DISHWASHING MACHINE
JP-24BPNSU
TECHNICAL MANUAL
460 VOLT - 60 HERTZ - 3 PHASE
HIGH TEMPERATURE SANITIZING
UNDERCOUNTER UNIT
DESCRIPTION, OPERATION, INSTALLATION
AND MAINTENANCE INSTRUCTIONS
Visit Jackson on the Internet at:
www.jacksonmsc.com
June 22, 2000
P/N 7610-002-38-50
