  • Page 2 Notice 2000 Compaq Computer Corporation. Compaq, the Compaq logo, and Deskpro are registered in the U. S. Patent and Trademark Office. Microsoft, Windows, and Windows NT are registered trademarks and Visual C++ is a trademark of Microsoft Corporation in the United States and/or other countries.

  • Page 3: Table Of Contents

    Balancing the Projector...1-5 Connecting the Projector to a Portable Computer ...1-6 Connecting the Projector to a Desktop Computer ...1-7 Connecting the Projector to a Compaq PC Companion ...1-9 Connecting the Projector to Other Video Sources...1-10 Powering On the Projector ...1-11 Powering Off the Projector ...1-12...
  • Page 4 SING THE PTIONAL OMPAQ Identifying the Multimedia Adapter Components... 3-1 Attaching the Optional Multimedia Adapter to the Projector ... 3-3 Connecting a Camcorder, VCR, or DVD Player to the Optional Multimedia Adapter... 3-4 Connecting a Video Player... 3-6 Video On-Screen Menu Adjustments... 3-6 Explaining Functions in the Video On-Screen Menu...
  • Page 5 appendix A ROUBLESHOOTING Solving Display Problems...A-1 Solving Lamp Problems ...A-5 Solving Miscellaneous Problems ...A-6 appendix B GENCY EGULATORY Federal Communications Commission Notice...B-1 Modifications ...B-1 Cables...B-1 Declaration of Conformity for Products Marked with the FCC Logo—United States Only ...B-2 Canadian Notice...B-2 Avis Canadien ...B-2 European Notice...B-3 Japanese Notice...B-3...

  • Page 6: Using This Guide

    Using This Guide The User's Guide includes general information about your projector, troubleshooting and diagnostics, and technical specifications. Symbols and Conventions The following words and symbols mark special messages throughout this guide: WARNING: failure to follow directions could result in bodily harm or loss of life.

  • Page 7: Warning Messages

    Warning Messages Before operating the projector, please read the following messages. WARNING: To reduce the risk of harm to your eyes, do not look directly into the bright light of the projection lens. To reduce the risk of fire or electric shock, do not expose this product to rain or moisture.

  • Page 8: Getting Started

    16.7 million displayable colors Multilingual on-screen adjustment menu Plug and Play capability Flash ROM upgradeable Compaq Presentation utility for ease of use in setting up the projector with portable computers Compaq Projector Display Assistant utility to adjust screen settings Carrying case and projector carrying handle included...

  • Page 9: Introduction

    Introduction Before setting up your Compaq MP1400 Microportable Projector, be sure your shipping box includes the following items: Projector and lens cap 10-foot power cable Two signal cables One VGA signal cable for use with computers, portables, and some handheld products...

  • Page 10: Setting Up The Projector

    Compaq Projector Display Assistant utility, and a User’s Guide in ten languages If your shipping box does not contain all of the listed items, please contact your Compaq authorized dealer, reseller, or service provider. Setting Up the Projector To set up the projector, follow the instructions below and on the following pages.
  • Page 11 Do not place anything on power cords or cables. Arrange them so that no one may accidentally step on or trip over them. Do not pull on a cord or cable. When unplugging from the electrical outlet, grasp the cord by the plug. MP1400 Microportable Projector...

  • Page 12: Balancing The Projector

    Balancing the Projector The projector has a built-in elevator foot used to balance and elevate the projector. Always balance the projector before connecting anything to it. To balance the projector, turn the foot sideways. WARNING: To reduce the risk of the projector tipping or...

  • Page 13: Connecting The Projector To A Portable Computer

    Portable Computer 1. Rotate the elevator foot to balance the projector. 2. Connect one end of the projector signal cable to the projector and the other end to the VGA connector 1B or the DFP connector 1A on the portable computer and tighten the screws.

  • Page 14: Connecting The Projector To A Desktop Computer

    Connecting the Projector to a Desktop Computer 1. Rotate the elevator foot to balance the projector. 2. Connect one end of the projector signal cable 1B to the projector and the other end to the VGA connector on the desktop computer and tighten the screws.
  • Page 15 For security purposes, this projector has been fitted with a security lock slot 3 (located on the left, front side) for use with a security cable lock that can be purchased separately at most computer stores. MP1400 Microportable Projector...

  • Page 16: Connecting The Projector To A Compaq Pc Companion

    Compaq PC Companion. It is sold separately. For information on purchasing this card, call your Compaq authorized dealer, or reseller. To locate a reseller near you, call Compaq at 1- 800-AT-COMPAQ or visit the Compaq web site at http://www.compaq.com/products.

  • Page 17: Connecting The Projector To Other Video Sources

    VCR, for compatibility with the projectors. The optional Compaq Multimedia Adapter is not included with the Compaq MP1400 Microportable Projector. It is sold separately and includes a remote control. For information on purchasing the optional Multimedia Adapter and remote control, call your Compaq authorized dealer, or reseller.

  • Page 18: Powering On The Projector

    3. Turn on the Main power switch 2 on the back of the projector and allow the projector to warm up for one to two minutes. When the projector has warmed up, the Compaq startup screen displays, and the LED on the STANDBY button 3 turns green.

  • Page 19: Powering Off The Projector

    3. Disconnect the power cord from the electrical outlet and the projector. CAUTION: After the projector is turned off, wait at least one minute before turning the projector back on. Failure to follow this caution can result in damage to the projector.

  • Page 20: Adjusting The Projected Image

    Adjusting the projector height Adjusting the projector focus Adjusting the Projector Height This projector has a built-in elevator foot that can raise the projector approximately one inch. To adjust the height: 1. Ensure the foot is turned sideways to balance the projector.
  • Page 21 1 on the front of the projector to release the foot 2. 3. To lower the display angle, press the elevator button on the front of the projector again and press down on the projector to lower it. WARNING:...

  • Page 22: Adjusting The Projector Focus

    Adjusting the Projector Focus To focus the projected image, rotate the focus ring 1 until the image is clear. The projector will focus at distances from 3.3 feet to 35.64 feet (1 meter to 10.8 meters). If vertical bars appear on the display after adjusting the focus, press the Resync button 2 to automatically synchronize and track the display.

  • Page 23: Image Size Adjustment

    19.8" 26.3" 39.5" 52.7" 65.9" Height Projection 4.9' 6.6' Distance If the projector is used at the maximum distance indicated in this chart, the display may appear to be dimmer than usual. 1-16 105.5" 123.0" 140.6" 158.1" 175.8" 79.1" 9.8' 13.1'...

  • Page 24: Using The Compaq Presentation Utility

    The utility also disables the computer’s screen savers and auto-suspend feature. A graphical user interface (GUI) is required to control the MP1400 Projector’s resolution settings and the enabled/disabled status. The Compaq Presentation utility supports the following GUI operating systems: Microsoft Windows 95, Windows 98, Windows 2000, and Windows NT 4.0.

  • Page 25: Using The Compaq Projector Display Assistant

    The Compaq Projector Display Assistant utility included on the CD-ROM is an adjustment tool for improving the display quality of the MP1400 projector. Adjustments need to be made when the projector is first attached to a computer or when a different display mode is selected for the first time.

  • Page 26: Using The Projector

    Identifying the Projector Buttons Symbol Control Standby button and LED Select button MP1400 Microportable Projector Function Powers the projector lamp on and off. The Standby LED changes color to indicate the following operating modes: 1. Green glow indicates power is on.

  • Page 27: Introducing The On-Screen Menu

    Resync button IMPORTANT: To use standby mode, press the 6- to 10-second delay, the unit enters standby mode and the projector lamp turns off. A “Going to Standby” message appears on the screen for the duration of the 6- to 10-second delay. When the message disappears from the screen, there is a 45-second delay before the lamp can be turned back on.
  • Page 28 Reset Lamp Hours Flip Image Serial Number Master Reset Save and Return Cancel Factory Reset Confirm Reset Exit MP1400 Microportable Projector Adjustment scale Adjustment scale Adjustment scale Adjustment scale Adjustment scale Adjustment scale On-Off Display hours - 5 digits Confirmation...

  • Page 29: Adjusting The On-Screen Menus

    Adjusting the On-Screen Menus To launch and make adjustments to the on-screen menus: 1. Press the Select button 1 located on the projector panel or, if you are using the optional remote control, press the Menu button. The menu will display on the projection screen.

  • Page 30: Explaining Functions In The On-Screen Menu

    Explaining Functions in the On-Screen Menu Brightness and Contrast—Adjusts the displayed image brightness and contrast ranges from 0 to 100. An example of a standard setting is to set the contrast level to 67 and the brightness level to 50. MP1400 Microportable Projector...
  • Page 31 The current language is highlighted. Select another language in which to display all menu functions. Menu Location—Positions the on-screen menu at a convenient location on the projector screen; positions the menu up or down, left or right. MP1400 Microportable Projector...

  • Page 32: Special On-Screen Messages

    The following on-screen messages will appear on the projection display to identify the following conditions: Check Video Cable—Indicates the video cable may not be plugged into the projector or the selected video input is not accurate. Input Signal Out of Range—Indicates the projector is unable to access the appropriate input signal.
  • Page 33 When the optional Compaq Multimedia Adapter is attached to the projector, the following messages, in addition to the previous messages, will appear on the projection display to identify the following conditions: Analog, Use Source to change input — Indicates Analog and DVI inputs are both connected.

  • Page 34: Using The Optional Compaq Multimedia Adapter

    Chapter 3 Using the Optional Compaq Multimedia Adapter Identifying the Multimedia Adapter Components Item Component Infrared Receiver Speaker Volume S-Video connector 8-pin connector DVI connector Source button MP1400 Microportable Projector Function Interprets signals received from the remote control Provides audio performance...
  • Page 35 < Install buttons The optional Compaq Multimedia Adapter is not included with the Compaq MP1400 Microportable Projector. It is sold separately and includes an optional remote control. For information on purchasing the optional Multimedia Adapter and remote control, call your Compaq authorized dealer, or reseller.

  • Page 36: Attaching The Optional Multimedia Adapter To The Projector

    Multimedia Adapter. 2. Insert the hooks on top of the optional Multimedia Adapter into the upper slots 2 on the projector by inserting and pushing upward, then insert the adapter plug into the digital connector 3 on the back of the projector.

  • Page 37: Connecting A Camcorder, Vcr, Or Dvd Player To The Optional Multimedia Adapter

    Optional Multimedia Adapter A rubber boot cover protects the DFP (digital) connector on the projector. Be sure to remove the cover before connecting the Multimedia Adapter to the projector and replace the cover when the projector is not in use to prevent electrostatic discharges from damaging the connector.
  • Page 38 4. Press the Source button 5 on the Multimedia Adapter to toggle and select between the connected input sources. The optional Compaq Multimedia Adapter can remain attached to the projector, or it can be removed and stored in the carrying case. MP1400 Microportable Projector...

  • Page 39: Connecting A Video Player

    RCA video cable. If your video player uses a round, four-prong S-video connector, use the S-video cable. Both cables are included with the optional Compaq Multimedia Adapter. 1. Plug the RCA video cable into the video-out port on the video player and the video port on the video adapter.
  • Page 40 3. Set the Source button on the optional multimedia adapter or optional remote control to video. 4. Press the Select button on the projector or the Menu button on the optional remote control to display the following menu. Video Menu...

  • Page 41: Explaining Functions In The Video On-Screen Menu

    Audio—Adjusts the audio controls for the speaker on the multimedia adapter Source—Selects between composite, S-video, DVI, and analog input On-Off Display hours - 5 digits Confirmation Delay adjustment Horizontal - Vertical - Both Display Serial Number Confirmation MP1400 Microportable Projector...

  • Page 42: Using The Optional Remote Control

    Identifying the Remote Control Buttons Item Component Standby button SCE—Source button Laser Mouse ball MP1400 Microportable Projector Function Glows green when the remote is operating Powers the projector into and out of Standby mode Selects the input source Activates laser pointer for use in presentations 1.
  • Page 43 Adapter kit, which is sold separately. For information on purchasing the optional Compaq Multimedia Adapter kit, call your Compaq authorized dealer, or reseller. To locate a reseller, call Compaq at 1-800-AT-COMPAQ or, to buy directly from Compaq, visit the Compaq web site at http://www.compaq.com/products/projectors.

  • Page 44: Calibrating The Mouse

    To calibrate the mouse ball on the remote control: 1. Ensure that the projector, multimedia adapter, and remote control are powered on. 2. Press down on the top of the mouse ball and hold it down until it clicks, 3.

  • Page 45: Remote Control Functions

    Duplicates the functions of the projector buttons, including adjusting the on-screen menus Controls the computer connected to the projector by navigating through the computer directories, and opening and closing files IMPORTANT: To operate a computer using the remote control, an 8- pin to-USB/RS232- cable (included in the optional Multimedia Adapter kit) must be used.

  • Page 46: Picture-In-Picture On-Screen Menu Adjustments

    Picture-in-Picture On-Screen Menu Adjustments When the optional Multimedia Adapter is attached to the projector, a data source is connected, and the S-video and Composite connectors are attached to input sources, a second alternate Picture- in-Picture (PIP) on-screen menu displays on the projector screen.
  • Page 47 Adjustment scale On—Off Adjustment scale Adjustment scale Adjustment scale (Toggles 5 locations) Composite, S-Video Adjustment scale Adjustment scale On-Off Display hours - 5 digits Confirmation Delay adjustment Horizontal Vertical Both Save and Return Cancel Display Serial Number Confirmation MP1400 Microportable Projector...

  • Page 48: Explaining Functions In The Pip On-Screen Menu

    Audio—Adjusts the audio controls for the speaker on the multimedia adapter. Source—Selects between composite, S-video, DVI, and analog input. PIP—Turns PIP on/off; changes the PIP location on the projected image; and selects the input source. MP1400 Microportable Projector...

  • Page 49: Care And Maintenance

    Chapter 5 Care and Maintenance This chapter explains how to care for and maintain your Compaq projector during normal everyday use. Protecting the Projector To protect your projector from overheating and other types of damage, follow these suggestions: Use only a power source and connection appropriate for this projector as indicated on the marking label.
  • Page 50 Adjust only those controls that are covered by the operating instructions. If the projector is not operating properly or has been dropped or damaged, contact your Compaq authorized dealer, reseller, or service provider. MP1400 Microportable Projector...

  • Page 51: Cleaning The Lens

    The cloth can be contaminated if left in the open air or in a lab coat pocket. MP1400 Microportable Projector Do not spray any type of fluid or cleaner Do not store the cloth in contact with the lens...

  • Page 52: Replacing The Projector Lamp Module

    Replacement Suggested” displays on the projection screen, you should change the lamp as soon as possible. Contact your local Compaq authorized dealer, seller, or reseller to purchase a replacement lamp or have the lamp changed. To locate a reseller near you, call 1-800-AT-COMPAQ. To purchase the lamp directly from Compaq, visit the Compaq web site at http://www.Compaq.com/products/projectors.
  • Page 53 To replace the projector lamp module, follow these steps: 1. Turn off the power to the projector by pressing the Standby button 1. 2. Allow the projector to cool down for at least 30 minutes. WARNING: The lamp assembly operates at a very high temperature.
  • Page 54 IMPORTANT: This lamp contains < 0.125 percent mercury by weight. If the projection lamp breaks, the mercury may be released into the atmosphere. Please follow applicable federal, state, and local regulations for disposal and/or recycling. MP1400 Microportable Projector...

  • Page 55: Troubleshooting

    6. Ensure the pins on the connectors are not crooked or broken. 7. Turn off or disable the portable or desktop computer screen saver function. Compaq recommends installing the Compaq Presentation Utility to disable computer screen savers. 8. Ensure the projection lamp has been securely installed.
  • Page 56 Portable computer: A-2 Troubleshooting Continued) 1. Press the Resync button on the projector panel. 2. Turn everything off; first power on the portable or desktop computer, then power on the projector. 3. If the above steps do not correct...
  • Page 57 Monitors. Press the Resync button on the projector panel to adjust the tracking. If that doesn't stop the flickering, adjust the Clock Phase function in the on-screen menu.
  • Page 58 Projected colors do not match computer or camcorder color Black or gray border visible outside the usable area of the projection screen Only the Compaq startup screen displays Blue screen displays on the projection screen when a VCR is connected to the projector...

  • Page 59: Solving Lamp Problems

    For information on purchasing a replacement lamp module, call your Compaq authorized dealer, seller, or reseller. To locate a reseller near you, call 1-800-AT-COMPAQ. To purchase directly from Compaq, visit the Compaq web site at http://www.compaq.com/products/...

  • Page 60: Solving Miscellaneous Problems

    Multimedia Adapter and the computer. Upgrade the projector ROM using the Flash ROM download kit included in the Compaq MP1400 Microportable Projector’s packing box. For more information, refer to Appendix C, “Flash ROM Upgrade.” If this does not resolve the problem,...

  • Page 61: Agency Regulatory Notices

    Modifications The FCC requires the user to be notified that if any changes or modifications are made to this device, not expressly approved by Compaq Computer Corporation, this may void the user’s authority to operate the equipment. Cables Connections to this device must be made with shielded cables with metallic RFI/EMI connector hoods to maintain compliance with FCC Rules and Regulations.

  • Page 62: Declaration Of Conformity For Products Marked With The Fcc Logo-United States Only

    For questions regarding your product, contact: Compaq Computer Corporation P.O. Box 692000, Mail Stop 530113 Houston, Texas 77269-2000 Or, call 1-800-652-6672 (1-800-OK COMPAQ) For questions regarding this FCC declaration, contact: Compaq Computer Corporation P.O. Box 692000, Mail Stop 510101 Houston, Texas 77269-2000...

  • Page 63: European Notice

    European Notice Products with the CE Marking comply with both the EMC Directive (89/336/EEC) and the Low Voltage Directive (73/23/EEC) issued by the Commission of the European Community. Compliance with these directives implies conformity to the following European norms: EN55022 (CISPR 22) - Radio Frequency Interference EN50082-1 (IEC801-2, IEC801-3, IEC801-4) - Electromagnetic Immunity EN60950 (IEC950) - Product Safety...

  • Page 64: Specifications

    Specifications Compaq MP1400 Microportable Projector Projection Panel Lamp Type Image Size Avg. Lamp Life in Hours Projection Distance Maximum Weight (Unpacked) Maximum Dimensions W × H × D Maximum Graphics Resolution Displayable Colors Horizontal Frequencies Analog signals Digital signals Vertical Frequencies...

  • Page 65: Preset Display Resolutions Table

    Preset Display Resolutions Table This projector automatically recognizes the preset display resolutions listed in the following table. Preset Modes 1. Industry Standard 2. VESA Standard 3. Industry Standard 4. Industry Standard 5. VESA Standard 6. VESA Standard 7. Industry Standard 8.

  • Page 66: Power Cords

    6 feet (1.8 m) and 12 feet (3.6 m). If you have questions about the type of power cord to use, contact your Compaq authorized service provider. A power cord should be routed so that it is not likely to be walked on or pinched by items placed upon it or against it.

  • Page 67: Flash Rom Upgrade

    The Flash ROM upgrade provides the following functions: Implements new features on the projector. Provides upgrades to existing features. Resolves compatibility issues. First, locate the following items in the Compaq MP1400 Microportable Projector shipping box: DFP to DVI cable RS232 to DVI upgrade adapter To upgrade the projector’s ROM, complete the following steps:...
  • Page 68 3. Power on the computer and monitor only. Access the Compaq Web site at http://www.Compaq.com/Support. 5. Follow the steps outlined on the Web site. 6. Power on the projector. 7. Wait about two minutes to allow the Flash Upgrade program to complete the upgrade, then the projector will automatically reset and be ready to use.
  • Page 69 elcome to Using this Guide     Go to Using this Guide (this section) Previous Page Next Page Click a subject in the bookmarks on the left side of the screen to jump to that subject. Click any blue text to jump to information on that topic.
