SportsArt Fitness T652 Manual

Hide thumbs Also See for T652:
Table of Contents

Advertisement

Quick Links

See also: Repair Manual , Owner's Manual

TABLE OF CONTENTS

1. INTRODUCTION.....................................................................................................
2. IMPORTANT SAFETY PRECAUTIONS..................................................................
3. LIST OF PARTS.......................................................................................................
4. TREADMILL ASSEMBLY.........................................................................................
STEP 2 Install the Display......................................................................................
STEP 3 How to Move the Treadmill.......................................................................
STEP 4 Level the Unit...........................................................................................
STEP 5 Align the Walk Belt...................................................................................
STEP 6 Adjust Walk Belt Tightness.......................................................................
STEP 7 Install the Power Cord..............................................................................
STEP 8 Replacing the Fuse..................................................................................
5. T652 DISPLAY........................................................................................................
Display Features....................................................................................................
Display Functions...................................................................................................
Button Functions....................................................................................................
Safety Key..............................................................................................................
6. HOW TO USE YOUR T652 TREADMILL...............................................................
Quick Start..............................................................................................................
Workout Setup........................................................................................................
Operating Procedure during Exercise....................................................................
Cool Down..............................................................................................................
About Telemetry Heart Rate...................................................................................
About Contact Heart Rate......................................................................................
8. PROGRAM DETAILS.............................................................................................
9. GUIDELINES FOR EXERCISE..............................................................................
10. USER PARAMETER SETTING.............................................................................
USB PORT.............................................................................................................
11. MAINTENANCE....................................................................................................
12. ERROR MESSAGES............................................................................................
13. WIRING SCHEMATIC..........................................................................................
1
2
7
10
10
17
20
21
22
23
24
25
26
26
26
27
29
30
30
30
31
32
33
33
33
35
38
39
39
40
44
45

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T652 and is the answer not in the manual?

Questions and answers

Related Manuals for SportsArt Fitness T652

Summary of Contents for SportsArt Fitness T652

  • Page 1: Table Of Contents

    STEP 8 Replacing the Fuse.................. 5. T652 DISPLAY......................Display Features....................Display Functions....................Button Functions....................Safety Key......................6. HOW TO USE YOUR T652 TREADMILL............... Quick Start......................Workout Setup......................Operating Procedure during Exercise..............Cool Down......................7. ABOUT THE HEART RATE DETECTION AND PRESENTATION......

  • Page 2: Introduction

    Congratulations on the purchase of one of the finest pieces of commercial exercise equipment on the market today, the SportsArt T652 Commercial Treadmill. The T652 is designed with the end-user in mind and constructed of high quality materials for years of trouble-free use.
  • Page 6 If the user desires to correct the interference, it is at his or her own expense.

  • Page 8: List Of Parts

    LIST OF PARTS Assembly Parts Number Qty Number Name Name Display Left pedestal Handlebar assembly Owner manual Safety key Hardware kit Power cord Right pedestal Applicator tube Feeder cord Silicone lubricant Waterproof ring Main frame Right side cover Left side cover...
  • Page 9 Hardware Kit Name Specification Number Notes Screw cover (flat) Screw cover (rounded) 15A-100V~110V Fuse 10A-200V-240V L-shaped Allen wrench (M4) L-shaped Allen wrench (M5) L-shaped Allen wrench (M6) L-shaped Allen wrench (M6) Double open-end wrench (22*24) Screwdriver handle green Screwdriver bit Phillips and flat Components on the Product Number...
  • Page 10 Please make sure that the walk belt runs below the walk belt guides. Walk belt guides should press the walk belt down on both sides. If the walk belt is on top of the guides, loosen screws at position A. Place the walk belt below the guides as shown. Then readjust walk belt tightness per instructions in part 6.

  • Page 11: Treadmill Assembly

    TREADMILL ASSEMBLY Assemble the Left and Right Pedestals and Handlebars STEP 1...
  • Page 12 1-1. Remove pedestal mount covers (A6a,A6b). 1-2. Remove screws (41) from the pedestal mount as shown.
  • Page 13 1-3. Follow steps (a~e) in order to thread the data cable into the right pedestal. (a) First, remove the zip tie on the cable in the right pedestal mount. Then stretch the cable out as shown. (b) Place the right pedestal (A3) on the floor, with the lower hole facing the data cable.
  • Page 14 1-4. Hold the data cable at the top of the right pedestal (A3), and insert the bottom of the pedestal onto the pedestal mount. Avoid pinching or crimping the data cable. Place the water guard (A6) on the pedestal higher than the motor cover. Loosely secure the right pedestal (A3) with screws (42).
  • Page 15 1-5. Follow steps (a~e) to install handlebars. a. First, remove the screws (42, 43) from the handlebar assembly (A2). b. Insert the left side of the handlebar (A2) into the left pedestal (A7). c. Connect the cables in area A from the right pedestal (A3) and from the handlebar (A2).
  • Page 16 d. Tuck cables into the pedestal safely. Then insert the right side of the handlebar assembly (A2) into the right pedestal (A3), without pinching or crimping cables. e. Thread screws in place by hand. First, secure screws (42) in area B. Then secure screws (43) in area C.
  • Page 17 1-6. After the handlebars are in place, secure pedestal screws on left and right sides. Put pedestal covers (A6a,A6b) in place. Then put water guards (A5) down against the motor cover on both sides.

  • Page 18: Step 2 Install The Display

    STEP 2 Install the Display...
  • Page 19 2-1. Follow steps (a~g) below to install the display assembly. a. Remove screws (44) from the handlebar (A2). b. Insert the display (A1) onto the handlebar assembly (A2). Note: aim properly to avoid damaging the display board. c. Then slightly lift the display (A1) d.
  • Page 20 e. Connect cables in areas A and B. f. After connecting cables, tuck them away for safety. Then slightly lift the display (A1) and press it into place. Note: In area C, the display cover must be outside of the handlebar cover. g.

  • Page 21: Step 3 How To Move The Treadmill

    STEP 3 How to Move the Treadmill 3-1. First, place hands under the frame in area A, lift the treadmill, then roll it into position as desired.

  • Page 22: Step 4 Level The Unit

    STEP 4 Level the Unit 4-1. Press on points A and B to inspect whether the unit is stable and level on the ground. 4-2. If not, please level the treadmill by following instructions (a, b, c): a. First, loosen leveler nuts. b.

  • Page 23: Step 5 Align The Walk Belt

    STEP 5 Align the Walk Belt 5-1. The walk belt should run in the center of the deck, with an even amount of space on both sides, between the belt edges and the landing strips. If the space on either side is not the same, rotate rear roller screws about one-half turn at a time.

  • Page 24: Step 6 Adjust Walk Belt Tightness

    STEP 6 Adjust Walk Belt Tightness 6-1. As you exercise, does the walk belt suddenly pause and then regain traction? Or, if you bear down against the walk belt, does the belt not pause whatsoever? If either of these two conditions occur, the walk belt may be too loose or too tight. In this case, please turn off the treadmill and adjust walk belt tightness.

  • Page 25: Step 7 Install The Power Cord

    STEP 7 Install the Power Cord 7-1. First remove screws (45) from the power cord socket on the product. 7-2. Insert the power cord into place on the product. 7-3. Secure power cord connector screws (45). Then insert the other end of the power cord into the appropriate power supply socket in the wall.

  • Page 26: Step 8 Replacing The Fuse

    STEP 8 Replacing the Fuse If current becomes too high, the fuse breaks. This protects the product. To replace a fuse, follow instructions (a~g) below. (a) Press inward on the fuse cap. (b) Turn the fuse cap counterclockwise. (c) The fuse and fuse cap springs out. (d) Remove the burnt fuse.

  • Page 27: T652 Display

    T652 DISPLAY A. Display Features Cardio Advisor Feedback Window Heart Rate LED Programs Numeric Keypad Dot Matrix Display B. Display Functions 1. SPEED: 0.1 to 15.0 MPH or 0.2 to 24.0 KPH in 0.1 increments 2. INCLINE: 0 to 15%, in 0.5% increments 3.

  • Page 28: Button Functions

    6. CAL/Hr: Calories burnt per hour, 0.0 to 999.9 KCAL 7. METS (Metabolic burn rate): 0.00 to 99.00 8. PACE: 1/SPEED 9. PROGRAM: MANUAL, HILL (HILL1, HILL2, HILL3), RANDOM, INTERVAL (1:1, 1:2, 2:2), TRACK (TRACK 5K, TRACK 10K), GLUTE, FAT BURN, ZONE TRAINER, WT LOSS/CARDIO and FIT TEST (BRUCE, GERKIN, FIRE FIGHTER) 10.
  • Page 29 10. WT LOSS/CARDIO Press to start the heart rate control modes - Wt Loss & Cardio. The weight loss program keeps the user's heart rate at 65% of maximum (i.e. (220-AGE)*0.65) to provide an optimal weight loss workout, while the cardio program keeps the user's heart rate at 80% of maximum (i.e.

  • Page 30: Safety Key

    b. Under any status: Hold this button to reset to the startup screen. D. Safety Key 1. Before exercising, set the magnetic side of the safety key into its slot on the treadmill. Clip the other side of the safety key cord onto your clothes. 2.

  • Page 31: How To Use Your T652 Treadmill

    HOW TO USE YOUR T652 TREADMILL 1. Quick Start Press QUICK START to start exercising without first inputting user information. "TREAD STARTING" will appear on the display, and the walk belt will rotate at 0.1 MPH/0.2 KPH. Press SPEED up/down to change speed. The user default setting is 165 LB/75 KG.

  • Page 32: Operating Procedure During Exercise

    (5) When "TRACK" is selected, the 14-segment display will show "TRACK". → → → Press more times to view TRACK TRACK 5K TRACK 10K ... In "TRACK", press ENTER to confirm your choice. If you selected TRACK 5K or TRACK 10K, the exercise course begins immediately. If you selected TRACK, the 14-segment display will show "TIME-1 DIST-2".

  • Page 33: Cool Down

    (2) Wt Loss Training Zone & Cardio Training Zone: Users of different ages will see different target heart rates. The target heart rate is based on user age. C. Even though you are exercising under one workout program, you can activate a different workout program.

  • Page 34: About The Heart Rate Detection And Presentation

    ABOUT THE HEART RATE DETECTION AND PRESENTATION About Telemetry Heart Rate The word "telemetry heart rate" refers to the detection of the heart rate, usually via a strap worn on the exerciser's chest, and transmitted over the air for reception by a receiver built into the product.
  • Page 35 4. The vibration of treadmills at speeds over 4 MPH/6.4 KPH makes heart rate detection difficult. Also, if your hands move, heart rate detection becomes difficult. Suggestions: For better heart rate detection, keep hands in one place on the contact plates. Or wear a telemetry heart rate strap on your chest.

  • Page 36: Program Details

    PROGRAM DETAILS 1. MANUAL & TRACK One lap is equal to 400 meters (0.25 mile). 2. HILL There are three hill workout programs (HILL 1, HILL 2, and HILL 3). Press HILL to switch to a different hill course. 3. RANDOM The random program includes an infinite number of programs.
  • Page 37 6. WT LOSS & CARDIO Heart Rate Control Programs Both WT LOSS & CARDIO heart rate control programs automatically adjust speed or incline to maintain your heart rate at a specific target, based on your exercise goals. A. Target heart rates: (1) WT LOSS = 65% of "maximum"...
  • Page 38 8. FAT BURN The fat burn program might well be called challenge. There are twenty stages to choose from. Each stage corresponds to a different pattem of incline levels. The chart below shows stages and their corresponding workout levels. Dots indicate a repetition of this pattem.

  • Page 39: Guidelines For Exercise

    GUIDELINES FOR EXERCISE How hard should I exercise? Studies show that to achieve the benefits of aerobic exercise, it is necessary to work within your training zone. Your training zone depends on your age and level of fitness. The above chart indicates the recommended Heart Rate training zones (darkened area of the chart).

  • Page 40: User Parameter Setting

    USER PARAMETER SETTING User parameters determine basic operating features, such as distance units, of the treadmill. To change these parameters, at the banner display, hold the CHANGE DISPLAY button for three seconds. 1. Set up MPH/KPH. The 14-segment display will show the current status as either ＜...

  • Page 41: Maintenance

    MAINTENANCE Periodic maintenance is crucial to the performance of fitness equipment, just like it is to the performance of an automobile. The better you maintain a product, the longer it will serve your needs. This treadmill requires periodic lubrication of the walk belt and has a built-in system to prevent overuse without maintenance.
  • Page 42 1. Remove one treadmill end cap. ▲ ▼ 2. Simultaneously press and hold INCLINE + INCLINE + 0 keys for two seconds. The treadmill will operate at low speed. At this point, no UP or DN keys will operate. 3. Insert the applicator tube so the line on the applicator touches the side of the walk belt.
  • Page 43 6. Remove the applicator and the bottle of lubricant. 7. Secure the end cap on the treadmill. 8. Then the message "PLEASE PRESS THE STOP KEY AFTER FINISHING LUBRICATION" appears. Press the STOP key to complete the lubrication procedure. The treadmill will recalculate the total distance and operate normally.
  • Page 44 Lubricating When Not Prompted The physical task of lubricating the treadmill can be done at any time. When the startup ▲ banner, SPORTSART-T652, is displayed, simultaneously press and hold INCLINE ▼ INCLINE + 0 for two seconds. The motor will operate at low speed at which time you can apply lubricant to the walk belt.

  • Page 45: Error Messages

    ERROR MESSAGES 1. Display format: 2. Explanations for each error message: ERROR_1_1_ The AC servo motor encoder is out of order. Please re-start the unit. ERROR_1_2_ The AC servo motor is overheated. Speed is restricted to half. ERROR_1_3_ The AC servo motor is overloaded. Please re-start the unit. ERROR_2_1_ The IGBT current is too high.

  • Page 46: Wiring Schematic

    Wiring Schematic: Board CON2 CON4 CON1 CON3 CON7 *Option CON5 iPod decoder Board T652 CTL Board CON3 USB CHARGER BOARD CON6 CON2 DRV Board PWR Board DSP Board Encoder Incline SERVO Bridge Board MOTOR Switch CN10 CN2 CN3 HTR Board...
