Measurements

• Frequency range (analog): 4 Hz to 300 kHz (-3 dB)
• Crosstalk at 1 kHz: -95 dB (analog); -100 dB (digital)
• THD: 0.0008 % (analog 0 dBu); 0.0004 % (digital -1 dBfs)
• Noise (A-weighted): -105.1 dB (analog); -96.8 dB (digital)
• Dynamic range: 137.6 dB (analog); 120.8 dB (digital)

Internal Voltages

• Analog: +/- 60 V
• Digital: + 5 V und + 3.3 V

Power supply

• Mains voltage (switchable): 230 V AC / 50 Hz or 115 V AC / 60 Hz
• Power consumption: max. 40 VA
• Fuses: 230 V: T 500 mA; 115 V: T 1 A
• Standby power consumption: 0.7 W
