YS480/YS640 Built-in

valance assembly

B E F O R E Y O U G E T S T A R T E D

Begin by confirming all the parts included in this kit are accounted for in this kit. Should

any items be missing, please contact Customer Service for assistance at 877.409.6337 or

customerservice@yodersmokers.com.

PARTS INCLUDED

( 2 ) Valance Face Panels

( 2 ) Valance Side Panels

( 4 ) 1/4" Nuts ( 16 ) 1/4" Screws

t o o l s y o u ' l l n e e d

7/16" Socket Wrench | 7/16" Socket | 7/16" Wrench | 5/32" Hex Key

SOCKET WRENCH

7/16" SOCKET

5/32" HEX KEY

7/16" WRENCH

Need help?

Do you have a question about the YS480 and is the answer not in the manual?

Page 1 YS480/YS640 Built-in valance assembly B E F O R E Y O U G E T S T A R T E D Begin by confirming all the parts included in this kit are accounted for in this kit. Should any items be missing, please contact Customer Service for assistance at 877.409.6337 or...
Page 2 ASSEMBLING THE VALANCE FOR INSTALLATION step 01 Attach the front panel (labeled 1) to side panel (labeled 2) using four screws provided, then repeat with the back panel and remaining side panel.
Page 3 ATTACHING THE VALANCE TO THE COOKER step 02 Install the assembled valance onto the cooker using the provided screws and nuts by attaching to the leg posts of the cooker as shown below.
Page 4 THIS COMPLETES THE HARDWARE INSTALL FOR PRODUCT SUPPORT: CustomerService@YoderSmokers.com 877.409.6337 (OPTION 2)
