General Dynamics Itronix GoBook VR-2 Help Manual page 2

VR-2 Help
About Windows
The First Time. . .
Before using your computer, install the battery and then attach the computer to AC power.
Installing the Battery:
1. Line up the battery connectors.
2. Press gently on the battery until it clicks
into place.
3. Slide the battery locks toward the outside
of the computer to lock the battery and
ensure they latch completely.
Attaching AC Power:
1. Connect the AC adapter power cord to the AC
adapter.
2. Connect the AC adapter to the DC power port on
the back of your computer.
3. Connect the AC adapter power cord to a properly
grounded AC outlet.
NOTE It is recommended you use a quality
protector.
Begin Using the Computer
1. Open the display to a comfortable viewing angle.
2. Press the power switch to turn on the power.
The POST (power-on self-test) routine executes and Windows begins loading.
file://C:\Documents and Settings\harwoodm\Local Settings\Temp\~hh3F7F.htm
surge
Page 2 of 70
4/26/2007
