Dear buyer!
Thank you for purchasing Neoline X-COP R750 hidden installation hybrid. Be sure to read current guide carefully and
completely in order to use the device properly and extend its life. Keep the user guide and address it if you need it in
future.
Please note that this device has no service limitation in the Russian Federation and countries-members of the
Customs Union.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X-COP R750 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Neoline X-COP R750

Summary of Contents for Neoline X-COP R750

  • Page 1 Dear buyer! Thank you for purchasing Neoline X-COP R750 hidden installation hybrid. Be sure to read current guide carefully and completely in order to use the device properly and extend its life. Keep the user guide and address it if you need it in future.

  • Page 2: Table Of Contents

    [ Contents ] [ Service conditions ] ................. . . 4 [ Short description ] .
  • Page 3 [ Operation ] ..................30 Buttons.

  • Page 4: [ Service Conditions ]

    [ Service conditions ] • Study terms and conditions in the Warranty leaflet. • Install hybrid properly, in accordance with the user guide. Follow the rules to avoid accidents. • Use only the power cable included in the set. When charged with a third-party charger, even with similar PWC, efficiency can be violated.
  • Page 5 • Readouts shown by the radar detector unit may be inaccurate due to potential extraneous emissions. Powerful emission sources may cause the device instability. Such sources may include, among other things, the following: interior blind area sensors, automatic sliding door open sensors, mobile base stations, traffic sensors, additional interior electronic devices (including GPS modules, radar detector units, mobile phones etc.), high-voltage power transmission lines.
  • Page 6 Recharge the battery once in two months if you don’t use Х-СОР R750 for a long period of time. • Neoline Company shall not be liable for memory loss and/or damage, direct or indirect, caused to user or third party by incorrect device or software usage, incorrect installation, usage of non-included accessories.

  • Page 7: [ Short Description ]

    [ Short description ] Neoline X-COP R750 is intended to ensure your safety when driving. Most police radars and stations equipped with radar detection complexes are located on busy city roads and high-speed suburban highways with speed limits. Therefore, even if you do not know about this or the traffic sign is absent, you will always be warned to avoid violation of traffic rules.

  • Page 8: [ Special Characteristics ]

    Wireless connection of a dash camera to a radar detection unit hidden under the motor hood • External GPS antenna for vehicles with athermal or heated windscreens • Neoline Easy Touch Plus interface • Intuitive touchscreen control. • Ergonomic positioning in the cabin.

  • Page 9: Specifics Of Police Radar And Camera Gps Detecting

    • Quick access to main settings and functions from main screen. • Playing/locking/rewinding videos on device screen. • Software and GPS database updates through mobile app and MicroSD memory card Specifics of police radar and camera GPS detecting • Wireless radar detector unit mounted under hood. •...
  • Page 10 • Intellectual processing of Trip Track cameras. • On/Off for separate types of GPS spots: traffic control post police radar dummy Trip Track cameras Arrow radar, video block Arrow radar Fixed radars and cameras • Voice alerts about 45 types of fixed radars. •...

  • Page 11: Main Features Of Dash Camera

    • Add/Remove Dangerous and False zones. • Setting range for Dangerous and False zones. • 3 settings for GPS alert distance: by value in GPS database by value in settings by current speed • Detection range up to 2.5 km. •...
  • Page 12 • Parking mode. • Recording in Parking mode. • Volume adjusting (nine levels). • Cabin sound recording. • Charge indicator. • G-sensor and motion sensor. • X-COP Player to replay videos on PC. • Russian and English support, • Memory card support: MicroSD (SDHC U3: 2 Gb ~ 32 Gb, SDXC 64 Gb ~ 128 Gb), class 10*. •...

  • Page 13: [ Specifications ]

    [ Specifications ] Car Blackbox specifications • Processor : Ambarella A7LA55 • Resolution : 1920*1080 (real Full HD) / 1280*720(HD) • Image Sensor : IMX322LQJ (Sony) • Optical Lens : 57.4º(V) * 108.5º(H) * 129.7º(D), All glass • Display : 2.8 inch IPS LCD with full touch screen (240 * 320 resolution) •...

  • Page 14: Radar Specifications

    Radar specifications • Ultra-X and Ultra-K Band • X-Band (10.525GHz +/- 50MHz) • K-Band (24.150GHz +/- 100MHz) • KA-Band (34.70GHz +/- 1300MHz) • Laser Band (800nm ~ 1100nm) • Strelka detection with signal strength level indication (24.150 GHZ) GPS specifications •...

  • Page 15: Characteristics

    Characteristics • Input voltage : DC 11V ~ 28V • Remote Current consumption : 110mA ~ 130mA • DVR Current consumption : 220mA ~ 320mA • Dimension : 52(L) * 90(W) * 76.5(H) • Operating Temperature : -20°C ~ 70°C...

  • Page 16: [ Devices & Accessories ]

    [ Devices & Accessories ] X-COP R750 unit 2. Remote Radar unit Wind-shield mounting holder with suction-cup - Optional 4. Wind-shield mounting Power holder with 3M Tape Cigarette power cord (DC12V ~ 24V) 6. All times power cable (DC12V ~ 24V) External GPS antenna 8.
  • Page 17 The following items are included in the packaging.

  • Page 18: [ Installation ]

    [ Installation ]...

  • Page 19: Radar Detector Unit Installation

    If you do not have the skills required for installation of electrical equipment in a vehicle, please apply to a service center*. ATTENTION! Inoperability of this device caused by improper installation may lead to cancellation of Neoline X-COP R750 warranty obligations.
  • Page 20 ATTENTION! Do not install the radar detector unit behind metal surfaces (load-bearing car body elements, radiator, metal gauze etc.), because this may lead to bad reception of radio signals coming from police and laser radars. Installation behind plastic elements (inside the bumper, behind the aerodynamic cowl panels etc.) may also lead to deterioration of radar signal reception and impossibility to detect laser radars! It is recommended to install the radar detector unit under the hood, behind the radiator grille •...

  • Page 21: Mounting Spot On Windshield

    Note: to avoid damaging cable jacket, lay it away from overheated engine surfaces. Avoid cable kinks and step aside from moving engine elements. • Fix cable with clips and fasteners. Mounting spot on windshield • Position the device so that it is in the middle of windshield, slightly lower than rearview mirror, in order not to block the...
  • Page 22 Optional mounting spot on dashboard You can place the device directly on dashboard, rotating it by 180 degrees. You need to rotate the device first, and then turn it on. Thus, the image and all icons will be displayed correctly. You should use 3M tape to attach the device to dashboard.
  • Page 23 • Х-СОР R750 unit should be mounted in a way to allow the camera capture image in proportion “30% sky, 70% road”, to achieve better recordings. • Connect the power cord 12-24V to cigarette lighter socket and Smart Click Plus holder. Adjusting antiglare filter Antiglare filter (CPL) is designed to reduce sun glares on recorded image.

  • Page 24: Power Cable Installation

    Power cable installation Cigarette power cord The following installation of Cigarette power cord is recommended for the cable not to disturb driver’s vision. It is helpful to use the cord clips to fix the cable during installation.
  • Page 25 All times power cable • Connect the cable to the fuse box as like the following picture. • How to connect it to fuse box is as follows: Connect the BATT(+) terminal of the cable to the fuse for brake lamp in fuse box. Connect the ACC terminal of the cable to the fuse of Cigar Lighter in fuse box.
  • Page 26 Diagram for connecting power cable to car network (Neoline Fuse Cord 3 pin)

  • Page 27: External Gps Antenna Installation

    External GPS antenna installation Take external antenna from the kit. NOTE: before mounting the antenna choose a proper spot in your car and attach the antenna with a magnet or double-sided tape. Make sure that the top side (black plastic cover) is directed outwards and to the sky. ATTENTION! Do not mount the GPS antenna behind metallic surfaces –...
  • Page 28 3M tape. Connect antenna to dash camera using connection cable and special jack. ATTENTION! Installing Neoline X-COP R750 radar detector unit, dash camera and external GPS antenna, don’t forget that elements shouldn’t block visibility or become potential trauma source in case of accidents.

  • Page 30: [ Operation ]

    “Event” folder of SD card and the image resolution is 1920*1080 pixels. RESET Button X-COP R750 uses a battery so that there may be a case of system down unexpectedly. In this case, you can re-booting by pressing the RESET button and then pressing the power button for two...
  • Page 31 REC Button POWER Button RESET Button...

  • Page 32: Power On And Off

    Power On and Off X-COP R750 will power On when user starts car engine or presses the power button for two seconds and will show the following start-up image and then become a normal screen as follows. (LOGO display) (normal screen)
  • Page 33 X-COP R750 will power Off when user turns off the car engine or presses the power button for two seconds. When user does the power off by pressing Power button, the display will show LOGO and then be off.

  • Page 34: All Times Display(Normal Screen)

    All times display(Normal Screen) 1. Quick Icon Normal screen is composed for user to understand and operate easily. If user touchs this quick icon, 7 Icons are displayed as Please see the explanations about each icon on the shown below: screen as follows.
  • Page 35 a. Recording ON/OFF (Operation by touch) d. User location Addition/Deletion (Operation by touch) b. Audio recording ON/OFF (Operation by touch) User location Addition Touch this icon at the condition of no user location alert and pop up window with “Add User Area?” will be appeared.
  • Page 36 e. Silence zone Addition/Deletion (Operation by touch) f. City/Highway/Turbo/X-COP mode(operation by touch) Touch this icon and the mode will be changed by this order like Highway -> Turbo -> X-COP -> City. During mode change, each voice and icon are shown False zone —...
  • Page 37 This mode combines perfectly with long-range EXD • interior blind area sensors radio module built into X-COP R750 unit • automatic sliding door open sensors • mobile base stations g.
  • Page 38 Long-range EXD radio module – a unique tool developed by Neoline. If combined with Turbo mode, Neoline X-COP R750 hidden hybrid fully unlocks its potential in terms of police radars detection distance, including low- powered radars “in the back”. It is recommended to use this mode only when driving outside of the population areas.
  • Page 39 X-COP mode  — automatic switch between “City/Highway” sensitivity modes and Z-signature filtration modes* depending on the vehicle speed. Speed, Filter Z Traffic conditions km/h K band S band Mode signature Announcement Small residential 0-40 City No Beep and no Voice. settlements Only display Small residential...

  • Page 40: Menu (Operation By Touch)

    2. Menu (Operation by touch) 4. Time Touch this icon and it enters into the Setting mode. It shows the current time At Setting mode, settings for Blackbox/GPS/Radar and playing the recorded video are available. 5. City/Highway/Turbo/X-COP mode It shows the Mode 6.
  • Page 41 • Sound status • battery recharge It shows the Sound ON/OFF status It shows the battery charge level In case there is no SD card. • Voice recording status In case there is no SD card in SD slot, “Please insert SD It shows the voice recording ON/OFF status card”...

  • Page 42: Z-Signatures Anti-False Alert Filter

    Z-signatures anti-false alert filter The unique technology developed by Neoline to reduce the number of false responses. Timely detects and blocks false signals coming from blind area sensors in vehicles equipped with Blind Spot Monitoring, Side Assist, Blind Spot Detection and other systems.
  • Page 43 The significant benefit of this technology as compared with others is that Z-signatures anti-false alert filter, when used, does not block real police radars, including, among other things, the following: • Fixed and mobile KRIS-S/KRIS-P complex • Fixed and mobile ARENA complex •...
  • Page 44 Max Z-signatures anti-false alert filter – maximum Z-signature filtration level. Timely detects and blocks false signals coming from interior blind area sensors and prevents maximum number of other false responses. At that, the detection distance with regard to real police radars is lower as compared with the minimum Z-signature filtration mode.
  • Page 45 ANTTENTION! You can engage Maximum and Minimum filters at once, still, when Maximum Z-signatures anti-false alert filter is on, speed on Minimum filter cannot be set lower than hump speed of Maximum filter, for example: Max. Z-signatures anti-false alert filter is on, set for 0-70 km/h, so the speed for Min. filter can be set for 70 up to 250 km/h (not lower than 70 km/h).

  • Page 46: Parking Mode

    Parking mode It enters into the parking mode as the following cases. Mode setting : OFF Never enters into Parking mode, and when car engine is off, the unit will be power-off also. Mode setting : ON When Car Engine is Off, the unit enters into the parking mode immediately.

  • Page 47: Mute

    Resolution to be able to set : 1920*1080 (real Full HD) / 1280*720(HD) Recording frames: 15fps Power saving at Parking mode When the voltage of car battery becomes lower than 11.3V, X-COP R750 will be power off even at parking mode to prevent the car battery from being discharged.
  • Page 48 Touch the Radar Alert display for Mute On/Off Touch the GPS alert display for Mute On/Off Touch any of Radar alert display or GPS alert display during both alerts at once for Mute On/Off Auto mute At Auto mute On, the volume level will be decreased 50% in 6 seconds after starting Radar or GPS Alert.
  • Page 49 Voice On/Off Touch calibration Voice is heard at Voice On and no voice at Voice Off Please do the Touch calibration at Menu If the touch mode. screen operation is not done correctly. Touch Calibration process is as follows. Beep On/Off Menu->Blackbox setting->Touch calibration, “Do you Beep alert sound is heard at Beep On and no beep want to do touch calibration?”...
  • Page 50 Click “+” with sharp stick at the following screen If you want to store the new setting, please touch “Yes”. If you want to return to the previous stored setting, please touch “No”. Click “+” part several times with sharp stick and “Are you sure to apply new settings?”...

  • Page 51: Blackbox Firmware Upgrade

    Touch “OK” when the following is shown At this moment, the name of the firmware file must start with ”X-COP R750” and the file format must be “. Bin”. (For example : “X-COP R750 _BB(REVM1)_1.1.31.bin”) If the file name and format are not correct, the upgrade...
  • Page 52 The process of upgrade is as follows. If there is no firmware file, “Firmware file is not found” text will be shown on the screen. 8. The power of X-COP R750 will be Off and then On automatically once the Firmware upgrade is completed.

  • Page 53: Sd Card Format

    SD card format 2. Touch “OK” and “Caution! Delete all?” will be pop- X-COP R750 can do the SD card format differently from up as below normal format only in PC. If you do the SD card format, all data in the SD card memory will be deleted.
  • Page 54 Download the latest database file of X-COP R750 from Neoline homepage. 2. Connect the SD Card to PC by using the micro SD card adaptor which is included in the package. Copy the database file and paste it to the root directory of SD Card.

  • Page 55: Radar Firmware Upgrade

    Radar firmware upgrade X-COP R750 can upgrade the firmware of Radar module conveniently by using the SD card. The process of Radar module upgrade is as follows. Download the latest radar firmware of X-COP R750 from the Neoline homepage. 2. Connect the SD card to PC by using the micro SD 4.
  • Page 56 The Radar firmware upgrade will be processed with Radar alert the upgrade screen as below. X-COP R750 uses 2.8inch IPS LCD so that it helps to show If there is no Radar firmware file, the screen will the Radar alerts effectively for safety driving.
  • Page 57 Band identification Signal strength meter The following each radar band is displayed when any of The received signal is divided from Level-1 to Level-5 radar band is detected: according to the strength. The higher level has shorter beep sound. — X Band —...
  • Page 58 X-COP R750 has GPS POI(Point Of Interest) feature. is detection distance: The kinds of POI which X-COP R750 can detect are as 300 м / 400 м / 500 м / 600 м / 700 м / 800 м / 900 м...
  • Page 59 3. When distance is set by car speed, detection Alert operation distance is as below: X-COP R750 will give the voice announcement for the detected GPS POI and display the alert on LCD screen at once Car Speed, km/h Distance, m...
  • Page 60 Video surveillance alert In case of Video surveillance alert display, it shows an average speed differently from other types of POI. It shows the remaining distance up to Camera start point as like the following picture and then the average speed when it passes through the Camera start point.
  • Page 61 Intellectual processing of Trip-Track cameras TRIP TRACK system — This system consists of Displays distance to 1st camera and gives voice alert 2 cameras installed at the road section within the distance of 500 m —10 000 m from each other. 1st After the 1st camera is passed, displays distance to 2nd camera captures drive-through time.
  • Page 62 Types of police radars and traffic control cameras Camera type Icon Voice alert Camera type Icon Voice alert Stream Stream radar system Strelka Strelka radar Robot Robot radar Kris Kris radar Strelka video Strelka video block Arena Arena radar block Visir Visir radar Fixed / Low-duty...
  • Page 63 Camera type Icon Voice alert Camera type Icon Voice alert Mesta Mesta radar Odyssey Odyssey radar complex Ramet Ramet radar Sova Sova video control Python Python radar Avtouragan photo Avtouragan complex Speedgun Speedgun radar Cordon Cordon radar Multanova Multanova radar Harpoon Harpoon radar Redspeed...
  • Page 64 Many of the aforementioned police radars equipped Camera type Icon Voice alert with video unit enable control over the observance of road traffic regulations: Skat Skat radar Road traffic Display Voice recording Traffic control regulations control Traffic control post  post Bus lane control Bus lane control Crossroad and traffic...

  • Page 65: Emergency Recording Mode

    To activate the manual emergency recording mode, press the “Emergency Recording” button. The device will respond with an acoustical signal and a blue LED on the front panel of X-COP R750 will start blinking. Video Settings SET mode Touch the Video setting icon at the following...
  • Page 66 The explanation about each setting of Video Settings is as follows. LCD brightness Setting the brightness of LCD. Setting value : 1 ~ 10 (10 is brighter) LCD backlight time Touch in order to return to Normal screen. Setting the LCD screen to be turned off in some time in order to care for LCD screen and help driver’s view Change the Setting page by touching Setting value : Off(LCD is always...
  • Page 67 Automatic brightness setting for the display to be seen Video quality better by controlling the background and objective Setting the quality of recording video. brightness. Setting value : Super Fine/Fine/Nomal Setting value : On/Off Sharpness Sensitivity(Driving) Setting the sharpness of recording video. Setting the G-Sensor sensitivity during driving.
  • Page 68 Parking mode time Setting value : On/Off Setting value : Off/On/1min/5min/10min/15min/20min/25 GPS based time min/30min Setting time display by GPS based time or not. Recording time (Driving) Time will be displayed according to GMT time setting. Setting time for recording video file at the driving (Moscow : GMT + 3) mode.
  • Page 69 Setting On : the Speed will be indicated on the When the car shifts the lanes during the over speeding, recording screen. the warning will be announced, and the lane signs in Setting Off: there is no indication. the screen will turn red color. Off/20~140Km/h Speed stamp under 100Km/h LDWS Setting...
  • Page 70 If you enter car number, the number will be indicated on Recording Brightness : 0.0 the recording screen. WDR : On Sensitivity(Driving) : 2 Language Sensitivity(Parking) : 3 Setting the language for the text display. Motion detection(Parking) : 3 Setting value : Russian/English Parking mode time : 5min Recording time (Driving) : 1min Factory set...
  • Page 71 Beep : On Strelka only videomodule : On GPS alarm : On Radar strelka : On Radar alarm : On Fixed radar : On GPS Priority : On Radius of silence zone : 200m Touch calibration Radius of User Area : 600m It is to calibrate the Screen touch.
  • Page 72 Voice Voice On : Radar/GPS Voice alert is announced. Voice Off : Only beep alert is heard without Radar/GPS voice alert. Setting value : On/Off Beep Beep On : Radar/GPS beep alert is heard. Each setting of Detection is as follows. Beep Off : No Radar/GSP beep alert is heard.
  • Page 73 GPS Priority Legal overspeed setting When GPS priority is On, GPS alert priority is higher than The set value will be added to the speed limit of GPS Radar alert POI. Set range : 0/+5Km/+10Km/+15Km/+20Km/+25Km/+30Km Radius of silence zone Maximum overspeed setting (change by DOWN/UP) The detection range of silence zone can be changed.
  • Page 74 Filter Z signature Setting Car Speed Distance Filter Description 0 km/h ~ 60 km/h 600 meters It is current filter Z signature which blocks only car blind zones sensors. 61 km/h ~ 70 km/h 650 meters Possible settings 71 km/h ~ 80 km/h 700 meters Filter is off 81 km/h ~ 90 km/h...
  • Page 75 X Band Autodoria Setting value : On/Off Setting value : On/Off K Band Strelka only videomodule Setting value : On/Off Setting value : On/Off KA Band Radar strelka Setting value : On/Off Setting value : On/Off Laser Band Fixed radar Setting value : On/Off Setting value : On/Off Strelka...
  • Page 76 “Do you want to lock the file? (Yes or No)”. Unlock : Pressing the locked video file more than 3 sec. X-COP R750 can see the recorded video on high- • “Do you want to unlock the file? (Yes or No)”...

  • Page 77: Firmware Upgrade

    X-COP Player For the operating stability of the unit, the storage capacity for the locked files is limited. X-COP R750 can play the recorded videos at PC by using • “Lock file are overloaded. Please check the SD card.” a PC Player program and can change the setting value as well.
  • Page 78 The installation processes are as follows:...
  • Page 82 X-COP Player screen. Please click the X-COP Player ICON at the basic screen for the program start. The basic screen of PC Player is as follows.
  • Page 83 X-COP Player’s each screen is as follows.
  • Page 84 Current playing video. 2. G-Sensor value & Latitude, Longitude, Heading angle during driving. The status of PLAY. 4. Controlling the PLAY. Click the icon and then choose the SD Card Drive and then the video list inside of SD card will be appeared at right top side.
  • Page 85 Screen setting Click the icon at the right top side and the setting screen will be appeared. At the setting screen, you can change each setting value. Click “OK” button after changing to the value that you want and the setting value will be saved.

  • Page 86: X-Cop App

    X-COP APP (Rebooting – when Wifi is On or off) APP Install Download the App program from the APP Stores, and install the program on the Mobile Phone. X-COP set Setting Check at the Quick Menu Wifi On/Off...
  • Page 87 Menu  Video Setting  Page.7 Wifi SSID Setting – the name of Wifi (unit) Wifi SSID Rebooting...
  • Page 88 Wifi Password Setting If user sets the password under 7 digits, Password Setting...
  • Page 89 Rebooting...
  • Page 90 APP Play – Mobile Phone...
  • Page 91 WI-FI...
  • Page 92 Wifi Connected * Note: Default Password is set as “1234567890” (Back to the App) APP & DVR Connected с...
  • Page 93 a. Model Name & Firmware Version. b. Connect & Disconnect – Phone & Unit. c. Live Video. Back to the Main menu Screenshot Go to the Blackbox video list...
  • Page 94 d. Blackbox Video Download Delete Play...
  • Page 96 e. Download Video. f. Parking Location. NOTE: Parking Location function is only run, when the phone is connected with other online network (such as 3G or 4G, or other Wifi).
  • Page 97 g. Setting – the same as Unit settings.

  • Page 98: Potential Problems And Solutions

    Potential problems and solutions Connection to WiFi network failed Check password. Disengage other smartphone, connected earlier. Delete network from smartphone list and reconnect. Video recording and photo shooting failed Check free space on micro SD memory card, check whether it is locked. Spontaneous stop in recording process Due to high volume of video files use only high-speed micro SD cards, 10th class minimum, by proven manufacturers.
