A.3.7 Internal SCSI Connector
AMP Inc. Part No. 786555-7
Pin
1
2
3
1 35
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
34 68
27
28
29
30
31
32
33
34
SCSI Internal Connector (Channel A) Pinouts
TABLE A-18
Signal Name
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
TERMPWRA
TERMPWRA
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
Appendix A
Pin Signal Name
35 SCSI_AC_DAT<12>
36 SCSI_AC_DAT<13>
37 SCSI_AC_DAT<14>
38 SCSI_AC_DAT<15>
39 SCSI_AC_PAR<1>
40 SCSI_AC_DAT<0>
41 SCSI_AC_DAT<1>
42 SCSI_AC_DAT<2>
43 SCSI_AC_DAT<3>
44 SCSI_AC_DAT<4>
45 SCSI_AC_DAT<5>
46 SCSI_AC_DAT<6>
47 SCSI_AC_DAT<7>
48 SCSI_AC_PAR<0>
49 GND
50 GND
51 TERMPWRA
52 TERMPWRA
53 GND
54 GND
55 SCSI_AC_ATN_L
56 GND
57 SCSI_AC_BSY_L
58 SCSI_AC_ACK_L
59 SCSI_AC_RST_L
60 SCSI_AC_MSG_L
61 SCSI_AC_SEL_L
62 SCSI_AC_CD_L
63 SCSI_AC_REQ_L
64 SCSI_AC_IO_L
65 SCSI_AC_DAT<8>
66 SCSI_AC_DAT<9>
67 SCSI_AC_DAT<10>
68 SCSI_AC_DAT<11>
Jumpers, Headers, Connectors, and Adapters
J1001
A-19
