Topic: Treadmill Walk Belt Lubrication and the Lubrication Prompt

Date: 2009-03-10

Overview: In late 2008, SportsArt added a prompt to remind people to lubricate

treadmill walk belts. This document explains what to do when the lubrication

prompt appears. It also explains walk belt lubrication as part of a treadmill

maintenance program.

Applies to treadmills with the lubrication prompt: T610, T620, T625, T630,

T650, T650M, T670, and T680

When total distance exceeds 4000 KM/2500 miles and the walk belt stops

moving, the message "SERVICE NEEDED- APPLY LUBE" appears on the

treadmill display.

Until total distance exceeds 4100 KM/2560 miles, the treadmill can be

operated normally. At over 4100 KM/2560 miles, the "SERVICE NEEDED-

APPLY LUBE" message will remain on the screen and the treadmill will not

operate until the following process is completed.

1. On T630, T650, T650M, T670, T680 treadmills, remove one end cap (left).

On T610, T620, T625 treadmills, remove one end cap and one landing strip

(right).

Table of Contents

Need help?

Do you have a question about the T610 and is the answer not in the manual?

Page 1 APPLY LUBE” message will remain on the screen and the treadmill will not operate until the following process is completed. 1. On T630, T650, T650M, T670, T680 treadmills, remove one end cap (left). On T610, T620, T625 treadmills, remove one end cap and one landing strip (right).
Page 2 2. Simultaneously press and hold INCLINE ▲ + INCLINE ▼ + 0 keys for two seconds. This activates the “lubrication mode.” The treadmill will operate at the lowest speed. At this point, ▲ and ▼ command keys will not operate. 3.
Page 3 7. Secure the end cap on T630, T650, T650M, T670, T680 treadmills. On T610, T620, T625 treadmills, secure the landing strip and the end cap. This completes the lubrication procedure. Lubricating When Not Prompted The lubrication mode can be activated at any time through the following procedure: 1.
Page 4 SportsArt Walk Belt Lubrication Kit Walk Belt Lubrication Kit HyperGlide™ lubricant includes both items shown (50 cc, 1 ounce) below. Part number: LUBE-03 Part number: LUBE-04 Price: $3.00 Price: $8.20 Applicator tube Part number: LUBE-02 Price: $5.20 Order these parts online at www.SportsArtAmerica.com or by calling the SportsArt service department at 1-866-709-1750.
