Door Open Function

When the cooker has been in maintenance for more than 10 minutes and the cooker loses more than 15
degrees, the program interpretes that the cooking chamber door has been opened. When this happens,
there is a specifi c piece of programming that is executed to speed recovery back to the set point.

Prime Button

The prime button overrides the program altogether and turns the auger continuously, feeding pellets as
long as the button is depressed. This is valuable anytime you have had the door open for a long time and
have lost signifi cant temperature or if you want to raise the cooker temperature from say 250 to 350° F.
To use this function, press and hold the prime button on for 60 seconds, then let off for 60 seconds. You
may repeat this twice allowing at least 2 minutes before repeating.
15
640 COMP CART
ITEM # PART #
1 A90491 YS, PELLET, CHAMBER ASSEMBLY, 640
2 W90551 YS, WELDMENT, 640 COMP CART, BASE
3 90725 YS, CASTER, FLATFREE TIRE, 8" DIA., RIGID, MARATHON
4 90724 YS, CASTER, FLATFREE TIRE, 8" DIA., SWIVEL/LOCK, MARATHON
5 W90531 YS, WELDMENT, TIE-DOWN, UNDERCARRAIGE, 640
6 3816X1WHB BOLT, WHIZ, 3/8-16 X 1" LONG
7 23867 WASHER, PHENOLIC, 3/8"
8 3816LNN NUT, NYLOCK, 3/8-16
9 90527 YS, SIGN, COMP CART BASE, YODER SMOKERS LOGO
10 1420X12BHCSSS 1/4-20 X 1/2" BUTTON HEAD CAP SCREW, STAINLESS STEEL
11 1420X1WHB BOLT, WHIZ, 1/4-20 X 1" LONG
12 23866 WASHER, PHENOLIC, 5/16"
13 1420LNN NUT, NYLOCK, 1/4-20
14 91434 YS, HARNESS, WIRING EXTENSION W/RCPT, COMP CART
15 632X38MS SCREW, MACHINE, ROUND HEAD, 6-32 X 3/8" LONG
16 632HN NUT, HEX, 6-32
17 A90535 YS, ASSEMBLY, FRONT SHELF, 640, STAINLESS
18 A90511 YS, ASSEMBLY, SIDE SHELF, 640, STAINLESS
19 W90348 YS, WELDMENT, 2ND SHELF, 640 PELLET
20 90460 BUCKET, GALVANIZED, 1-1/4 QT
21 24117 EDGE TRIM, ADHESIVE, 1/4" OUTSIDE WIDTH, NC02-05
22 91435 FUSE, 250V, 1.6A, 5X20MM, LITTLEFUSE #021701.6HXP
DESCRIPTION
44
QTY.
1
1
2
2
1
20
4
20
2
8
8
8
16
1
2
2
1
1
1
1
6 LF
1
