SportsArt Fitness T655L Owner's Manual

16” & 19” senza console
Hide thumbs Also See for T655L:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
T655L-16"&19" SENZA CONSOLE OWNER'S MANUAL
SENZA SERIES DISCLAIMER TERMS ................................................. 1
1. INTRODUCTION ................................................................................ 2
2. SAFETY PRECAUTIONS ..................................................................
3. LIST OF PARTS .................................................................................
4. ASSEMBLE THE PRODUCT ............................................................. 10
STEP 2 Install the Display ..................................................................... 21
STEP 3 Install the Right/Left Side Covers ............................................. 25
STEP 4 Move the Treadmill into Place for Use ...................................... 26
STEP 5 Level the Treadmill ................................................................... 27
STEP 6 Align the Walk Belt ................................................................... 28
STEP 7 Adjust the Walk Belt Tension .................................................... 29
STEP 8 Install the Power Cord .............................................................. 30
STEP 9 TV Terminal and Network ......................................................... 31
STEP 10 Install the TV Cable ................................................................ 32
DISPLAY Overview ................................................................................ 33
DISPLAY Safety Key ............................................................................. 33
DISPLAY Keys ...................................................................................... 34
DISPLAY Windows ................................................................................ 35
6. OPERATE THe PRODUCT ............................................................... 36
OPERATION Safety Operating Area ..................................................... 36
OPERATION Overview .......................................................................... 38
OPERATION Start Screen .................................................................... 38
OPERATION Start your (GO) workout .................................................. 39
OPERATION Workout Selection ............................................................ 39
OPERATION Workout Programs ........................................................... 40
OPERATION Workout Status ................................................................ 41
OPERATION Select Entertainment ....................................................... 43
OPERATION View Entertainment ......................................................... 43
OPERATION Workout Summary ........................................................... 44
OPERATION Idle Mode ........................................................................ 45
OPERATION Energy Smart Function ................................................... 45
OPERATION Error Messages ................................................................ 45
7. ABOUT HEART RATE DETECTION .................................................. 46
HEART RATE Telemetry ........................................................................ 46
HEART RATE Contact ........................................................................... 46
8. GUIDELINES FOR EXERCISE ......................................................... 47
9. MAINTENANCE ................................................................................ 48
MAINTENANCE Safety Precautions ..................................................... 48
MAINTENANCE Circuit Breaker ........................................................... 49
MAINTENANCE Lubrication System .................................................... 50
MAINTENANCE Schedule .................................................................... 53
MAINTENANCE Task List ..................................................................... 54
MAINTENANCE One-Year Maintenance Log ....................................... 55
3
8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T655L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SportsArt Fitness T655L

Summary of Contents for SportsArt Fitness T655L

  • Page 1: Table Of Contents

    STEP 8 Install the Power Cord .............. 30 STEP 9 TV Terminal and Network ............31 STEP 10 Install the TV Cable ..............32 5. UNDERSTAND THE T655L 16”&19” SENZA CONSOLE ....33 DISPLAY Overview ................33 DISPLAY Safety Key ................33 DISPLAY Keys ..................
  • Page 2 T655L-16”&19” SENZA CONSOLE OWNER’S MANUAL 10. ACCESSORIES ................ACCESSORIES Entertainment Cap ............ ACCESSORIES Options ..............11. APPENDIXES ................. 59 APPENDIXES Specifications ............... APPENDIXES Electronics Block Diagram ........... APPENDIXES Exploded Diagrams............61...

  • Page 3: Senza Series Disclaimer Terms

    SENZA SERiES diSCLAiMER TERMS Internet function: A1. This machine provides only a web page browsing method for web page and video browsing. A2. For web page videos, we support only Youku and YouTube. Note: Some videos may not be viewed due to restrictions resulting from country policies, internal server firewalls, or video formats, etc.

  • Page 4: Introduction

    1. iNTROdUCTiON Congratulations on the purchase of a high quality SportsArt product, the T655L 16” & 19” Senza Console Treadmill. Constructed of high quality materials and designed for years of reliable performance, this product was made for full commercial use.

  • Page 5: Safety Precautions

    2. SAfETy PRECAUTiONS This product was designed and built for optimum safety. However certain precau- tions apply during the use of this product. Please note the following safety precautions: • Please read the entire manual before assembly and operation. Make sure the product is installed and operated as instructed in this manual.
  • Page 6 2. SAfETy PRECAUTiONS (CONTiNUEd) CAUTION: If you feel any pain or any abnormal sensations, STOP YOUR WORKOUT and consult your physician immediately. Work within your recommended exercise level. DO NOT work to exhaustion. Before beginning any exercise program, you should consult with your doctor. It is recommended that you undergo a complete physical examination.
  • Page 7 2. SAfETy PRECAUTiONS (CONTiNUEd) If you are a French speaking person in North America, please place the following label contained in the owner’s manual on the console as shown. Customers outside of North America will not receive this French warning label.
  • Page 8 2. CONSiGNES dE SÉCURiTÉ iMPORTANTES Votre tapis de course SportsArt a été conçu et fabriqué afin d’assurer une sécurité optimale. Cependant certaines précautions s’appliquent chaque fois que vous uti- lisez votre tapis de course. • Lisez entièrement le manuel avant l’assemblage et l’utilisation. Veuillez aussi noter les consignes de sécurité...
  • Page 9 2. CONSiGNES dE SÉCURiTÉ (SUiTE) • Pour éviter de vous blesser, restez sur les bandes de repos (barres latérales) avant de démarrer le tapis de course. • Ce tapis de course n’est pas destiné à être utilisé par des personnes (y com- pris des enfants) dont les capacités physiques, sensorielles ou mentales sont réduites ou qui ne disposent pas de l’expérience ou du savoir nécessaires, sauf si celles-ci ont au préalable été...

  • Page 10: List Of Parts

    3. LiST Of PARTS Assembly Parts Name Qty. No. Name Qty. A1 Display A6b Left side cover A2 Handlebar assembly A7 Left pedestal Front handlebar A3 Right pedestal assembly (For 16” only) A4 Feeder cord A9 Owner’s manual A5 Water guard A10 Hardware kit A6 Main frame A11 Power cord...
  • Page 11 3. LiST Of PARTS (CONTiNUEd) Components in the Hardware Kit Name Qty. Specification Notes 31 Screw cover (flat) 32 Screw cover (rounded) 33 NTSC To PAL Adapter 34 Screw socket 35 Mushroom top Phillips screw M4*L12 T-shaped Allen wrench (M4) T-shaped Allen wrench (M6) L-shaped Allen wrench...

  • Page 12: Assemble The Product

    4. ASSEMBLE THE PROdUCT Follow instructions below to assemble this product. Note that in this manual the words “left” and “right” are used to refer to the product and its parts. As such, these designations correspond to the “left” and “right” sides of a person in position to exercise on this product.

  • Page 13: Step 1 Install The Pedestals And Handlebar Assembly

    STEP 1 install the Pedestals and Handlebar Assembly Follow instructions below to install the pedestals and handlebar assembly. The illustration below provides an overview of this step.
  • Page 14 STEP 1 install the Pedestals and Handlebar Assy. (Cont.) Remove screws (41) from the pedestal mount as shown.
  • Page 15 STEP 1 install the Pedestals and Handlebar Assy. (Cont.) Follow instructions (a) through (e) below to thread the data cable into the right pedestal. Before assembly, make sure the left & right pedestals are align with left and right sides on the main frame. (a) First, remove the zip tie on the cable in the right pedestal mount and then stretch the cable out as shown.
  • Page 16 STEP 1 install the Pedestals and Handlebar Assy. (Cont.) Follow instructions (a) through (d) below to thread the data cable into the left pedestal. Before assembly, make sure the left & right pedestals are align with left and right sides on the main frame. (a) First, remove the zip tie on the cable in the left pedestal mount and then stretch the cable out as shown.
  • Page 17 STEP 1 install the Pedestals and Handlebar Assy. (Cont.) Hold the data cable at the top of the right pedestal (A3), and insert the bottom of the right pedestal (A3) onto the pedestal mount. Place the water guard (A5) on the pedestal higher than the motor cover. Repeat the process for the left pedestal (A7) assembly.
  • Page 18 STEP 1 install the Pedestals and Handlebar Assy. (Cont.) Follow instructions (a) through (e) below to finish installing handlebar assembly. (a) First, remove screws (42) (43) from the handlebar assembly (A2). (Note: Remove screws on both sides.) (b) Securely connect the left and right cables from the handlebar assembly (A2) to the left and right pedestals (A3) (A7) cables.
  • Page 19 STEP 1 install the Pedestals and Handlebar Assy. (Cont.) (d) Place the removed screws (42) (43) back into the handlebar assembly. Tighten screws (42) in area B first and then tighten screws (43) in area C next.) (e) Finally, press the screw covers (31) into the screw heads.
  • Page 20 STEP 1 install the Pedestals and Handlebar Assy. (Cont.) After the handlebars are in place, secure pedestal screws in area A on left and right sides.
  • Page 21 Follow instructions (a) through (d) below to install the front handlebar assembly. (For T655L 16” touch screen only.) (a) Install the waterproof back into the front handlebar assembly (A8) if necessary. Make sure the arrow of the waterproof ring upward as shown.
  • Page 22 STEP 1 install the Pedestals and Handlebar Assy. (Cont.) (c) Connect the cables from the front handlebar assembly (A8) and the handlebar assembly (A2). Collect the cables and tuck them as indicated by arrows back into the hole of the front handlebar assembly (A8) for safety.

  • Page 23: Step 2 Install The Display

    STEP 2 install the display Follow instructions below to install the display onto the cowling. The illustra- tion below provides an overview of this step.
  • Page 24 STEP 2 install the display (Continued) Follow instructions (a) through (f) below to install the display assembly. (a) Remove screws (44) from the handlebar (A2). (b) Insert the display (A1) onto the handlebar assembly (A2). (Note: aim properly to avoid damaging the display board.) Push the display (A1) slightly upward and then insert the display mounting bottom into the opening on the handlebar assembly.
  • Page 25 STEP 2 install the display (Continued) (c) Remove screws (49) in the back of the display (A1) and then remove the rear cover (46) from the place marked with “OPEN” as shown. (d) Hold the display (A1) forward slightly as shown and then press downward when securing screws (44).
  • Page 26 STEP 2 install the display (Continued) (e) Pull the cables out of the handlebar (A2) and then connect to the cables from the display. After connecting the cables, push the black cover to cover the end of the cables as shown. Finally, tuck all the cables back into the display for safety.

  • Page 27: Step 3 Install The Right/Left Side Covers

    STEP 3 install the Right/Left Side Covers Put the right/left side covers (A6a) (A6b) in place and secure them with screws (35). Finally, put the water guards (A5) in area B down against the motor cover on both sides. Note: Inspect whether the screw sockets and screws in area C are in place on the product.

  • Page 28: Step 4 Move The Treadmill Into Place For Use

    STEP 4 Move the Treadmill into Place for Use First, place hands under the frame in area A, lift the treadmill and then roll it into position as desired.

  • Page 29: Step 5 Level The Treadmill

    STEP 5 Level the Treadmill Press downward on the rear part of the treadmill as shown. Inspect whether the treadmill rests flat on the floor. If the treadmill wobbles, adjust treadmill levelers as follows: (a) Loosen the leveler nut. (b) Rotate the leveler foot downward, touching the floor. (c) Rotate the leveler nut upward, against the frame of the product, to secure this position.

  • Page 30: Step 6 Align The Walk Belt

    STEP 6 Align the Walk Belt (a) First, make sure the treadmill is on a leveled surface and the incline is at (b) Start the speed at a lower rate of 3kph/2.5mph to check if the walk belt is aligned and there is an equal amount of space between walk belt and side-rails on both sides.

  • Page 31: Step 7 Adjust The Walk Belt Tension

    STEP 7 Adjust Walk Belt Tightness As you exercise, does the walk belt suddenly pause and then regain traction? Or, if you bear down against the walk belt, does the belt not pause whatsoev- er? If either of these two conditions occurs, the walk belt may be too loose or too tight.

  • Page 32: Step 8 Install The Power Cord

    STEP 8 install the Power Cord (a) First remove screws (45) from the power cord socket on the product. (b) Insert the power cord into place on the product. (c) Secure the power cord with screws (45) and then insert the other end of the power cord (A11) into the appropriate power supply socket in the wall.

  • Page 33: Step 9 Tv Terminal And Network

    STEP 9 TV Terminal and Network (a) NETWORK: Connect to Ethernet. (b) AV Terminal: Connect to DVD Player or Media Player. (c) TV: Connect to ATV (NTSC or PAL) or DTV.

  • Page 34: Step 10 Install The Tv Cable

    STEP 10 install the TV cable NTSC system: Directly connect your local area connector as shown. PAL system: Insert NTSC to PAL Adapter (33) as shown and connect to your local area connector.

  • Page 35: Understand The T655L 16"&19" Senza Console

    5. UNdERSTANd THE SENZA CONSOLE diSPLAy Overview T655L Series 16”&19” Senza Console are designed to help users obtain their fitness goals in a simple and convenient way. Before using the treadmill, please familiarize yourself with the functions of this display console to obtain optimum benefits and enjoyment from this product.

  • Page 36: Display Keys

    diSPLAy Safety Key (Continued) Always attach the clip to your clothes and set the magnet in place on the console. diSPLAy Keys Information on central control panel buttons and functions are shown in the following diagram.

  • Page 37: Display Windows

    diSPLAy Keys (Continued) Name of button function When the machine is in the Energy Smart Energy Smart Wake- conservation mode, pressing this button will Up Button wake up the machine and turn the power on again. The user can listen to audio or music after Headphone Jack inserting a headphone Incline Adjustment...

  • Page 38: Operate The Product

    (b) The central handlebar at area D is used for heart rate detection only, not for support and to maintain balance. (For T655L 16” only.) (c) Make sure stand on the center of the running belt where are marked with green round labels at area E when operating.

  • Page 39: Operation Proper Workout Position And Safety Get Off

    OPERATiON Proper Workout Position and Safety Get Off (a) User proper workout position as Figure (a). shown. (b) If the user needs to leave the working running belt urgently, please put the hands on the handlebars and feet step on the landing strips as Figure (b).

  • Page 40: Operation Overview

    OPERATiON Overview Touch screen design is simple and clear. The screen layout helps users fo- cus on exercise. It provides many workout modes that can help you achieve your fitness goal. The following sections introduce information concerning touch screen operation, the available types of workout, and how to start the workouts.

  • Page 41: Operation Start Your (Go) Workout

    OPERATiON Startup Screen (Continued) No. Name of button function CUSTOMIZED Web page status display for browsing and opera- WEB PAGE tion WINDOW Touch this button to access workout program se- SELECT lection Displays various virtual realities. Touch this screen FEATURE to access the virtual reality training mode 10 GO Touch this button to start workout...

  • Page 42: Operation Workout Programs

    OPERATiON Workout Selection (Continued) Description of icons on the “Select” screen iCON description Tap to return startup screen. During exercising, tap it to stop or resume workout. Pause Quick Tools OPERATiON Workout Programs Workout program details are explained below. QUiCK START A workout mode option based on time, distance and calories that allows user to start a workout immediately.

  • Page 43: Operation Workout Status

    OPERATiON Workout Programs (Continued) fiTNESS TEST A variety of professional fitness test modes are provided, including the fol- lowing programs: • BRUCE heart test uses a modified BRUCE protocol with an electrocar- diogram. • Canada Firefighters Fitness Test Program (GERKIN) •...
  • Page 44 OPERATiON Workout Status (Continued) Drop down menu introduction: drop down Menu items Symbol default Other Options Average Incline Incline Elevation Gain Change Incline Pace Speed Average Speed Change Speed Time Remaining Clock Time Elapsed Segment Duration Target Duration Segment Duration Segment Remaining Time Elapsed Time Remaining...

  • Page 45: Operation Select Entertainment

    OPERATiON Select Entertainment You can select the “Select Entertainment” page below the screen, and the available multimedia features will be displayed. The features include TV, In- ternet, SENZA Journeys, Bluetooth Audio, USB Audio USB Video, IPTV and AVIN, etc.: the small central window will display the selected multimedia screen immediately.

  • Page 46: Operation Workout Summary

    OPERATiON View Entertainment (Continued) Description of Icons in the “Entertainment” screen icon description Full Screen Close Full Screen Mute Lower volume Raise volume Slow reverse Play Fast Forward OPERATiON Workout Summary At the end of a workout or when you press the stop button, the workout sum- mary screen will appear.

  • Page 47: Operation Idle Mode

    OPERATiON idle Mode When the treadmill stops running with no other activity for 2 minutes, the ma- chine will enter the idle mode and the display will randomly show the standby picture. Touch any position in the idle mode to enter the Home page. Note: The standby picture can be changed and set by the user.

  • Page 48: About Heart Rate Detection

    7. ABOUT HEART RATE dETECTiON Heart rate detection functions are selected at the time of purchase. Not every product has every type of heart rate detection. The following explains factors that influence the performance of two of the most common types of heart rate detection devices.

  • Page 49: Guidelines For Exercise

    8. GUidELiNES fOR EXERCiSE HOW HARd SHOULd i EXERCiSE? Studies show that to benefit from aerobic exercise, people need to maintain a certain heart rate during their workouts. Your heart rate training zone depends on your age and fitness level. The darkened area in the chart to the right represents the recommended heart rate training zone for people of various ages.

  • Page 50: Maintenance

    9. MAiNTENANCE This section covers maintenance topics, including instructions on replacing a fuse and lubricating the walk belt, along with the presentation of a main- tenance schedule, maintenance task list, one-year maintenance log, and electronics block diagram. MAiNTENANCE Safety Precautions ●...

  • Page 51: Maintenance Circuit Breaker

    MAiNTENANCE Circuit Breaker (a) A circuit breaker is an automatically operated electrical switch designed to protect an electrical circuit from damage caused by overcurrent/ overload or short circuit. A spring located under the push button causes the button at area D to lift up and the breaker to trip as shown. (b) After the fault is repaired by qualified technicians, press the push button to reset circuit breaker to resume normal operation as shown.

  • Page 52: Maintenance Lubrication System

    MAiNTENANCE Lubrication System Lubrication System flowchart Model No. Display ex: T655 Total Exercise 5 seconds Distance Display (km) Power On RESET Walks Belt Version Display Total Exercise Total Exercise Total Exercise Speed Total ex:T655 Distance Display (mile) Distance Display (km) Distance Display (km) Running Time...
  • Page 53 MAiNTENANCE Lubrication System (Continued) To replace the lubricant bottle, follow instructions (a) through (d) below. (a) Loosen the screws on the bezel and push the bezel up. (b) Take the old lubricant bottle out. (c) Unscrew the nozzle from the old lubricant bottle and screw it onto new bottle.
  • Page 54 MAiNTENANCE Lubrication System (Continued) Error Messages: There are 2 error messages with this system. Error 1: It indicates that the system memory failing and it will not be able to perform any auto lubrication. Error 2: It indicates motor is failing or system will not be able to perform any function.

  • Page 55: Maintenance Schedule

    MAiNTENANCE Schedule Area Day Week Month Quarter Year Notes Exterior Clean. Screws Inspect and secure loose parts. Ensure the treadmill operates properly. Treadmill test Inspect alignment (centering) and look Walk belt for wear. Walk deck Inspect for wear. Belt guides Inspect for normal rotation.

  • Page 56: Maintenance Task List

    MAiNTENANCE Task List Like cars, fitness products require maintenance. Regular maintenance ex- tends product life, and failure to maintain products can void the manufac- turer’s warranty. Copy the maintenance log sheet, and record maintenance work for each fitness product. daily tasks 1.

  • Page 57: Maintenance One-Year Maintenance Log

    MAiNTENANCE One-year Maintenance Log Facility:_______________________ Supervisor:____________________ Product model number:__________ Serial number:_________________ Start date: ____________________ End date:_____________________ daily Tasks Weeks 1-7 Weeks 8-14 Weeks 15-21 Week 22-28 Completed daily Tasks Week 29-35 Week 36-42 Week 43-49 Week 50-52 Completed Weekly Tasks Weeks 1-7 Weeks 8-14 Weeks 15-21 Weeks 22-28...

  • Page 58: Accessories

    10. ACCESSORiES These accessories are related to the functions of this machine. Some are standard and others are optional. The details of each accessory and its function are explained. USB CHARGER (Standard) The USB charger will provide 5V and 1.5A voltage for charging of smart phone or other devices.

  • Page 59: Accessories Entertainment Cap

    ACCESSORiES Entertainment Cap (a) RFID member card slot: Work with both optional SA WELL+ and ECOFIT member cards. (Not available yet.) (b) Bluetooth/WIFI button: When a smart phone is connected with equipment, press this button to disconnect. Scan the QR code or touch the NFC tag on the console to connect to the equipment again if necessary.

  • Page 60: Accessories Options

    ACCESSORiES Options 1. Long Handrails 2. Fan Set...

  • Page 61: Appendixes

    11. APPENdiXES APPENdiXES Specifications Model T655L 16” T655L 19” L : 2200 mm (86.6”) L : 2200 mm (86.6”) dimensions W : 955 mm (37.5”) W : 955 mm (37.5”) H : 1467 mm (57.7”) H : 1550 mm (61”) Overall Weight 179.7 kg (395.34 lbs)

  • Page 62: Appendixes Electronics Block Diagram

    APPENdiXES Electronics Block diagram HTR Board CSAFE Board Control Board Display Board USB Board HRC Board NFC Board Head Phone Board EUP Key Board Contact HTR plates Bridge Board Safety Key Board Speed & Incline Keypad Board Incline Control Motor EAC Drive Incline Sensor Board...

  • Page 63: Appendixes Exploded Diagrams

    APPENdiXES Exploded diagrams Note: We reserve the right to revise the following diagrams at any time without notice to notify any person of such revisions. Please visit our official website www.gosportsart.com for the latest version. T655L 19”...
  • Page 64 your Authorized distributor...
