USER MANUAL
NI SMD-7613/7614/7615/7616
This manual contains information about the configuration and use of the National
Instruments SMD-7613, SMD-7614, SMD-7615, and SMD-7616. They are referred to
inclusively in this manual as the NI SMD-761x.
This manual is not applicable for NI SMD-7610/7611/7612 devices. Refer to
Note
to the unique documentation for information related to the NI SMD-7610/7611/7612.
Functionality on these devices are roughly equivalent. The NI SMD-7613/7615 operates from
18 to 53 VDC, and has a running current of up to 5 A per phase. The SMD-7614/7616 operates
from 18 to 88 VDC, and runs current up to 10 A per phase. The SMD-7615/7616 features
encoder feedback.
Contents
Safety Information .................................................................................................................... 2
Block Diagram.......................................................................................................................... 3
Getting Started .......................................................................................................................... 4
Mounting the Drive .................................................................................................................. 4
Connecting the Power Supply .................................................................................................. 5
Choosing a Power Supply......................................................................................................... 5
Voltage.............................................................................................................................. 5
Current .............................................................................................................................. 6
Regeneration..................................................................................................................... 7
Connecting the Drive Using Ethernet....................................................................................... 7
Motor Wiring Recommendations ............................................................................................. 12
Four Lead Motors ............................................................................................................. 13
Six Lead Motors ............................................................................................................... 13
Eight Lead Motors ............................................................................................................ 14
Connecting Input Signals.......................................................................................................... 15
STEP and DIR Inputs ....................................................................................................... 17
Single Ended Inputs.......................................................................................................... 19
Connecting Limit Switches and Sensors .......................................................................... 21
Analog Inputs ................................................................................................................... 22
Programmable Outputs ............................................................................................................. 23
Connecting an Encoder (SMD-7615/7616) .............................................................................. 25
Configuring the Drive............................................................................................................... 28
Motor ................................................................................................................................ 28
Control .............................................................................................................................. 29
I/O Configuration ............................................................................................................. 31
Self Test............................................................................................................................ 31
Advertisement
Table of Contents
Related Manuals for National Instruments NI SMD-7613
Summary of Contents for National Instruments NI SMD-7613
-
Page 1: Table Of Contents
NI SMD-7610/7611/7612. Functionality on these devices are roughly equivalent. The NI SMD-7613/7615 operates from 18 to 53 VDC, and has a running current of up to 5 A per phase. The SMD-7614/7616 operates from 18 to 88 VDC, and runs current up to 10 A per phase. -
Page 2: Safety Information
In operation, depending on the degree of enclosure protection, the product can have bare components that are live or have hot surfaces. Control and power cables can carry a high voltage even when the motor is not rotating. 2 | ni.com | NI SMD-7613/7614/7615/7616 User Manual... -
Page 3: Block Diagram
INPUT X4 INPUT X5 MOSFET INPUT X6 Optical Power X7/CWLIM Isolation Motor Amplifier X8/CCWLIM OUTPUT Y1 OUTPUT Y2 Encoder OUTPUT Y3 OUTPUT Y4 7615/7616 Only ANALOG IN1 Ethernet ANALOG IN2 NI SMD-7613/7614/7615/7616 User Manual | © National Instruments | 3... -
Page 4: Getting Started
The connectors are illustrated below. These are detailed later in the manual. Figure 2 shows an overview of the connectors on the NI SMD-7613/7614/7615/7616 stepper drive. Figure 2. NI SMD-7613/7614/7615/7616 Stepper Drive Connectors... -
Page 5: Connecting The Power Supply
You must decide what size of power supply (in terms of voltage and current) is needed for your application. National Instruments offers two power supplies that are excellent matches for the NI SMD-761x drives: PS-12 24V, 6.3A) and PS-13 (48V, 6.7A). -
Page 6: Current
ST11-2 15.0 1.08 ST14-1 26.0 1.87 ST17-1 31.4 2.26 ST17-2 51.0 3.67 ST17-3 62.8 4.52 ST23-1 76.6 5.52 ST23-4 12.7 ST23-6 19.0 ST23-8 25.48 ST24-1 123.2 8.87 3.36 0.73 ST24-2 12.74 0.43 6 | ni.com | NI SMD-7613/7614/7615/7616 User Manual... -
Page 7: Regeneration
Physically connect the device to your network (or directly to the PC). Set the drive IP address. Set the appropriate networking properties on your PC. NI SMD-7613/7614/7615/7616 User Manual | © National Instruments | 7... - Page 8 On the device switch settings 1 through E use the standard class B subnet mask (i.e., 255.255.0.0). The mask for the universal recovery address is the standard class A (i.e., 255.0.0.0). 8 | ni.com | NI SMD-7613/7614/7615/7616 User Manual...
- Page 9 DHCP server. Cancel this dialog and proceed to the Using DHCP section. If the option Use the following IP address is selected, change the subnet mask to and click OK. 255.255.0.0 NI SMD-7613/7614/7615/7616 User Manual | © National Instruments | 9...
- Page 10 To set the IP address of your PC: Open Control Panel. From the icon view, open Network (Windows 8.1/8/7/Vista) and Sharing Center, then click Change Adapter Settings. Right-click My Network Places and select Properties. (Windows XP) 10 | ni.com | NI SMD-7613/7614/7615/7616 User Manual...
- Page 11 Because you are connected directly to the device, anytime the device is not Note powered you will receive a small message bubble in the corner of your screen saying “The network cable is unplugged.” NI SMD-7613/7614/7615/7616 User Manual | © National Instruments | 11...
-
Page 12: Motor Wiring Recommendations
Ensure any shield or grounding strap on the motor is connected to the chassis Note ground screw located near the motor/power connector. Figure 5. Motor/Power Connector Figure 6. Grounding Screw on the Chassis 12 | ni.com | NI SMD-7613/7614/7615/7616 User Manual... -
Page 13: Four Lead Motors
30% less than the rated current to prevent overheating. Refer to the wiring diagrams below to connect a six lead motor. Figure 8. Six Lead Motor Connected in Series Red/Wht Phase B+ Black No connect Phase B– NI SMD-7613/7614/7615/7616 User Manual | © National Instruments | 13... -
Page 14: Eight Lead Motors
30% less than the rated current to prevent overheating. Refer to the wiring diagrams below to connect an eight lead motor. Figure 10. Eight Lead Motor Connected in Series Phase B+ Red/Wht Yel/Wht Phase B– Yellow 14 | ni.com | NI SMD-7613/7614/7615/7616 User Manual... -
Page 15: Connecting Input Signals
These drives can use input signals from a motion controller or accept ethernet Note streaming commands. For more information on commanding the drive using Ethernet, see the Working with Ethernet Steppers page in SoftMotion help. NI SMD-7613/7614/7615/7616 User Manual | © National Instruments | 15... - Page 16 Y COMMON X6/CCWJOG Y3/FAULT Y2/MOTION ANALOG IN2 Y1/BRAKE ANALOG IN1 Figure 13. ISelect Internal Circuitry of the I/O Connector XCOM 2200Ω X3/EN 2200Ω x4/RST 2200Ω 2200Ω X7/CWLIM+ 2200Ω X7/CWLIM– X8/CCWLIM+ 2200Ω X8/CCWLIM- 16 | ni.com | NI SMD-7613/7614/7615/7616 User Manual...
-
Page 17: Step And Dir Inputs
IN/OUT 1 Sinking Outputs X1/STEP+ STEP X1/STEP– Figure 16. Connecting to Indexer with Differential Outputs DIR+ X2/DIR+ Indexer DIR– X2/DIR– with IN/OUT 1 Differential STEP+ X1/STEP+ Outputs STEP- X1/STEP– NI SMD-7613/7614/7615/7616 User Manual | © National Instruments | 17... - Page 18 Caution input terminal. Connect the resistors according to the following diagrams: Figure 18. Connecting to the controller with Sourcing (PNP) Outputs +12-24V X2/DIR+ OUT1 with X1/STEP– 761x Sourcing Outputs X1/STEP+ OUT2 X2/DIR– 18 | ni.com | NI SMD-7613/7614/7615/7616 User Manual...
-
Page 19: Single Ended Inputs
(PNP) signals, connect COM to the negative terminal of the power supply. When using sinking (NPN) signals, connect COM to the positive terminal of the power supply. NI SMD-7613/7614/7615/7616 User Manual | © National Instruments | 19... - Page 20 12-24 VDC Power Supply – OUT+ XCOM Drive IN/OUT1 OUT– X3..X6 Figure 23. Connecting an NPN Type Proximity Sensor to an Input XCOM 12-24 VDC Proximity Output Power Drive X3..X6 Sensor Supply 20 | ni.com | NI SMD-7613/7614/7615/7616 User Manual...
-
Page 21: Connecting Limit Switches And Sensors
Refer to the following diagrams for help connecting limit switches and sensors: Figure 25. Wiring a Mechanical Limit Switch CWLIMIT+ CCWLIMIT+ 12-24 VDC Power Drive CWLIMIT– Supply CCWLIMIT– – NI SMD-7613/7614/7615/7616 User Manual | © National Instruments | 21... -
Page 22: Analog Inputs
The following figure represents the internal circuitry of the analog inputs: Figure 28. Internal Circuitry of Analog Inputs Signal AIN1 Conditioning Signal AIN2 Conditioning Use the NI Stepper Configuration Utility to configure settings such as signal range, offset, deadband, and filter frequency. 22 | ni.com | NI SMD-7613/7614/7615/7616 User Manual... -
Page 23: Programmable Outputs
The current through an output terminal must not exceed 100 mA. Caution Figure 30. Sinking Output Using Y1, Y2, or Y3 Load Y1/2/3 5-24 VDC Power IN/OUT1 Supply – YCOM NI SMD-7613/7614/7615/7616 User Manual | © National Instruments | 23... - Page 24 Y4 – Figure 32. Sourcing Output Using Y1, Y2, or Y3 5-24 VDC Power Supply – IN/OUT1 Y1/2/3 YCOM Figure 33. Sourcing Output Using Y4 5-24 VDC Power Supply – IN/OUT1 Y4– 24 | ni.com | NI SMD-7613/7614/7615/7616 User Manual...
-
Page 25: Connecting An Encoder (Smd-7615/7616)
If your encoder is single ended, connect the encoder outputs to the A+, B+ and Z+ inputs. Leave A-, B- and Z- unconnected. (Z is the encoder index signal and is optional.) Figure 36. Encoder Connection Pin Numbering NI SMD-7613/7614/7615/7616 User Manual | © National Instruments | 25... - Page 26 Table 3. Encoder Connection Pin Definition Function Encoder A+ Encoder A- Encoder B+ Encoder B- Encoder Z+ Encoder Z- +5 VDC, 200 mA No Connect No Connect No Connect No Connect No Connect No Connect Shield 26 | ni.com | NI SMD-7613/7614/7615/7616 User Manual...
- Page 27 The internal circuitry of the encoder connection is depicted below: Figure 37. Encoder Connection Pin Numbering A– B– Z– NI SMD-7613/7614/7615/7616 User Manual | © National Instruments | 27...
-
Page 28: Configuring The Drive
If you operate the motor at 90% of rated current, the motor provides 90% of the rated torque and approximately 81% as much heat. At 70% current, the torque is reduced to 70% and the heating to about 50%. 28 | ni.com | NI SMD-7613/7614/7615/7616 User Manual... -
Page 29: Control
If the Steps/Rev setting is 2,000 or higher, this feature is not needed and can be set to the highest possible value, 2,500. NI SMD-7613/7614/7615/7616 User Manual | © National Instruments | 29... - Page 30 Your maximum pulse rate equals the highest motor speed multiplied by the number of steps per revolution. For example: revs steps × 20 000 ------------------ - --------------- - revs Consider the maximum pulse rate when deciding whether you must increase the filter frequency. 30 | ni.com | NI SMD-7613/7614/7615/7616 User Manual...
-
Page 31: I/O Configuration
If you are having trouble getting your motor to turn, use the built-in self test from the NI Stepper Configuration Utility home page. Select the Drive menu item and choose Self Test. Use this feature to confirm that the motor is wired correctly, selected, and otherwise operational. NI SMD-7613/7614/7615/7616 User Manual | © National Instruments | 31... -
Page 32: Torque Speed Curves
Figure 43. SMD-761x Torque Curve for ST17, 24 V Power Supply ST17 24 VDC Power Supply, 20000 Steps/Rev, All Motors Connected in Parallel ST17-3 (2.0 A/Phase) ST17-2 (2.0 A/Phase) ST17-1 (1.6 A/Phase) Rev/Sec 32 | ni.com | NI SMD-7613/7614/7615/7616 User Manual... - Page 33 Figure 45. SMD-761x Torque Curve for ST23, 24V Power Supply ST23 24 VDC Power Supply, 20000 Steps/Rev, All Motors Connected in Parallel ST23-8 (6.0 A/Phase) ST23-6 (5.0 A/Phase) ST23-4 (5.0 A/Phase) ST23-1 (3.4 A/Phase) Rev/Sec NI SMD-7613/7614/7615/7616 User Manual | © National Instruments | 33...
- Page 34 ST23-4 (5.0 A/Phase) ST23-1 (3.4 A/Phase) Rev/Sec Figure 47. SMD-761x Torque Curve for ST24, 24V Power Supply ST24 24 VDC Power Supply, 20000 Steps/Rev ST24-3 (4.80 A/Phase) ST24-2 (4.80 A/Phase) ST24-1 (3.36 A/Phase) Rev/Sec 34 | ni.com | NI SMD-7613/7614/7615/7616 User Manual...
- Page 35 Figure 49. SMD-7614/7616 Torque Curve for ST34-2/5/8, 48V Power Supply ST34-2/5/8 with SMD-7614/7616 24 VDC Power Supply, 20000 Steps/Rev, All Motors Connected in Parallel 1400 ST34-8 (10 A/Phase) 1200 ST34-5 (9.7 A/Phase) ST34-2 (10 A/Phase) 1000 Rev/Sec NI SMD-7613/7614/7615/7616 User Manual | © National Instruments | 35...
- Page 36 Figure 51. SMD-7614/7616 Torque Curve for ST34-2/5/8, 80V Power Supply ST34-2/5/8 with SMD-7614/7616 80 VDC Power Supply, 20000 Steps/Rev, All Motors Connected in Parallel 1400 ST34-8 (10 A/Phase) 1200 ST34-5 (9.7 A/Phase) ST34-2 (10 A/Phase) 1000 Rev/Sec 36 | ni.com | NI SMD-7613/7614/7615/7616 User Manual...
- Page 37 Figure 53. SMD-7614/7616 Torque Curve for ST34-1/4/7, 48V Power Supply ST34-1/4/7 with SMD-7614/7616 48 VDC Power Supply, 20000 Steps/Rev, All Motors Connected in Parallel 1000 ST34-7 (6.72 A/Phase) ST34-4 (7.56 A/Phase) ST34-1 (7.56 A/Phase) Rev/Sec NI SMD-7613/7614/7615/7616 User Manual | © National Instruments | 37...
-
Page 38: Motor Heating
Our measurements were made in a 40 °C (104 °F) environment with the motor mounted to an aluminum plate sized to provide a surface area consistent with the motor power dissipation. Your results may vary. 38 | ni.com | NI SMD-7613/7614/7615/7616 User Manual... - Page 39 Figure 55. Duty Cycle for the ST17-1 with the SMD-761x, 24 VDC ST14-1 Max Duty Cycle vs Speed 24 VDC, 1.2A, 40°C Ambient Mounted on 4.75" x 4.75" x .25" Aluminum Plate Speed (RPS) NI SMD-7613/7614/7615/7616 User Manual | © National Instruments | 39...
- Page 40 Figure 57. Duty Cycle for the ST17-2 with the SMD-761x, 48 VDC ST17-2 Max Duty Cycle vs Speed 48 VDC, 2.0 Amps 40°C Ambient on 4.75 x 4.75 x .25 Aluminum Plate Speed (RPS) 40 | ni.com | NI SMD-7613/7614/7615/7616 User Manual...
- Page 41 Figure 59. Duty Cycle for the ST23-1 with the SMD-761x, 48 VDC ST23-1 Max Duty Cycle vs Speed 48 VDC, 3.4 Amps, 40°C Ambient on 6.4 x 6.4 x .25 Aluminum Plate Speed (RPS) NI SMD-7613/7614/7615/7616 User Manual | © National Instruments | 41...
- Page 42 Figure 61. Duty Cycle for the ST23-4 with the SMD-761x, 48 VDC ST23-4 Max Duty Cycle vs Speed 48VDC, 5.0A, 40°C Ambient on 6.4 x 6.4 x .25 Aluminum Plate Speed (RPS) 42 | ni.com | NI SMD-7613/7614/7615/7616 User Manual...
- Page 43 Figure 63. Duty Cycle for the ST23-6 with the SMD-761x, 48 VDC ST23-6 Max Duty Cycle vs Speed 48 VDC, 5.0 Amps 40°C Ambient on 6.4 x 6.4 x .25 Aluminum Plate Speed (RPS) NI SMD-7613/7614/7615/7616 User Manual | © National Instruments | 43...
- Page 44 Figure 65. Duty Cycle for the ST34-2 with the SMD-761x, 80 VDC ST34-2 Max Duty Cycle vs Speed 80 VDC, 10.0 Amps 40°C Ambient on 10 x 10 x .5 Aluminum Plate Speed (RPS) 44 | ni.com | NI SMD-7613/7614/7615/7616 User Manual...
- Page 45 Figure 67. Duty Cycle for the ST34-5 with the SMD-761x, 80 VDC ST34-5 Max Duty Cycle vs Speed 80 VDC, 10.0 Amps 40°C Ambient on 10 x 10 x .5 Aluminum Plate Speed (RPS) NI SMD-7613/7614/7615/7616 User Manual | © National Instruments | 45...
-
Page 46: Drive Heating
Speed (RPS) Drive Heating While NI SMD-7613/7614/7615/7616 devices efficiently transmit power between the power supply and motor, they do generate some heat in the process. This will cause the temperature of the drive to rise above the surrounding air temperature and may also require that the drive be mounted to a heat conducting metal surface. - Page 47 = 1.0 °C/W θ Narrow side of drive mounted on a non-heat conducting surface: R = 2.1 °C/W θ Figure 70. Drive Thermal Losses SMD-7611/7612 Drive Losses Motor Current (A) NI SMD-7613/7614/7615/7616 User Manual | © National Instruments | 47...
-
Page 48: Mechanical Outline
SMD-7613/7615 Supply voltage ........12 to 53 VDC Motor current ........0.1 to 5.0 A/phase peak of sine SMD-7614/7616 Supply voltage ........18 to 88 VDC Motor current ........0.5 to 10.0 A/phase peak of sine 48 | ni.com | NI SMD-7613/7614/7615/7616 User Manual... - Page 49 Operating temperature range ......0 °C to 40 °C Mating connectors Motor/power supply ......... Phoenix Contact 1757051 (included) IN/OUT1........... DB-25 male (included) Encoder feedback ........HD-15 male Accessories Regeneration clamp ........NI SMD-7700, NI part number 748908-01 NI SMD-7613/7614/7615/7616 User Manual | © National Instruments | 49...
-
Page 50: Alarm Codes
NI product. Refer to the Export Compliance Information at ni.com/legal/export-compliance for the National Instruments global trade compliance policy and how to obtain relevant HTS codes, ECCNs, and other import/export data. NI MAKES NO EXPRESS OR IMPLIED WARRANTIES AS TO THE ACCURACY OF THE INFORMATION CONTAINED HEREIN AND SHALL NOT BE LIABLE FOR ANY ERRORS.
