640 COMP CART
19
1
10
9
13
14
15
16
2
5
3
43
18
17
11
12
13
21
7
8
4
6

Pre-Grill Checklist/Routine Maintenance

Perform the following services prior to each cooking session when the grill is cool
1. Open the cooking chamber door and remove the cooking grates.
2. Remove the heat diff user/drip plate, remove and discard previously used protective foil cover (if foil
has been applied). Install a new layer of protective foil. Select heavy duty foil that is wide enough to wrap
around the edges of the diff user plate and cut long enough to cover the entire plate. Install the foil from
left to right and fold over all four sides. Be sure the foil folded over the right hand edge is not hanging
over the front edge (no more than 1").
FIG 9
FIG 10
