Visual Indicators - Altronix WayPoint10A Installation Manual

Fig. 4
WARNING: When installing in a non-restricted service area use lock or other fastened means on door
latches. This installation should be made by qualified service personnel and should conform to the National
Electrical Code and all local codes.
Terminal and LED Identification Chart:
Output
LED
Terminals
COM & 24V 24VAC
COM & 28V 28VAC
The lightning flash with arrow head symbol within an equilateral triangle is intended to alert the user to the
presence of an insulated DANGEROUS VOLTAGE within the product's enclosure that may be of sufficient
magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- 6 -
Suggested Locations
for Wiring Inlets
Bottom of Enclosure
ON
Normal operating condition.
CAUTION: To reduce the risk of electric shock do not open enclosure. There are
no user serviceable parts inside. Refer servicing to qualified service personnel.
LED Status
No AC output. Blown fuse, illuminated master power
disconnect circuit breaker is tripped or OFF, AC failure.
OFF
AC Outdoor
