AD4D AD4D Dual Channel Receiver
Mic/Line Switch
30 dB pad
Phantom Power Protection
Yes
Dimensions
44 x 483 x 333 mm H x W x D
Weight
4.6 kg (10.1 lbs), without antennas
Housing
Steel; Extruded aluminum
Power Requirements
100 to 240 V AC, 50-60 Hz, 0.55 A max.
Thermal Power Dissipation
Maximum
Idle
DC Power Requirements
10.5 to 32V DC4 A max.
Network Interface
10/100 Mbps, 1Gbps, Dante Digital Audio
Network Addressing Capability
DHCP or Manual IP address
Maximum Cable Length
100 m (328 ft)
Cascade Output
Connector Type
BNC
2
Configuration
Unbalanced, passive
Impedance
50 Ω
Insertion Loss
0 dB, typical
RF Input
Spurious Rejection
>80 dB, typical
2
Note: For connection of one additional receiver in the same band
2017/08/03
23 W (78 BTU/hr)
15 W (51 BTU/hr)
