SERVICE MANUAL
1-1 Technical Specification
Projection Panel
Lamp Type
Avg. Lamp Life in Hours
Noise Level
Projection Lens
Max. Weight (Unpacked)
Max. Dimensions (W*H*D)
Resolution
Max. Graphics Resolution
Displayable Colors
Power Source
Flash Upgrade
Input Terminal
Firmware
Martin 1-2
DMD 7" SVGA 800*600*1
Baseline is 1.0mm (minimum improved 1.3mm)
Brightness > 600 lumens
1500 hours for 1.3mm, 1000 hours minimum for 1.0 assume
use the same reflector as 1.3mm
Under 44dBA
Goal : 42dBA
3.3 feet - 35.64 feet; 1 meter - 10.8 meters
Under 4.5 lbs (without cables, handle and cap)
8*8.5*27 inches
800*600 (SVGA)
1024*768 compression
16.7 million colors
90 - 265 VAC, 50 - 60 Hz
RS232 to DFP adapter
One 15-pin D-type connector with one cable included,
one Digital FP connector with one cable included
Pixelworks 264 chip with USB, DVI, IR
Goal : 700 lumens
