VR-2 Help
6 Fingerprint
Scanner
7 Touchpad
8 Power Button
9 Application
Launch Button
10 Battery
11 Keyboard Task
Lights
12 Keyboard
72_0133_001
2007.03.19
© 2007 GD-Itronix Corporation. All rights reserved.

Top View

Hover the mouse over each number on the picture to see a description
# Feature
1 CRMA Express
Antenna
2 GPS Antenna
file://C:\Documents and Settings\harwoodm\Local Settings\Temp\~hh3F7F.htm
The optional swipe style fingerprint scanner can be used for all standard
security needs
Use for navigation
Turns computer on or off
Programmable button
Removable Lithium-Ion battery
Two task lights located in the display hinges directly below the display
illuminate the keyboard to permit typing in a dimly lit or darkened
environment.
Standard keyboard with embedded numeric keypad
Description
Antenna for WAN Communications
Antenna for GPS Receiver
Page 7 of 70
4/26/2007
