- Page 1 Keysight 87406Q Low PIM Coaxial Matrix Switch Operating and Service Manual...
- Page 3 Keysight 87406Q Operating and Service Manual...
-
Page 4: Safety Notices
Printed in Malaysia performance of this document or of any information contained herein. Keysight Technologies Sdn. Bhd. Should Keysight and the user have a Phase 3 Bayan Lepas Free Industrial Zone separate written agreement with WA R N I N G... -
Page 5: Weee Compliance
WEEE Directive Annex I, this product is classed as a "Monitoring and Control Instrumentation" product. Do not dispose in domestic household waste. To return unwanted products, contact your local Keysight office, or www.keysight.com for more information. Keysight 87406Q Operating and Service Manual... - Page 6 Contacting Keysight For more information, please contact your nearest Keysight office. Americas Canada (877) 894 4414 Brazil 55 11 3351 7010 Mexico 001 800 254 2440 United States (800) 829 4444 Asia Pacific Australia 1 800 629 485 China 800 810 0189...
-
Page 7: Table Of Contents
RF path selection Open all RF ports Electronic Position Indicators Specifications General Specifications Supplemental specifications (cold switching) Specifications Switch drive specifications RF specifications Environmental specifications Physical specifications Troubleshooting Installation and Verification Installation Initial inspection Keysight 87406Q Operating and Service Manual... - Page 8 Contents Operating and Service Instruction Operator’s check Performance test Service instructions Keysight 87406Q Operating and Service Manual...
-
Page 9: Introduction
Keysight 87406Q Low PIM Coaxial Matrix Switch Operating and Service Manual Introduction General Information 8 Key Features 9 This chapter provides an overview of the Keysight 87406Q Low PIM Coaxial Matrix Switch. -
Page 10: General Information
Introduction General Information The Keysight 87406Q terminated switch provides the life and reliability required for automated test and measurement and signal monitoring and routing applications. The switch can be used in various applications as it is available in multiple frequency ranges, up to 20 GHz. -
Page 11: Key Features
• Excellent isolation, typically > 100 dB at 20 GHz • PIM level (typical) of –165 dBc • Opto- electronic indicators and interrupts • Terminated ports • TTL/5 V CMOS compatibility (optional) Keysight 87406Q Operating and Service Manual... - Page 12 Introduction This page is intentionally left blank. Keysight 87406Q Operating and Service Manual...
-
Page 13: Switch Configuration
Keysight 87406Q Low PIM Coaxial Matrix Switch Operating and Service Manual Switch Configuration General Operation 12 Driving the Switch 14 DC power connection 14 RF path selection 15 Open all RF ports 16 Electronic Position Indicators 18 This chapter provides you information on how to drive the switch using standard drive and TTL drive. -
Page 14: General Operation
Switch Configuration General Operation The 87406Q matrix switch consists of six ports which can be individually connected via internal microwave switches to form an RF path (see Figure 2- 1). When control inputs are sent to the switch, the internal diode logic and position sensing circuitry routes current to the appropriate solenoids to close or open the microwave switches based on the input state. - Page 15 Switch Configuration Figure 2-1 Keysight 87406Q block diagram Keysight 87406Q Operating and Service Manual...
-
Page 16: Driving The Switch
After the RF path is switched and latched, the drive current is interrupted by the N O T E electronic position-sensing circuitry. Pulsed control is not necessary, but if implemented, the pulse width must be 15 ms minimum to ensure the switch is fully latched. Keysight 87406Q Operating and Service Manual... -
Page 17: Rf Path Selection
Switch Configuration RF path selection To connect any two RF ports, apply control signal to the corresponding drive pins as shown below. Table 2-1 Keysight 87406Q RF port drive pin control data (see Figure 3-5 for drive connection diagrams) RF port... -
Page 18: Open All Rf Ports
(Option 024) or TTL "High" (Option T24) to open all RF ports at power- up. Break-before-make Remove the control inputs from the undesired port, and then select the desired port. The internal logic will unselect the old port automatically upon application of the new port selection. Keysight 87406Q Operating and Service Manual... - Page 19 Select the new RF port while maintaining the control input on the original ports. Allow 15 ms for the switching action to be completed, and then unselect the original port; the original port will be automatically disconnected by the internal logic. Keysight 87406Q Operating and Service Manual...
-
Page 20: Electronic Position Indicators
“Environmental specifications” on page 24. The electronic position indicators require that the supply (20 to 32 VDC) be connected to pin 1 and ground connected to pin 15. Figure 2-2 Pin configuration for indicator function Keysight 87406Q Operating and Service Manual... -
Page 21: Specifications
Keysight 87406Q Low PIM Coaxial Matrix Switch Operating and Service Manual Specifications General Specifications 20 Supplemental specifications (cold switching) 21 Specifications 22 Switch drive specifications 22 Environmental specifications 24 Physical specifications 25 Troubleshooting 27 This chapter provides the specifications of the switch. -
Page 22: General Specifications
1 W average Into thru path Hot switching 2 W CW 100 W peak, 10 μs max pulse width, not to exceed 2 W average Cold switching “Supplemental specifications (cold switching)” Switching time 15 ms maximum Keysight 87406Q Operating and Service Manual... -
Page 23: Supplemental Specifications (Cold Switching)
• Sea level (0.88 derating at 15,000 feet) • Load VSWR < 1.2 (see Figure 3- 1 for derating above 1.2 VSWR) • Power handling at 25 °C is 100 W at 4 GHz Figure 3-1 Power derating factor vs. VSWR Keysight 87406Q Operating and Service Manual... -
Page 24: Specifications
[1] 200 mA is required for each RF port closed or opened. Using “open all ports” (pin 16) will require up to 1200 mA (six ports times 200 mA each). See “General Operation” on page Figure 3-2 TTL control voltage states (Option T24) Keysight 87406Q Operating and Service Manual... -
Page 25: Rf Specifications
1.21 maximum from DC to 4 GHz 1.35 maximum from 4 to 10 GHz 1.5 maximum from 10 to 15 GHz 1.7 maximum from 15 to 18 GHz 1.9 maximum from 18 to 20 GHz Keysight 87406Q Operating and Service Manual... -
Page 26: Environmental Specifications
Specifications Environmental specifications The low PIM switches are designed to fully comply with Keysight’s product operating environmental specifications. Parameter Specification Temperature –25 °C to 75 °C • Operating –55 °C to 85 °C • Storage –50 °C to 150 °C, 10 cycles •... -
Page 27: Physical Specifications
Specifications Physical specifications Parameter Specification Dimensions Figure 3-3 Weight 229 gm (0.50 lb) Figure 3-3 Product outline Keysight 87406Q Operating and Service Manual... - Page 28 Specifications Figure 3-4 Connector configuration Figure 3-5 Drive connection diagram Keysight 87406Q Operating and Service Manual...
-
Page 29: Troubleshooting
• Select line not at ground (std) • TTL “Low” voltage too high (Option T24) 2. Position indicators do not work • Supply not connected • Supply < 20 VDC • Pin 15 not connected to ground Keysight 87406Q Operating and Service Manual... - Page 30 Specifications This page is intentionally left blank. Keysight 87406Q Operating and Service Manual...
-
Page 31: Installation And Verification
Keysight 87406Q Low PIM Coaxial Matrix Switch Operating and Service Manual Installation and Verification Installation 30 Initial inspection 30 Operating and Service Instruction 31 Operator’s check 31 Performance test 32 Service instructions 32 This chapter provides you installation information and... -
Page 32: Installation
2 If the contents are incomplete, there is mechanical damage or defect, or the instrument does not pass the electrical performance test, contact the nearest Keysight Sales and Service office (refer to “Contacting Keysight” on page 4). Keysight will arrange for repair or replacement of the damaged or defective equipment. -
Page 33: Operating And Service Instruction
The S- parameter measurement is the best way to determine if the switch is working properly. NETWORK ANALYZER POWER SUPPLY Port 1 Port 2 Keysight Coaxial Transfer Switch Figure 4-1 Connection to perform quick check Keysight 87406Q Operating and Service Manual... -
Page 34: Performance Test
Service instructions Adjustment and repair Keysight 87406Q low PIM coaxial matrix switch does not require internal adjustments and are not recommended for repair. If any of the low PIM coaxial matrix switches fails within the warranty period, a N O T E new unit will be replaced. - Page 35 Option 100, T24 The above list of replacement units is not applicable as customer-orderable units. N O T E The list only applies for any low PIM coaxial matrix switch which fails within the warranty period. Keysight 87406Q Operating and Service Manual...
- Page 36 Installation and Verification This page is intentionally left blank. Keysight 87406Q Operating and Service Manual...
- Page 37 This information is subject to change without notice. © Keysight Technologies 2014 Edition 2, October 2014 *87406-80005* 87406-80005 www.keysight.com...
