Troubleshooting LEDs

STS – Status LED
The green Status LED provides information regarding the state of the Gateway. This includes indication of
the various stages of the start-up routine (power-up), and any errors that may
Startup Routine
LED Indication
Rapidly Flashing Gateway is currently loading program
Steady Gateway is operating normally
3.2.2 – Serial Host Ports – TX/RX/LEDs
LED Indication
Green Transmitting
Red Receiving
3.2.3 – TCP/IP Ethernet Port LEDs
LED Indication
Yellow (Solid) Link Established
Yellow (Flashing) Network Activity
Green 10 BASE-T Communications
Amber 100 BASE-T Communications
These LED's are the first step in troubleshooting communications issues. Please note the action of these
LED's, IN DETAIL, when contacting the Monico for technical support.
