Configuring Network Connections for the PC

12
LX100 G S G
ETTING TARTED
1. From the PC, click on the Start menu and then click on the Run option.
2. When the "Run" window appears, type ncpa.cpl
3. After the "Network Connections" window opens, right click on the Local
Area Connection and select Properties.
4. After the "Local Area Connection Properties" window appears, click on
Internet Protocol (TCP/IP) then click on the Properties button.
5. Once the "Internet Protocol (TCP/IP) Properties" window opens, set the
options under "Use the following IP address" and "Use the following DNS
server addresses" to the following ReadiManager server default settings:
IP Address: IP Address: Can be any IP address from 192.168.1.1
through 192.168.1.253 (e.g. 192.168.1.37)
Subnet Mask: 255.255.255.0
Default Gateway: leave blank, or do not change
Preferred DNS server: leave blank, or do not change
Alternate DNS server: leave blank, or do not change
6. Click on OK for both the IP Properties window and the LAN properties
window. Then close both windows.
