Plug the other end into the slot
3.
under the SoundStation2 Console
as illustrated. Then thread the
cable through the channels on the
underside of the console as shown
at right.
Plug the Power Adapter Cable
4.
into the Interface Module jack
marked
Adapter into the electrical outlet.
► The first time the SoundStation2
Avaya is powered up and con-
nected to the network through the
Interface Module, it will run a brief
self-test and synchronize itself
with your telephone network. Dur-
ing this time the LEDs will blink.
When the process is complete you
will hear a tone and the LEDs will
switch off. This process can take
20 seconds.
The SoundStation2 Avaya is designed
for greater room coverage with ex-
tended microphones.
► If using the optional extension
microphones, connect to
SoundStation2 as shown at right.
Place the SoundStation2 Avaya on a
flat, stable surface in the center of the
room.
► If using the extended hypercar-
diod microphones, for the best
coverage, position as shown in
the example to the right.
Ready State
SoundStation2 Avaya will display a
Ready message upon power up and
completion of initialization.
The Ready message is also shown after a
call is completed and the phone is avail-
able for the next call.
then plug the Power
English
SoundStation2 Avaya User Guide - 8
German
MIC 4
MIC 2
READY
SP DIAL PH BOOK
BEREIT
MIC 1
MIC 3
5551212
REDIAL
5551212
MIC 5
