Sandia 80-5000 Operation And Maintenance Manual

Hard surface extractor sniper 12-gallon 1200 psi hard surface extractor 1200 psi adjustable pump, dual motors
Hide thumbs

Advertisement

Quick Links

New Equipment Warranty
Limited Warranty
Sandia Products warrants new equipment against defects in material and
workmanship under normal use and service to the original purchaser. Any statutory
implied warranties, including any warranty of merchantability or fitness for a
particular purpose, are expressly limited to the duration of this written warranty.
Sandia Products will not be liable for any other damages, including but not limited
to indirect or special consequential damages arising out of or in connection with the
furnishing, performance, use or inability to use the machine. This remedy shall be the
exclusive remedy of the purchaser. The warranty period is subject to the conditions
stated below.
Lifetime Warranty on Body, 2-Years on Vacuum Motors, 1-Year on
Pump and all Electrical Parts, 90-Days on Tools and Accessories
Sandia Products warrants the roto-molded body to be free from defects in material
and workmanship, under normal use and service for a lifetime. Sandia Products
warrants the motors to be free from defects in material and workmanship, under
normal use and service for two (2) years from the original date of sale and the
pump/electrical parts one (1) year. Parts replaced or repaired under this warranty
are warranted for the remainder of the original warranty period. Service labor
charges are covered for one (1) year from the date of purchase, when performed by
a manufacturer-authorized service provider.
Labor is only provided by authorized service centers. If an authorized service
center is not near you, it is the purchaser's responsibility to take their machine to an
authorized service center.
Normal wear items such as capacitors, cords, finishes or switches will be warranted
for manufacturing defects for ninety (90) days from the purchase date.
All warranties of motors and associated components will be voided: if the machine
is serviced by anyone other than an authorized service provider; if the machine is
mechanically modified; if the machine is operated when not operating properly; or if
the machine is misused or abused.
The warranty starts on the purchase date by the original purchaser from Sandia
Products subject to proof of purchase. The Machine Registration Card must be
completed and returned immediately at the time of purchase. Registration may
also be performed online at: www.sandiaplastics.com/registration.aspx. If proof of
purchase cannot be identified, the warranty start date is ninety (90) days after the
inventory stocking date at the distributor's warehouse.
Ultimate Solutions Corporate Office
15571 Container Lane, Huntington Beach, CA 92649
Phone: 800-983-5834 | Fax: 714-901-8404
www.us-group.com | www.sandiaplastics.com
Make a copy of this card for future reference.
Copyright © 2016 Ultimate Solutions | Sandia Products. All Rights Reserved.
Safety, Operation and Maintenance
Manual with Parts List
Please read before use!
1200 PSI ADJUSTABLE PUMP, DUAL MOTORS
Model No. 80-5000
Important Information and Safety Instructions
Register your Machine Online or Return your Machine Warranty Card!
Serial No:
Copyright © 2016 Ultimate Solutions | Sandia Products
ACTIVATE
YOUR
WARRANTY!
Manufactured with
Pride in the U.S.A.
Another Innovative
Product from
