VR-2 Help
# Feature
1 Front Handle Mount
2 CRMA Express
3 Optical Disk Drive
4 Smart Card Reader
or
EXPRESS Card Slot
5 PC Card Slot

Back Edge View

Hover the mouse over each number on the picture to see a description
# Feature
1 DC-in Jack
2 Network Jack (RJ45/LAN)
3 Two 2.0 USB Ports
4 Modem Jack (RJ11)
file://C:\Documents and Settings\harwoodm\Local Settings\Temp\~hh3F7F.htm
Description
The front soft handle mount, located on both sides of the unit, is used with the
optional soft handle
CRMA Express Radio bay
CD-RW, DVD/CD-RW, or DVD-RW/CD-RW
Smart Card Reader or EXPRESS Card
Use this slot for PC Card devices
Description
Connects to an AC adapter
Connects to an Ethernet-based network. Connection speed is 10/100/1000
Mbps
Connects to USB devices (e.g., USB digital camera)
Connects a phone line to the internal fax/data modem. It can transmit data
