight edge is within 1/32” of the measured dimension at the pulley grooves.
  • Page 19 8. Protect the electrical cord and/or air hose from damage (such as being stepped on or run over). 9. Store the air compressor in a clean and dry location. Note 19-ENG...
  • Page 20: Troubleshooting Guide

    TROUBLESHOOTING GUIDE PERFORMING REPAIRS MAY EXPOSE VOLTAGE SOURCES, MOVING PARTS OR COMPRESSED AIR SOURCES. PERSONAL INJURY MAY OCCUR. PRIOR TO ATTEMPTING ANY REPAIRS, UNPLUG THE AIR COMPRESSOR AND BLEED OFF ALL AIR TANK AIR PRESSURE. PROBLEM CAUSE Excessive air tank...
  • Page 21 Contact Service Center for inspection or replacement if necessary. Have checked by a Service Center. Do not operate the air compressor in the spray area. See Flammable Vapor Warning. Have checked by a local Service Center. 1. Check fuse box for blown fuse and replace if necessary.
  • Page 22 Decrease amount of air usage. Check the accessory air requirement. If it is higher than the CFM or pressure supplied by your air compressor, you need a larger air compressor. Clean or replace air intake filter. Do not operate the air compressor in the paint spray area.
  • Page 23 Improper wiring gauge. Incorrect voltage. Current style electric motors run relatively hot under normal operating conditions, with reasonable air compressor loading. This condition is normal and no adjustment is necessary. Under normal operating conditions, the motor amperage draw will not exceed the nameplate amperage rating, plus the service factor, as it appears on the electric motor.
  • Page 24: Plumbing Components

    ACCESSORIES Accessories can be found at the store from which the unit was purchased or at a local hardware store. FILTERS, REGULATORS, LUBRICATORS FILTER / REGULATOR Regulates air pressure and removes moisture, oil and other debris from the air line. Protects tools from rust and is essential when spray painting.
  • Page 25 NOTES 25-ENG...
  • Page 26: Limited Warranty

    90 Day – Service parts Engine warranties are the responsibility of the engine manufacturer. Warranties of merchandise sold by Porter-Cable which has been manufactured by and identified as the product of another company are the responsibility of the manufacturer of that product.
