Above ground pool chlorination

Advertisement

ELECTROLYTIC CHLORINE GENERATOR

BASIC POOL MAINTENANCE REQUIREMENTS

TEST
IDEAL RANGE
Free Chlorine
1.0 - 3.0 ppm
pH
7.2 - 7.6
Alkalinity
80 - 120 ppm
Salt
2700 - 3400 ppm Add salt as required to increase.
Stabilizer
20 - 30 ppm
(if necessary)
Calcium
125 - 250 ppm
Electrolytic Cell inspect & clean
620 Division St.
Elizabeth, NJ 07207
ADJUSTMENT REQUIRED
Raise desired output % to
increase, lower desired output %
to decrease -OR- increase or
decrease pump filtration time.
Too high - add muriatic acid
Too low - add soda ash.
Add baking soda to increase.
Add acid as required to decrease.
Add cyanuric acid to increase.
Add calcium to increase.
Drain and add water to decrease.
Refer to section in manual.
092443A RevB
Copyright © 2010 Hayward
Aqua Trol
Above Ground Pool Chlorination
Operation and Installation
Manual
AQ-TROL-RJ-CUL
®
www.haywardnet.com
Canada: 888-238-POOL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Aqua Trol AQ-TROL-RJ-CUL and is the answer not in the manual?

Questions and answers

Summary of Contents for Hayward Aqua Trol AQ-TROL-RJ-CUL

  • Page 1 Add calcium to increase. Drain and add water to decrease. Electrolytic Cell inspect & clean Refer to section in manual. Operation and Installation Manual AQ-TROL-RJ-CUL www.haywardnet.com 620 Division St. 092443A RevB Elizabeth, NJ 07207 Canada: 888-238-POOL Copyright © 2010 Hayward...
  • Page 2 SwimPure chlorination products to be free of defects in materials and workmanship, under When using this electrical equipment, basic safety pre- normal use and service, for a period of three (3) years. Hayward/Goldline also warrants its Aqua Trol chlorination products to be free of defects in materials and workmanship, under cautions should always be followed, including the follow- normal use and service for a period of one (1) year.
  • Page 3 24 hours, whichever comes first. "Check Salt" LED illuminated or flashing Take a sample of your pool water to your local Authorized Aqua Rite Dealer Hayward OPERATION OPERATION OPERATION...
  • Page 4: Troubleshooting

    Bonding OPERATION Lugs used for bonding is attached to the bottom of the Aqua Trol enclosure. Connect to the pool bonding system using minimum 6AWG copper wire if required by code. The Aqua Trol ® is an automatic chlorine generation system for above ground pools. Electrolytic Cell The operation requires a low concentration of salt (sodium chloride) in the pool water Route the cell cable through the enclosure cutout and connect to the Aqua Trol.
  • Page 5 Plumbing Water Chemistry Unscrew the hose adaptor from the pool return jet fitting and, in its place, screw in the As with any pool, it is important that you maintain chemical makeup of the pool water. right-angle cell mounting adaptor. Note that this installation does NOT require a flow The table on page 2 summarizes the levels that are recommended by the National Spa switch--however it is very important that the cell be mounted vertically directly below and Pool Institute (NSPI).
  • Page 6 It is important to use only sodium chloride (NaCl) that is 99% pure. This is common food quality or water softener salt available in 40-80 lb. bags at your local Hayward dealer. It is also acceptable to use water conditioning salt pellets, however, it will take longer for them to dissolve.
  • Page 7 Servicing and Cleaning the Aqua Trol cell Turn off power to the Aqua Trol before removing the electrolytic cell. Once removed, look inside the cell and inspect for scale formation (light colored crusty or flaky deposits) on the plates and for any debris which has passed through the filter and caught on the plates.
  • Page 8 Controls Salt Display The pool filter pump should run long enough to circulate the entire volume of pool The Salt Display shows the current salt concentration of the pool water. Readings are water each day. This will vary depending on pump size, pool plumbing and pool size. in ppm (parts per million).
